User manual for the HP LaserJet Enterprise M506dh Monochrome Laser Printer
The user manual for the HP LaserJet Enterprise M506dh Monochrome Laser Printer provides
necessary instructions for the proper use of the product Computers & Solutions - Printers & Accessories - Laser Printers.
Finish large printing jobs faster with the LaserJet Enterprise M506dh Monochrome Laser Printer from HP, which incorporates an encrypted 500GB hard disk drive. Capable of automatic duplex printing and speeds of up to 45 ppm, the M506dh is designed to get offices moving and make them more productive. The unit also handles documents ranging in size from 3 x 5" to 8.5 x 14" and has a resolution of 1200 x 1200 dpi for creating crisp text and documents. A first print out time of 11.3 seconds furthers the printer's penchant for speed as well, getting users going in no time.
For general operation, checking and changing settings is simple using a variety of buttons and the 4-line color LCD. Media handling is great as well with the M506dh with a 100-sheet multipurpose tray and a 550-sheet input tray, resulting in a total capacity of 650 sheets. The printer also has a monthly duty cycle of 150,000 pages for durability along with USB 2.0 and Ethernet connectivity options.
|
If you own a HP laser printers and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the HP LaserJet Enterprise M506dh Monochrome Laser Printer in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the HP LaserJet Enterprise M506dh Monochrome Laser Printer:
| Printing Technology | Laser; HP FastRes 1200, HP ProRes 1200 | | Maximum Resolution | 1200 x 1200 dpi | | Print Speed | 45 ppm | | First Print Out Speed | 11.3 sec | | Print Color | Black | | Duplex Printing | Automatic | | Printer Duty Cycle | Monthly: 150,000 pages
Recommended Monthly Volume: 2,000-7,500 pages | | Print Features | FutureSmart Firmware, Open Extensibility Platform, Instant-on Technology, HP Auto-On/Auto-Off technology, Easy Access USB, Two-Sided Printing, JetIntelligence cartridges, Mopria-certified, Apple AirPrint, HP ePrint, Hardware Integration Pocket, Online help | | Paper Handling | Multipurpose tray
Input tray 1
Output bin | | Paper Types | Paper (bond, color, letterhead, plain, preprinted, prepunched, recycled, rough), envelopes, labels, cardstock, transparencies, user-defined | | Paper Sizes | Multipurpose Tray: 3 x 5" to 8.5 x 14" / 7.6 x 12.7 cm to 21.6 x 35.6 cm
Input Tray: 4.1 x 5.8" to 8.5 x 14" / 10.4 x 14.7 cm to 21.6 x 35.6 cm | | Media Weight | Multipurpose Tray: 16-53 lb
Input Tray: 16-32 lb | | Paper Capacity | Multipurpose Tray: 100 sheets
Input Tray: 550 sheets
Output Bin: 250 sheets | | Interface | USB 2.0
Ethernet | | Wireless Printing Features | HP ePrint, Apple AirPrint, Mopria-certified | | OS Compatibility | Windows XP SP3 (32/64-bit), Vista (32/64-bit), 7 (32/64-bit), 8/8.1 (32/64-bit), 10 (32/64-bit)
Mac OS X 10.8-10.10
iOS, Android, Windows 8/8.1/10 RT
SUSE Linux (12.2, 12.3, 13.1), Fedora (17, 18, 19, 20), Linux Mint (13, 14, 15, 16, 17), Boss (3.0, 5.0), Ubuntu (10.04, 11.10, 12.04, 12.10, 13.04, 13.10, 14.04, 14.10), Debian (6.0.x, 7.x)
UNIX | | Processor | 1.2 GHz | | Memory | Standard: 512 MB
Maximum: 1.5 GB | | Hard Disk | Standard, 500 GB encrypted hard disk drive | | Printer Language | HP PCL 6, HP PCL 5, HP PostScript Level 3 emulation, PDF v1.7 | | Network Protocols | IPv4/IPv6: Apple Bonjour Compatible (Mac OS v10.2.4 or higher), SNMPv1/v2c/v3, HTTP, HTTPS, FTP, TFTP, Port 9100, LPD, WS Discovery, IPP, Secure-IPP, XMPP, IPsec/Firewall
IPv6: DHCPv6, MLDv1, ICMPv6
IPv4: Auto-IP, SLP, Telnet, IGMPv2, BOOTP/DHCP, WINS, IP Direct Mode, WS Print | | Fonts | 105 internal TrueType fonts scalable with HP PCL
92 internal fonts scalable with HP PostScript Level 3 emulation
1 internal Unicode font
2 internal Windows Vista 8 fonts | | Control Panel | 4-line color LCD
19 buttons (cancel job, up and down arrow, select, back, home, 12-key, and help)
3 LED indicator lights (attention, ready, busy) | | Power Requirements | 100-127 VAC, 60 Hz | | Power Consumption | Active Printing: 742 W
Ready: 13.7 W
Sleep: 2.5 W
Auto-Off/Off: <0.1 W | | Typical Power Consumption | 1.886 kWh/week | | Certifications | ENERGY STAR certified
Blue Angel
CECP
EPEAT | | Acoustic Noise | Power Emissions: 6.8 B(A)
Pressure Emissions: 54 dB(A) | | Operating Conditions | Temperature: 59 to 90.5°F / 15 to 32.5°C
Humidity: 10 to 80%, relative
Recommended Temperature: 63.5 to 77°F / 17.5 to 25°C
Recommended Humidity: 30 to 70%, relative | | Storage Conditions | Temperature: -4 to 140°F / -20 to 60°C
Humidity: 10 to 90%, relative | | Dimensions | 16.5 x 14.8 x 11.7" / 41.8 x 37.6 x 29.8 cm
Maximum: 16.5 x 25.2 x 11.7" / 41.8 x 63.9 x 29.8 cm | | Weight | 26.2 lb / 11.9 kg | |
The user manual for the HP LaserJet Enterprise M506dh Monochrome Laser Printer can be downloaded in .pdf
format if it did not come with your new laser printers, although the seller is
required to supply one. It is also quite common that customers throw out
the user manual with the box, or put the CD away somewhere and then can’t find it.
That’s why we and other HP users keep a unique electronic library
for HP laser printerss,
where you can use our link to download the user manual for the HP LaserJet Enterprise M506dh Monochrome Laser Printer.
The user manual lists all of the functions of the HP LaserJet Enterprise M506dh Monochrome Laser Printer,
all the basic and advanced features and tells you how to use the laser printers.
The manual also provides troubleshooting for common problems. Even greater
detail is provided by the service manual, which is not typically shipped with the product,
but which can often be downloaded from HP service.
If you want to help expand our database, you can upload a link to this website
to download a user manual or service manual, ideally in .pdf format. These pages
are created by you – users of the HP LaserJet Enterprise M506dh Monochrome Laser Printer. User manuals are also
available on the HP website under Computers & Solutions - Printers & Accessories - Laser Printers.
