User manual for the Canon 6815B001 VB-H710F Full HD Fixed IP Camera 6815B001

The user manual for the Canon 6815B001 VB-H710F Full HD Fixed IP Camera 6815B001 provides necessary instructions for the proper use of the product Surveillance - Surveillance Video - Wired IP Cameras.

The Canon 6815B001 VB-H710F Full HD Fixed IP Camera, featuring Canon's DIGIC DV III image processor, is a fixed box security camera that offers easy installation and HD quality videos. The 112.6° wide-angle lens on the VB-H710F camera is designed to maximize the camera's low light performance, allowing it to capture clear color videos even under 0.3 lux and black & white videos under 0.015 lux. A 3x optical zoom and built-in motorized focus and zoom function enables users to adjust those settings at any time from any Internet-connected PC, which is a major benefit for inaccessible and/or large-scale installations. The camera features 9 levels of exposure compensation that add to the image capture range.

The VB-H710F camera has a 2.1 MP CMOS sensor that captures detailed images in resolutions up to 1920 x 1080. The sharp images can be streamed with low bandwidth utilization and using less disk space thanks to the H.264 codec, which allows video to be streamed at up to 8 different rates.

This IP camera integrates the advanced 16:9 CMOS sensor and the DIGIC DV III image processor, and the DIGIC NET II network video processor to deliver full 1920 x 1080 HD images at up to 30 fps in both H.264 and M-JPEG. The VB-H710F also provides ONVIF (Open Network Video Interface Forum) Profile S conformance for compatibility with other ONVIF-compliant 3rd party devices.

The VB-H710F camera offers an impressive assortment of sophisticated on-board video analytics, including Moving Object Detection, Removed Object Detection, Abandoned Object Detection, Camera Tampering Detection, Volume Level Detection, and Passing (or “tripwire”) Detection. You can also program the camera with up to 20 digital preset positions and create a custom tour if desired.

A Digital PTZ feature enables you to digitally zoom in and crop-out up to 5 portions of the image. The VB-H710F can then digitally encode and transmit just those cropped areas, which can be viewed in a pre-set tour, in essence providing this fixed camera with PTZ capabilities.

The VB-H710F camera includes a privacy mask function which can be used to block selected areas of the camera’s view. In sensitive locations where surveillance is required but particular areas can’t be seen or recorded, such as door entry or ATM keypads, computer monitors or apartment windows, the camera will hide that area via a privacy mask while still capturing a full range of motion.

The camera features SDXC memory card compatibility, which allows storage of an impressive amount of recorded video on the card memory (card sold separately). This plug and play capability ensures that integrating a VB-H710F camera into your existing network takes very little time.
If you own a Canon wired ip cameras and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Canon 6815B001 VB-H710F Full HD Fixed IP Camera 6815B001 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Canon 6815B001 VB-H710F Full HD Fixed IP Camera 6815B001:
Camera
Image Sensor 1/3" type CMOS (primary color filter)
Number of Effective Pixels Approximately 2.1 million pixels
Scanning Method Progressive
Lens 3x optical (4x digital) zoom lens (electric drive)
Focal Length 2.8 mm (wide) to 8.4 mm (tele)
F Number F1.2 (wide) to F2.0 (tele)
Viewing Angle Horizontal: 112.6° (wide) to 36.7° (tele)
Vertical: 60.8° (wide) to 20.6° (tele)
Day/Night Switching Auto / manual
Minimum Subject Illumination Day Mode (Color):
0.3 lux: F1.2, shutter speed 1/30 sec, when Smart Shade Control is off, 50 IRE
0.02 lux: F1.2, shutter speed 1/2 sec, when Smart Shade Control is off, 50 IRE
0.008 lux: F1.2, shutter speed 1/2 sec, when Smart Shade Control is on, 50 IRE
Night Mode (Monochrome):
0.015 lux: F1.2, shutter speed 1/30 sec, when Smart Shade Control is off, 50 IRE
0.001 lux :F1.2, shutter speed 1/2 sec, when Smart Shade Control is off, 50 IRE
0.0005 lux: F1.2, shutter speed 1/2 sec, when Smart Shade Control is on, 50 IRE
Focus One-shot AF /manual / fixed at infinity
Shooting Distance Range From Front of Lens
Day Mode: 12' to infinity (3.65 m to infinity)
Night Mode: 3.3' to infinity (1.01 m to infinity)
Shutter Speed 1, 1/2, 1/4, 1/8, 1/15, 1/30, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1,000, 1/2,000, 1/4,000, 1/8,000, 1/16,000 sec
Exposure Auto/ auto (flickerless) / auto (shutter-priority AE) / manual (shutter speed, aperture, gain)
White Balance Auto/ light source (daylight fluorescent / white fluorescent / warm fluorescent / mercury lamp / sodium lamp / halogen lamp) / lock (one-shot WB) / manual
Metering Modes Center-weighted / average / spot
Exposure Compensation 9 levels
Smart Shade Control 7 levels (increases the brightness of shaded subjects in a video)
AGC (Automatic Gain Control) 5 levels
Server
Video Compression Format M-JPEG & H.264
Video File Size M-JPEG: 1920 x 1080, 960 x 540, 480 x 270, 320 x 240
H.264: 1920 x 1080, 960 x 540, 480 x 270
Video Quality M-JPEG, H.264: 5 levels
Frame Rate M-JPEG: 0.1 to 30 fps
H.264: 1 / 2 / 3 / 5 / 6 / 10 / 15 / 30 fps
Maximum Frame Rate 1920 x 1080: 30 fps
I-Frame Interval 0.5 / 1 / 1.5 / 2 / 3 / 4 / 5 sec
Simultaneous Client Access Maximum 30 clients + 1 admin client

H.264: maximum 10 clients

Camera Control Administrator, authorized user, guest user (level of control varies depending on user) Maximum 50 user names and passwords registered for authorized users.
Access Control User authority (user name and password)
Host access restrictions (IPv4, IPv6)
Encrypted Communications SSL/TLS, IPsec (auto key exchange / manual)
Protocols IPv4: TCP/IP, UDP, HTTP, FTP, SNMP (MIB2), SMTP (client), DHCP (client), DNS (client), ARP, ICMP, POP3, NTP, SMTP authentication, RTSP, WV-HTTP (Canon proprietary), ONVIF IPv6: TCP/IP, UDP, HTTP, FTP, SMTP (Client), DNS (Client), ICMPv6, POP3, NTP, SMTP authentication, RTSP, WV-HTTP (Canon proprietary), ONVIF
Audio Compression Method G.711 µ-law (64 Kbps)
Audio Communication Full-duplex (2-way), echo cancellation function compliant
Sound transfer protocol by Canon

Speakers are not included.

Preset Maximum 20 positions (digital) (Preset Tour capable)
Intelligent Function Video Detection Types: Moving object detection, abandoned object detection, removed object detection, camera tampering detection, and passing detection
Detection Settings: Maximum 15
Volume: Volume detection
Image Upload FTP/HTTP/SMTP (email)
Temporary Storage Memory in Camera: Maximum approximately 5 MB
Frame Rate: Maximum 10 fps
Event Notification HTTP/SMTP (email)
Image Crop Digital PTZ Cropping Sizes: 640 x 360, 512 x 288, 384 x 216, 256 x 144, 128 x 72
IP Auto
Interface
Network Terminal 1x LAN (RJ45, 100Base-TX) (auto / full-duplex / half-duplex)
Audio Input Terminals 1x mini-jack connector (mono), line-in or mic-in
Audio Output Terminals 1x mini-jack connector (mono), line-out
External Device I/O Terminals 2x Input, 2x output
Memory Card SD, SDHC, SDXC memory card compatible
Frame Rate: Maximum 1 fps
Operating Environment
Temperature 14 to 122° F (-10 to 50° C)
Humidity 5 to 85% (without condensation)
Power Supply
PoE PoE power supply via LAN Connector (IEEE802.3af compliant)
External Power 24 VAC / 12 VDC
Power Consumption PoE: 6.9 W maximum (approximately)
AC Adapter PA-V17: 8.64 W maximum (approximately)(sold separately)
DC: 7 W maximum (approximately)
AC: 6.5 W maximum (approximately)
Mechanical
Dimensions (W x D x H) 2.56 x 3.15 x 7.56" (65 x 80 x 192 mm)
Weight 1.48 lb (0.67 kg)
