User manual for the Bosch AUTODOME 5000 Series VEZ-513-EWCR Day/Night F.01U.277.826
The user manual for the Bosch AUTODOME 5000 Series VEZ-513-EWCR Day/Night F.01U.277.826 provides
necessary instructions for the proper use of the product Surveillance - Surveillance Video - Wired Analog & HD Cameras.
The white AUTODOME 5000 Series VEZ-523-EWCR Day/Night PTZ Outdoor Camera with Clear Rugged Bubble (PAL) from Bosch features a high-resolution 960H sensor that is capable of delivering a maximum resolution of 720 TVL. The Wide Dynamic Range of the sensor allows the camera to capture detailed images even in challenging high contrast scenes.
|
If you own a Bosch wired analog & hd cameras and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Bosch AUTODOME 5000 Series VEZ-513-EWCR Day/Night F.01U.277.826 in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the Bosch AUTODOME 5000 Series VEZ-513-EWCR Day/Night F.01U.277.826:
| System | PAL | | Image Sensor | 960H, 1/4" Double Scan CCD, 720 TVL sensor resolution | | Effective Pixels (H x V) | Approximately 570,000; 976 x 582 (PAL) | | Horizontal Resolution | 720 TVL (960H with WDR capability) | | Lens | 3.43 to 120 mm, F1.6 to 4.5 | | Focus | Constant, Manual, Spot | | Iris | Auto, Manual | | Field of View (H x V x D) | Optical Zoom
Wide: 57.8 x 43.4 x 72.3°
Tele: 1.70 x 1.28 x 2.13° | | Gain Control | Auto, Manual | | Digital Zoom | 12x | | Sensitivity | 30 IRE
Day Mode: 0.1 lux, under F1.6
Night Mode (B&W): 0.01 lux, under F1.6 | | Electronic Shutter Speed | 1/50 to 1/10000 sec | | Wide Dynamic Range | On, Off | | Signal-to-Noise Ratio | >60 dB (with AGC off) | | White Balance | Auto, Manual, Indoor, Outdoor, ATW | | Video Output | 1 Vpp / 75 Ω, BNC | | Pan Range | 360° continuous | | Tilt Range | 0 to 180° | | Speed | Manual: 0.5 to 90° / sec
Pre-position: 5 to 360° / sec | | Preset Accuracy | 0.225° | | Flip / Mirror | Image: 180°
Mechanical: 90° | | Input Voltage | 24 VAC, 50/60 Hz | | Power Consumption | With Heater: 50 W | | Privacy Masking | 20 individually-configurable masks | | DNR | 2 DNR / 3 DNR | | AGC (Automatic Gain Control) | Auto, manual | | Backlight Compensation | On, Off | | Proportional Pan / Tilt to Zoom | On, Off | | Image Enhancement | Zoom, Stabilize, Off | | Nightview | On, Off, Auto | | Prepositions | 99 | | Tours | 8 | | Auto Pan | 4 | | Preset Tours | 8 | | Camera Setup/Control | RS-485 | | Communications | Bosch OSRD, Pelco D/P | | Supported Languages | English, Dutch, French, German, Italian, Polish, Portuguese, Russian, Spanish, Simplified Chinese | | Inputs | 4 x 5 V 10 kΩ pull up | | Outputs | 2 x relay
Maximum 2 A, 30 VDC / 0.5 A, 125 VAC | | Ingress Protection Rating | IP66 | | Operating Temperature | -40 to 122°F (-40 to 50°C) | | Storage Temperature | -4 to 158°F (-20 to 70°C) | | Humidity | 10 to 90% relative, non-condensing | | Heater | Turns on at 19.4°F (-7°C)
Turns off at 37.4°F (3°C) | | Electromagnetic Compatibility | Complies with FCC part 15, ICES-003, EN 55022:1998, EN 50130-4:1995, EN61000-3-2:2000 and EN 61000-3-3:1995 | | Safety | EN60950-1:2006, +A11:2009, A1:2010, +A12:2011 / UL 60950-1 | | Material | Housing: Die-cast aluminum
Sunshield: Outdoor-grade plastic | | Dimensions (Diam. x H) | With Sunshield: 8.2 x 11.6" (20.8 x 29.5 cm)
Without Sunshield: 7.4 x 11.6" (18.6 x 29.5 cm) | | Weight | 8.0 lb (3.6 kg) with sunshield | |
