We recommend checking out our discussion threads on the For.A HVS-300HS 1M/E HANABI HD/SD Portable Video HVS300HS B, which address similar problems with connecting and setting up Production Switchers For.A.



User manual for the For.A HVS-300HS 1M/E HANABI HD/SD Portable Video HVS300HS B

The user manual for the For.A HVS-300HS 1M/E HANABI HD/SD Portable Video HVS300HS B provides necessary instructions for the proper use of the product Professional Video - Studio & EFP Equipment - Production Switchers.

The HVS-300HS 1M/E HANABI HD/SD Portable Video Switcher (type B) from For.A is a 1U switcher that offers (4) HD/SD-SDI inputs and outputs. This "type B" model of the switcher refers to the combination of the HVS-300MU mains unit and a separate HVS-30OU operating unit. The mains unit is controlled with the separate desktop controller, although other control options are available.
If you own a For.A production switchers and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the For.A HVS-300HS 1M/E HANABI HD/SD Portable Video HVS300HS B in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the For.A HVS-300HS 1M/E HANABI HD/SD Portable Video HVS300HS B:
Inputs/Outputs Standard:
HD:
1080/60i, 1080/59.94i, 1080/50i, 1080/24PsF, 1080/23.98PsF, 720/60p, 720/59.94p, 720/50p (selectable at menu)
SD:
525/60 (NTSC), 625/50 (PAL) (selectable at menu)

Processing
4:2:2:4, 10-bit, digital component

Quantization:
Y: 10-bit, C: 10-bit, KEY: 10-bit

Video Input:
HD:
HD-SDI: 1.485Gbps or 1.485/1.001Gbps, or SD-SDI: 270Mbps, 75 Ohms, 4 inputs, BNC
SD:
SD-SDI: 270Mbps, 75 Ohms, 4 inputs , BNC

Reference Input:

HD:
BB: NTSC: 0.429Vp-p/PAL: 0.45Vp-p; or Tri-level sync: +/-0.3Vp-p, 75 Ohms or loopthrough, 1 input, BNC
SD:
BB: NTSC: 0.429Vp-p/PAL: 0.45Vp-p, 75 Ohms or loopthrough, 1 input, BNC

Reference Output:
HD:
BB: NTSC: 0.429Vp-p/PAL: 0.45Vp-p; or Tri-level sync: +/-0.3Vp-p, 75 Ohms, 1 output, BNC
SD:
BB: NTSC: 0.429Vp-p/PAL: 0.45Vp-p, 75 Ohms, 1 output, BNC

I/O Delay:
1H (minimum delay mode)
1 frame - 2 frame + 1H (Using frame synchronizer or Input re-sizing engine )
2 frame - 3 frame + 1H (Using frame synchronizer or Input re-sizing engine + DVE)
3 frame - 4 frame + 1H (Using frame synchronizer or Input re-sizing engine + Output re-sizing engine + DVE)

Backup Device:
USB memory device

Interfaces:
EDITOR: 1 port, 9-pin D-sub (female)
RS-422: 1 port, 9-pin D-sub (female)
GPI IN/TALLY: 1 port, 15-pin D-sub (female) (12 in/outputs)
ARCNET: 1 port, 75Ohms or loopthrough, BNC
Ethernet: 10/100Base-T, 1 port, RJ-45

Power 100 to 240VAC, +/-10%, 50/60Hz, maximum 220VA (211W)
Dimensions (HxWxD) HVS-300: 1.73 x 16.93 x 16.93" (44 x 430 x 430mm)
HVS-30OU: 3.43 x 16.54 x 9.69" (87.2 x 420 x 246mm)
Weight HVS-300: 22 lbs (10kg)
HVS-30OU: 6.6 lbs (3kg)
Packaging Info
Package Weight 25.5 lb
Box Dimensions (LxWxH) 23.6 x 23.2 x 9.3"
The user manual for the For.A HVS-300HS 1M/E HANABI HD/SD Portable Video HVS300HS B can be downloaded in .pdf format if it did not come with your new production switchers, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other For.A users keep a unique electronic library for For.A production switcherss, where you can use our link to download the user manual for the For.A HVS-300HS 1M/E HANABI HD/SD Portable Video HVS300HS B.

The user manual lists all of the functions of the For.A HVS-300HS 1M/E HANABI HD/SD Portable Video HVS300HS B, all the basic and advanced features and tells you how to use the production switchers. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from For.A service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the For.A HVS-300HS 1M/E HANABI HD/SD Portable Video HVS300HS B. User manuals are also available on the For.A website under Professional Video - Studio & EFP Equipment - Production Switchers.
