User manual 3D Systems CubePro Trio 3D Printer 401735

Operating instructions and pdf manual for use - 3D Systems CubePro Trio 3D Printer 401735 User manual, User manual 3D Systems CubePro Trio 3D Printer 401735, 3D, Systems, CubePro, Trio, 3D, Printer, 401735, Video


User manual for 3D Systems CubePro Trio 3D Printer 401735

3D Systems  CubePro Trio 3D Printer 401735
  • Manufacturer: 3D Systems
  • Basic description and contents of package
  • Product classification: Computers & Solutions - Printers & Accessories - 3D Printers
  • Safety instructions
  • Startup and operation of the 3d printers
  • Tips for setting up your 3D Systems
  • Settings and expert assistance
  • Contact 3D Systems service
  • Troubleshooting
  • Warranty information
3D Systems  CubePro Trio 3D Printer 401735 3D Systems  CubePro Trio 3D Printer 401735 3D Systems  CubePro Trio 3D Printer 401735
Click to enlarge image

We recommend checking out our discussion threads on the 3D Systems CubePro Trio 3D Printer 401735, which address similar problems with connecting and setting up 3D Printers 3D Systems.



User manual for the 3D Systems CubePro Trio 3D Printer 401735

The user manual for the 3D Systems CubePro Trio 3D Printer 401735 provides necessary instructions for the proper use of the product Computers & Solutions - Printers & Accessories - 3D Printers.

The CubePro Trio from 3D Systems is a 3D printer capable of printing with up to three colors of ABS, PLA, and Nylon materials, at resolutions as fine as 70 microns. Design models up to 7.3 x 10.75 x 9.5" in volume, or larger if using just one or two extruders, and the CubePro will build them by melting plastic in thin sheets, depositing layer upon layer until they form a three-dimensional object.

Filaments for the CubePro come in smart cartridges that detect the type and quantity of material in the cartridge, which prompts the CubePro to adjust printing settings accordingly. The triple extruders work with over 20 colors of filament to produce thousands of possible color combinations for your prints.

Also included is 3D Systems' Cubify Invent software, which allows you to create and modify 3D designs in preparation for printing. You can also design your model in any other CAD software, because the CubePro software will convert your .stl file to the .cubepro extension that your CubePro will print. Transfer your .cubepro file onto the included USB stick and insert directly into your printer, or send it wirelessly via Wi-Fi from your desktop.

The fully-assembled CubePro Trio comes with white, neon green, and red ABS cartridges, 25 free designs, and a USB stick to help you start printing right out of the box.
If you own a 3D Systems 3d printers and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the 3D Systems CubePro Trio 3D Printer 401735 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the 3D Systems CubePro Trio 3D Printer 401735:
Specifications
    Printer
    Print Technology Plastic Jet Printing (PJP)
    Build Volume 7.3 x 10.8 x 9.5" / 18.5 x 27.3 x 24.1 cm Using 3 Extruders
    9.0 x 10.8 x 9.5" / 22.9 x 27.3 x 24.1 cm Using 2 Extruders
    10.8 x 10.8 x 9.5" / 27.3 x 27.3 x 24.1 cm Using 1 Extruder
    Layer Resolution (XY Axis) 70 microns / 0.07 mm
    200 microns / 0.2 mm
    300 microns / 0.3 mm
    Z Axis Resolution 100 microns / 0.1 mm
    Number of Extruders 3
    Extruder Nozzle Temperature 536°F / 280°C
    Print Speed Maximum: 15 mm/s
    Positioning Precision X: 200 microns / 0.2 mm
    Y: 200 microns / 0.2 mm
    Filament Diameter 1.75 mm
    Filament Compatibility ABS, Nylon, PLA
    Enclosure
    Build Area Enclosed
    Filament Spool Storage Proprietary Cartridge
    Camera No
    Scanner No
    Build Plate
    Composition Not Specified By Manufacturer
    Heated Not Specified By Manufacturer
    Leveling Not Specified By Manufacturer
    Connectivity
    Supported Wi-Fi Standards Yes
    Software
    Mac OS X Compatibility 10.8 and Above
    General
    Power Requirements 100 to 240 VAC/
    Dimensions - (WxHxD) 22.75 x 22.75 x 23.25" / 57.79 x 57.79 x 59.05 cm
    Weight 98 lb / 44.45 kg
    Packaging Info
    Package Weight 138.2 lb
    Box Dimensions (LxWxH) 32.0 x 26.0 x 26.0"
    The user manual for the 3D Systems CubePro Trio 3D Printer 401735 can be downloaded in .pdf format if it did not come with your new 3d printers, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other 3D Systems users keep a unique electronic library for 3D Systems 3d printerss, where you can use our link to download the user manual for the 3D Systems CubePro Trio 3D Printer 401735.

    The user manual lists all of the functions of the 3D Systems CubePro Trio 3D Printer 401735, all the basic and advanced features and tells you how to use the 3d printers. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from 3D Systems service.

    If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the 3D Systems CubePro Trio 3D Printer 401735. User manuals are also available on the 3D Systems website under Computers & Solutions - Printers & Accessories - 3D Printers.
