User manual FSR PFD-12X8-SA Pathfinder 12x8 S-Video & Stereo PFD-12X8-SA

Operating instructions and pdf manual for use - FSR PFD-12X8-SA Pathfinder 12x8 S-Video & Stereo PFD-12X8-SA User manual, User manual FSR PFD-12X8-SA Pathfinder 12x8 S-Video & Stereo PFD-12X8-SA, FSR, PFD-12X8-SA, Pathfinder, 12x8, S-Video, &, Ster


User manual for FSR PFD-12X8-SA Pathfinder 12x8 S-Video & Stereo PFD-12X8-SA

FSR PFD-12X8-SA Pathfinder 12x8 S-Video & Stereo PFD-12X8-SA
  • Manufacturer: FSR
  • Basic description and contents of package
  • Product classification: Professional Video - Signal Processing & Distribution - Routers & Switchers
  • Safety instructions
  • Startup and operation of the routers & switchers
  • Tips for setting up your FSR
  • Settings and expert assistance
  • Contact FSR service
  • Troubleshooting
  • Warranty information
We recommend checking out our discussion threads on the FSR PFD-12X8-SA Pathfinder 12x8 S-Video & Stereo PFD-12X8-SA, which address similar problems with connecting and setting up Routers & Switchers FSR.



User manual for the FSR PFD-12X8-SA Pathfinder 12x8 S-Video & Stereo PFD-12X8-SA

The user manual for the FSR PFD-12X8-SA Pathfinder 12x8 S-Video & Stereo PFD-12X8-SA provides necessary instructions for the proper use of the product Professional Video - Signal Processing & Distribution - Routers & Switchers.

The PFD-12X8-SA Pathfinder 12x8 S-Video & Stereo Audio Matrix Switcher from FSR is a matrix switcher designed for use with S-video and stereo audio signals. It features (12) inputs and (8) outputs. The system is designed to provide flat signals and adequate bandwidth to all connected components to ensure optimum fidelity. This switcher is well suited for use in video conference rooms, educational facilities, control rooms, monitoring centers, and government institutions, among many other possible applications.

The Pathfinder offers split-mode switching technology, which permits each color channel to be independently switched. This feature also allows the switcher to perform the duties of several units and ensures that its switching capabilities will not become obsolete as video types and resolutions are upgraded in the future.

Control of the unit can be managed via an ASCII command set that will provide complete access to all functions via compatible control systems. Moreover, the switcher includes both RS-232 and IP control ports. This unit may be used as a standalone device, but has also been designed for placement in a standard 19" rack.
If you own a FSR routers & switchers and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the FSR PFD-12X8-SA Pathfinder 12x8 S-Video & Stereo PFD-12X8-SA in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the FSR PFD-12X8-SA Pathfinder 12x8 S-Video & Stereo PFD-12X8-SA:
Construction Metal
Finish Black, white
Inputs/Outputs 12x8
Connectors Female BNC
Bandwidth 200MHz at -3dB
Gain Flatness +/- 0.5dB to 150MHz
Gain Unity
Impedance 75 ohms
Level 0.7V nominal, 2V maximum p-p
Audio Inputs/Outputs: 12x8
Type: balanced
Connector: 5-position pluggable captive screw terminal
Frequency: 20Hz to 20KHz
HD + Noise: 0.05% at 1KHz at maximum rated output
S/N Ratio: >90dB
Impedance:
Input: 10K ohms
Output: 50 ohms
Max level (input & output): +22dBm
Input gain switch: 0/ +14dB switchable by input
Input trim range: +/-10dB by input
Output volume range: -45 to +5dB by output
Dimensions (HxWxD) Not specified by manufacturer
Weight Not specified by manufacturer
The user manual for the FSR PFD-12X8-SA Pathfinder 12x8 S-Video & Stereo PFD-12X8-SA can be downloaded in .pdf format if it did not come with your new routers & switchers, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other FSR users keep a unique electronic library for FSR routers & switcherss, where you can use our link to download the user manual for the FSR PFD-12X8-SA Pathfinder 12x8 S-Video & Stereo PFD-12X8-SA.

The user manual lists all of the functions of the FSR PFD-12X8-SA Pathfinder 12x8 S-Video & Stereo PFD-12X8-SA, all the basic and advanced features and tells you how to use the routers & switchers. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from FSR service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the FSR PFD-12X8-SA Pathfinder 12x8 S-Video & Stereo PFD-12X8-SA. User manuals are also available on the FSR website under Professional Video - Signal Processing & Distribution - Routers & Switchers.
