User manual for the Galaxy Audio AXS-16 16-Input Analog Audio Mixer AXS-16

The user manual for the Galaxy Audio AXS-16 16-Input Analog Audio Mixer AXS-16 provides necessary instructions for the proper use of the product Pro Audio - Live Sound - Sound Reinforcement Mixers.

The AXS-16 from Galaxy Audio is a 16-input analog audio mixer featuring premium-quality mic preamps, stereo line inputs, compressors, EQs, a 24-bit multi-effects processor, and an integrated USB audio interface.
If you own a Galaxy Audio sound reinforcement mixers and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Galaxy Audio AXS-16 16-Input Analog Audio Mixer AXS-16 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Galaxy Audio AXS-16 16-Input Analog Audio Mixer AXS-16:
Inputs & Outputs
Inputs Inputs 1-8: 8 x Balanced XLR or 8 x 1/4"
Inputs 9-16: 8 x 1/4"
Aux Returns: 6 x 1/4"
2TK/USB: 2 x RCA
DSP Mute Switch: 1/4"
Insert Send/Return: 8 x 1/4"
Outputs Main: 2 x XLR, 2 x 1/4"
Sub: 2 x 1/4"
Control Room: 2 x 1/4"
Aux Send: 3 x 1/4"
FX Out: 1 x 1/4"
Monitor: 1 x 1/4"
Phones: 1 x 1/4"
2TK/USB: 2 x RCA
Microphone Inputs
Microphone Type XLR
Electronically Balanced
Discrete Input Circuit
Mic Input Noise (E.I.N.) Mic E.I.N. (20 Hz to 20 kHz):
@ 0 ohm Source Resistance: -134 dB / 135.7 A-weighted
@ 50 ohms Source Resistance: -131 dB / 133.3 dB A-weighted
@ 150 ohms Source Resistance: -129 dB / 130.5 dB A-weighted
Frequency Response: <10 hz to 150 khz (-1 db), <10 200 (-3 db)
Gain Range: +10 to +60 dB
Maximum Input Level: +12 dBu @ +10 dB gain
Impedance: Approximately 2.6 kOhms balanced
Signal to Noise Ratio: 110 dB / 112 dB A-weighted (0 dBu in @ +22 dB gain)
Distortion (THD+N): 0.005% / 0.004% A-weighted
Line Input Type: 1/4" TRS connector electronically balanced
Impedance: Approximately 20 kOhms balanced, 10 kOhms unbalanced
Gain Range: -10 to +40 dB
Maximum Input Level: 30 dBu
Fade-out Attenuation
Crosstalk / Attenuation Main Fader Closed: 90 dB
Channel Muted: 89 dB
Channel Fader Closed: 89 dB
Frequency Response
Microphone Input Microphone Input to Main Out:
<10 hz to 90 khz +0 db > <10 hz to 160 khz +0 db >
Stereo Input Type: 1/4" TRS Connector, electronically balanced
Impedance: Approximately 20 kOhms
Maximum Input Level: +22 dBu
EQ Type Mono Channels Low: ±15 dB shelving at 80 Hz
Mid: ±15 dB peak, sweepable from 100 Hz to 8 kHz
High: ±15 dB shelving at 12 kHz
EQ Type Stereo Channels Low: ±15 dB shelving at 80 Hz
Low-Mid: ±15 dB peak at 500 Hz
High-Mid: ±15 dB peak at 3 kHz
High: ±15 dB shelving at 12 kHz
AUX Sends Type: 1/4" TS connector, unbalanced
Impedance: Approximately 120 Ohms
Maximum Input Level: +22 dBu
AUX Returns Type: 1/4" TRS connector, electronically balanced
Impedance: Approximately 20 kOhms balanced / 10 kOhms unbalanced
Maximum Input Level: +22 dBu
Main Output Type: XLR electronically balanced and 1/4" TS unbalanced
Impedance: Approximately 240 ohm symmetrical / 120 Ohms unbalanced
Maximum Output Level: +28 dBu
Control Room Outputs Type: 1/4" TS connector unbalanced
Impedance: Approximately 120 Ohms
Maximum Output Level: +22 dBu
Headphone Output Type: 1/4" TRS connector, unbalanced
Maximum Output Level: +19 dBu / 150 Ohms (+25 dBm)
Meter 3-color LED
DSP
Converter 24-bit Sigma-Delta
64/128 times oversampling
Sampling Rate 40 kHz
USB
USB Audio: Stereo in/out
Connector: Type B
Converter: 16-bit
Sample Rate: 48 kHz
Main Mix
Noise Main Mix @ -∞ / Channel Fader @ -∞: -101 dB

Main Mix @ 0 dB / Channel Fader @ -∞: -93 dB

Main Mix @ 0 dB / Channel Fader @ 0 dB: -81 dB
Power / Consumption Power Supply: 100-240 VAC, 50/60 Hz
Power Consumption: 50 W
Fuse Fuse: T 1.6 A, 250 V
Dimension (D x W x H) 4.7 x 19.1 x 17.4" (118 x 48.5 x 44.3 cm)
Weight 15.3 lb (6.9 kg)
Packaging Info
Package Weight 6.0 lb
Box Dimensions (LxWxH) 21.063 x 21.063 x 7.874"
The user manual for the Galaxy Audio AXS-16 16-Input Analog Audio Mixer AXS-16 can be downloaded in .pdf format if it did not come with your new sound reinforcement mixers, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Galaxy Audio users keep a unique electronic library for Galaxy Audio sound reinforcement mixerss, where you can use our link to download the user manual for the Galaxy Audio AXS-16 16-Input Analog Audio Mixer AXS-16.

The user manual lists all of the functions of the Galaxy Audio AXS-16 16-Input Analog Audio Mixer AXS-16, all the basic and advanced features and tells you how to use the sound reinforcement mixers. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Galaxy Audio service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Galaxy Audio AXS-16 16-Input Analog Audio Mixer AXS-16. User manuals are also available on the Galaxy Audio website under Pro Audio - Live Sound - Sound Reinforcement Mixers.
