User manual Futaba 14SGH 14-Channel 2.4 GHz Computer Radio System FUTK9411

Operating instructions and pdf manual for use - Futaba 14SGH 14-Channel 2.4 GHz Computer Radio System FUTK9411 User manual, User manual Futaba 14SGH 14-Channel 2.4 GHz Computer Radio System FUTK9411, Futaba, 14SGH, 14-Channel, 2.4, GHz, Computer, R


User manual for Futaba 14SGH 14-Channel 2.4 GHz Computer Radio System FUTK9411

Overall rating 5.0
Overall Rating: 5.0

100% of respondents would recommend this to a friend.
Futaba 14SGH 14-Channel 2.4 GHz Computer Radio System FUTK9411
  • Manufacturer: Futaba
  • Basic description and contents of package
  • Product classification: Camcorders - Aerial Imaging & Drones - Remote Control Components
  • Safety instructions
  • Startup and operation of the remote control components
  • Tips for setting up your Futaba
  • Settings and expert assistance
  • Contact Futaba service
  • Troubleshooting
  • Warranty information
  • Price: 600 USD
We recommend checking out our discussion threads on the Futaba 14SGH 14-Channel 2.4 GHz Computer Radio System FUTK9411, which address similar problems with connecting and setting up Remote Control Components Futaba.



User manual for the Futaba 14SGH 14-Channel 2.4 GHz Computer Radio System FUTK9411

The user manual for the Futaba 14SGH 14-Channel 2.4 GHz Computer Radio System FUTK9411 provides necessary instructions for the proper use of the product Camcorders - Aerial Imaging & Drones - Remote Control Components.

The heli-optimized 14SGH 14-Channel 2.4 GHz Computer Radio System from Futaba is a transmitter (radio controller) that can be programmed to control a multitude of RC aircraft, including fixed-wind planes, helicopters and multi-rotors, and gilders. It can also be used with certain production equipment, such as video stabilizer gimbals, that have compatible receivers. The transmitter features 14-channels and supports receivers with the FASSTest, FASST, and S-FHSS protocols. The "H" in the model number indicates that the throttle gimbal is smooth rather than ratcheted, which is considered the preferred arrangement by many heli fliers.

The programmable computer is able to store settings for up to 30 models internally, and this memory can be expanded using an SD or SDHC card up to 32GB in capacity. To access the menu to change settings or view data from the aircraft (where supported) there is a 1.8 x 3" back-lit LCD screen. The transmitter is configured for Mode 2. Mode two is the most common in the U.S., however users in other countries may be accustomed to a different Mode. In Mode 2, roll and pitch are controlled with the pilot's right hand while yaw and throttle are controlled with the pilot's left hand.
If you own a Futaba remote control components and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Futaba 14SGH 14-Channel 2.4 GHz Computer Radio System FUTK9411 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
User manual for Futaba 14SGH 14-Channel 2.4 GHz Computer Radio System FUTK9411Download user manual for Futaba 14SGH 14-Channel 2.4 GHz Computer Radio System FUTK9411
(PDF file, 4.3 MB)
Additional parameters of the Futaba 14SGH 14-Channel 2.4 GHz Computer Radio System FUTK9411:
Transmitter
Modulation FASSTest, FASST, S-FHSS
Band 2.4 GHz
Number of Channels Proportional: 12
Switched: 2
Computer
Computer Radio Yes
Model Memory 30
Naming User Naming: 10-character
Model Naming: 10-character
Programming Airplane, helicopter, glider
Modes Modes 2
Expansion Storage SD/SDHC memory cards from 32 MB to 32 GB
Display
Type Back-lit LCD
Size 1.8 x 3" / 4.4 x 7.6 cm
Resolution 128 x 64
General
Battery Type 6V 1800 mAh NiMH battery pack
Dimensions Not specified by manufacturer
Weight Not specified by manufacturer
Receiver
Modulation FASSTest 2.4 GHz system, S.Bus system
Antenna Dual antenna diversity
Power Requirements 3.7 to 7.4 VDC battery or regulated output from ESC or other aircraft-based source

Note: When using ESC's, make sure that the regulated output capacity meets your usage application
Dimensions 1 x 1.7 x 0.6" / 24.9 x 47.3 x 14.3 mm
Weight 0.4 oz
Packaging Info
Package Weight 4.2 lb
Box Dimensions (LxWxH) 11.0 x 10.0 x 5.0"
The user manual for the Futaba 14SGH 14-Channel 2.4 GHz Computer Radio System FUTK9411 can be downloaded in .pdf format if it did not come with your new remote control components, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Futaba users keep a unique electronic library for Futaba remote control componentss, where you can use our link to download the user manual for the Futaba 14SGH 14-Channel 2.4 GHz Computer Radio System FUTK9411.

The user manual lists all of the functions of the Futaba 14SGH 14-Channel 2.4 GHz Computer Radio System FUTK9411, all the basic and advanced features and tells you how to use the remote control components. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Futaba service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Futaba 14SGH 14-Channel 2.4 GHz Computer Radio System FUTK9411. User manuals are also available on the Futaba website under Camcorders - Aerial Imaging & Drones - Remote Control Components.
