This 328 ft SMPTE Hybrid FMW/PBW LEMO Belden Indoor Fiber Cable from Camplex is a chassis-mount interconnect cable combining optical, electrical, and control signal paths. It features a round flange FMW LEMO connector and square flange PBW LEMO connector. It uses a Belden CMR Riser Rated indoor cable suitable for permanent installations in building risers. All assemblies are tested for < -55dB return loss, exceeding SMPTE 304M/311M standards. Diagnostics documentation is provided with each cable.

This cable is standardized by SMPTE for HDTV broadcast camera use. It supports 19.4 Mbps to 3 Gbps bandwidths.
If you own a Camplex fiber optic cables and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Camplex SMPTE Hybrid FMW/PBW LEMO Belden Indoor HF-FMWPBW-R-0328 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Camplex SMPTE Hybrid FMW/PBW LEMO Belden Indoor HF-FMWPBW-R-0328:
Specifications
    Length 328 ft (100 m)
    Cable Type Belden US SMPTE standard UL Listed CMR Riser Rated indoor broadcast cable
    Connector 1 Round flange FMW LEMO connector
    Connector 2 Square flange PBW LEMO connector
    Bandwidth 19.4 Mbps to 3 Gbps
    Diagnostics Tested for < -55dB return loss (documentation provided with each cable)
