User manual for the Atlona AT-UHD-H2H-44M 4K/UHD HDMI to HDMI Matrix AT-UHD-H2H-44M
The user manual for the Atlona AT-UHD-H2H-44M 4K/UHD HDMI to HDMI Matrix AT-UHD-H2H-44M provides
necessary instructions for the proper use of the product Professional Video - Signal Processing & Distribution - Routers & Switchers.
The AT-UHD-H2H-44M 4K/UHD HDMI to HDMI Matrix Switcher from Atola is a 4 x 4 switcher that routes any 4K/UHD @ 60Hz (4:2:0, 8-bit) source to any 4K/UHD destination with full HDCP 2.2 content protection. It supports various control functions like I/O routing from tablets, smart phones, or PCs. The switcher integrates with any TCP/IP, RS-232, or IR-based control system and can be controlled via the included IR remote or the controls available on the front panel. For ease of setup and management, the matrix includes a GUI-based integrated Web server for HDCP/EDID reporting, system configuration, and device status. The Web GUI uses an easy, intuitive drop down menu for fast setup and troubleshooting in the field.
If you own a Atlona routers & switchers and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Atlona AT-UHD-H2H-44M 4K/UHD HDMI to HDMI Matrix AT-UHD-H2H-44M in the following formats:
*.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Atlona AT-UHD-H2H-44M 4K/UHD HDMI to HDMI Matrix AT-UHD-H2H-44M:
4096 x 2160 @ 50/60 Hz & 3840 x 2160 @ 50/60 Hz supported @ chroma subsampling 4:2:0 8-bit only.
VESA
2560 x 2048, 2560 x 1600, 2048 x 1536, 1920 x 1200, 1680 x 1050, 1600 x 1200, 1600 x 900, 1440 x 900, 1400 x 1050, 1366 x 768, 1360 x 768, 1280 x 1024, 1280 x 800, 1280 x 768, 1152 x 768, 1024 x 768, 800 x 600, 640 x 480
With Feet: 2.2 x 17.3 x 10.0" (5.6 x 43.9 x 25.4 cm) With Rack Ears: 1.7 x 19.0 x 10.0" (4.3 x 48.3 x 25.4 cm) Rack Unit: 1 RU
Weight
6.55 lb (2.97 kg)
