User manual for the Atlona 7" Pro HD Monitor (Rack Mount) AT-DIS7-PROHD

The user manual for the Atlona 7" Pro HD Monitor (Rack Mount) AT-DIS7-PROHD provides necessary instructions for the proper use of the product Professional Video - Monitors - On Camera Monitors.

The Atlona 7" Pro HD Monitor (Rack Mount) is used to test the cabling and installation of equipment from a remote location. Using the monitor, installation problems can be efficiently investigated and fixed from a remote location. The AT-DIS7-PROHD Monitor is compatible with HDMI, DVI, VGA, or Component video source and supports resolutions up to 1080p and 1920 x 1200. It offers a brightness of 400 nits and contrast of 500 nits and is ideal for use in residential and commercial installations.

Equipped with built-in speakers, the AT-DIS7-PROHD Monitor allows you to view audio and video signals in real-time and ensures that cables, extenders, switchers, and AV receivers are functioning efficiently and transmitting signals properly during installation. The monitor is configured to display a message when it receives 3D signals.

When the monitor is connected to the AT-HD800 HDMI Signal Generator, the installer can be used to test HDCP, EDID, and 3D resolutions. On connecting the monitor to a camera, you can view videos that are being recorded. Tripod inputs (2 x 1/4") on the top and bottom of the unit allow it to be easily connected to a tripod setup. The monitor comes with a 5’ (1.5m) VGA to component cable and can be rack-mounted on a 4RU unit.
If you own a Atlona on camera monitors and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Atlona 7" Pro HD Monitor (Rack Mount) AT-DIS7-PROHD in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
User manual for Atlona 7Download user manual for Atlona 7" Pro HD Monitor (Rack Mount) AT-DIS7-PROHD
(PDF file, 0.4 MB)
Additional parameters of the Atlona 7" Pro HD Monitor (Rack Mount) AT-DIS7-PROHD:
Screen Size 7" diagonal
Maximum Resolution 1080p or 1920 x 1200
Refresh Rate 50/60 Hz
Power Supply 5V/2.6A DC (Universal)
Power / Consumption 9.6W
Operating Temperature 32 ~ 104°F (0 ~ 40°C)
Inputs HDMI (DVI Compatible) and HD15 (VGA or Component Compatible)
Resolution 480i/p, 576i/p, 720p 50/60, 1080i 50/60, 1080p 50/60, VGA~WUXGA - 640x480 ~1920x1200 (includes all VESA Resolutions)
Speakers 2W
Tripod 2 x 1/4" input holes
Power Requirements 5V/1.9A (User can purchase an optional battery)
Base Dimensions (WxHxD) 7.7 x 7.1 x 1
Weight 2.5lb
Power Supply 5V/2.6A DC (Universal)
Power Consumption 9.6W
Storage Temperature -20°C ~60°C / -4°F~140°F
Relative Humidity 20~90% RH (non-condensing)
Packaging Info
Package Weight 4.1 lb
Box Dimensions (LxWxH) 11.9 x 10.3 x 2.8"
The user manual for the Atlona 7" Pro HD Monitor (Rack Mount) AT-DIS7-PROHD can be downloaded in .pdf format if it did not come with your new on camera monitors, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Atlona users keep a unique electronic library for Atlona on camera monitorss, where you can use our link to download the user manual for the Atlona 7" Pro HD Monitor (Rack Mount) AT-DIS7-PROHD.

The user manual lists all of the functions of the Atlona 7" Pro HD Monitor (Rack Mount) AT-DIS7-PROHD, all the basic and advanced features and tells you how to use the on camera monitors. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Atlona service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Atlona 7" Pro HD Monitor (Rack Mount) AT-DIS7-PROHD. User manuals are also available on the Atlona website under Professional Video - Monitors - On Camera Monitors.
