User manual Ikelite Underwater Housing with Panasonic Lumix DMC-GH4 Micro

Operating instructions and pdf manual for use - Ikelite Underwater Housing with Panasonic Lumix DMC-GH4 Micro User manual, User manual Ikelite Underwater Housing with Panasonic Lumix DMC-GH4 Micro, Ikelite, Underwater, Housing, with, Panasonic, Lum


User manual for Ikelite Underwater Housing with Panasonic Lumix DMC-GH4 Micro

Ikelite Underwater Housing with Panasonic Lumix DMC-GH4 Micro
  • Manufacturer: Ikelite
  • Basic description and contents of package
  • Product classification: Photography - Underwater Photography - Still Cameras & Housings
  • Safety instructions
  • Startup and operation of the still cameras & housings
  • Tips for setting up your Ikelite
  • Settings and expert assistance
  • Contact Ikelite service
  • Troubleshooting
  • Warranty information
We recommend checking out our discussion threads on the Ikelite Underwater Housing with Panasonic Lumix DMC-GH4 Micro, which address similar problems with connecting and setting up Still Cameras & Housings Ikelite.



User manual for the Ikelite Underwater Housing with Panasonic Lumix DMC-GH4 Micro

The user manual for the Ikelite Underwater Housing with Panasonic Lumix DMC-GH4 Micro provides necessary instructions for the proper use of the product Photography - Underwater Photography - Still Cameras & Housings.

The Ikelite Underwater Housing with Panasonic Lumix DMC-GH4 Micro Four Thirds Camera Body Kit from B&H Photo bundles Ikelite's #6860.03 waterproof enclosure with the compatible Panasonic Lumix DMC-GH4 4K Mirrorless Micro Four Thirds Digital Camera body. Benefit from the ability to capture sharp, detailed photos and high-definition 4K video at depths up to 200'.

The housing's mechanical controls enable access to all essential camera functions. The enclosure is constructed in the USA from durable, corrosion-resistant polycarbonate, which is clear to enable you to monitor the O-ring seal and camera. A compatible lens port from Ikelite's Standard or Modular system is required and sold separately. Though the camera's built-in flash is not usable, the housing supports TTL flash metering with optional external strobes--without requiring the built-in flash to fire. Strobes connect to the housing via optional sync cords. Non-Ikelite strobes may also be used, but will provide manual exposure only. Included with the housing is an aluminum tray with rubberized grips and two sets of zoom gear sleeves for lenses.

The Panasonic Lumix DMC-GH4 4K Mirrorless Micro Four Thirds Digital Camera body features a 16.05MP Digital Live MOS sensor and a 4-CPU Venus Engine for high-resolution JPEG and RAW still images, UHD 4K 3840x2160p video at 30 and 24 fps, and cinematic DCI 4K 4096x2160p video at 24 fps. Real-time 4:2:2 8-bit and 4:2:2 10-bit video can also be sent to an external monitor or recorder with an optional micro HDMI cable. Additional video features include focus peaking, time code support, and cine-like gamma options. The camera is configured with the Micro Four Thirds mount for various lenses, which are available separately. It has a 3.0" 1,036k-Dot OLED touchscreen and a 2,359K-Dot OLED Live View Finder.
If you own a Ikelite still cameras & housings and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Ikelite Underwater Housing with Panasonic Lumix DMC-GH4 Micro in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
User manual for Ikelite Underwater Housing with Panasonic Lumix DMC-GH4 MicroDownload user manual for Ikelite Underwater Housing with Panasonic Lumix DMC-GH4 Micro
(PDF file, 0.67 MB)
Additional parameters of the Ikelite Underwater Housing with Panasonic Lumix DMC-GH4 Micro:
Specifications
    • Ikelite Underwater Housing for Panasonic Lumix DMC-GH3 or GH4 Digital Camera
      Depth Rating 200' (60 m)
      Control Type Mechanical
      Controls GH3 Camera: Access to all camera functions except Diopter Adjustment Control and Rear Control Dial
      GH4 Camera: Access to all camera functions except Diopter Adjustment Control, Rear Control Dial and Mode Dial Lock
      Mode Dial must be unlocked prior to installation for use underwater with the GH4
      Construction Polycarbonate
      Lens Port Required (not included)
      Buoyancy Nearly neutral in freshwater
      Internal Flash Usable No
      External Strobe Connector Ikelite digital TTL electrical bulkhead for strobe connection via optional sync cord
      Mounting 12-24 thread with 3.0" (7.6 cm) spacing for attaching included tray with handles
      2x quick-release points for lighting arm attachment
      Tripod sockets
      Dimensions 9.8 x 6.9 x 6.5" (24.9 x 17.5 x 16.5 cm)
      Weight 5.4 lb (2.4 kg) without tray and handles
      Packaging Info
      Box Dimensions (LxWxH) 14.724 x 9.37 x 8.583"
    • Panasonic Lumix DMC-GH4 Mirrorless Micro Four Thirds Digital Camera (Body Only)
      Imaging
      Lens Mount Micro Four Thirds
      Camera Format Micro Four Thirds (2x Crop Factor)
      Pixels Actual: 17.2 Megapixel
      Effective: 16.05 Megapixel
      Max Resolution 4608 x 3456
      Sensor Type / Size MOS, 17.3 x 13.0 mm
      File Formats Still Images: JPEG, MPO, RAW
      Movies: MOV, MP4, MPEG-4 AVCHD
      Audio: AAC, Dolby Digital 2ch, Linear PCM
      Dust Reduction System Yes
      Memory Card Type SD
      SDHC
      SDXC
      AV Recording
      Video Recording Yes, NTSC/PAL
      Video Format High Definition
      MOV
      4096 x 2160p / 24 fps (100 Mbps)
      3840 x 2160p / 23.98 fps (100 Mbps)
      3840 x 2160p / 24 fps (100 Mbps)
      3840 x 2160p / 25 fps (100 Mbps)
      3840 x 2160p / 29.97 fps (100 Mbps)
      1920 x 1080p / 23.98 fps (200 Mbps)
      1920 x 1080p / 24 fps (200 Mbps)
      1920 x 1080p / 25 fps (200 Mbps)
      1920 x 1080p / 29.97 fps (200 Mbps)
      1920 x 1080p / 50 fps (200 Mbps)
      1920 x 1080p / 59.94 fps (200 Mbps)
      High Definition
      MP4
      4096 x 2160p / 24 fps (100 Mbps)
      3840 x 2160p / 23.98 fps (100 Mbps)
      3840 x 2160p / 24 fps (100 Mbps)
      3840 x 2160p / 25 fps (100 Mbps)
      3840 x 2160p / 29.97 fps (100 Mbps)
      1920 x 1080p / 23.98 fps (200 Mbps)
      1920 x 1080p / 24 fps (200 Mbps)
      1920 x 1080p / 25 fps (200 Mbps)
      1920 x 1080p / 29.97 fps (200 Mbps)
      1920 x 1080p / 50 fps (200 Mbps)
      1920 x 1080p / 59.94 fps (200 Mbps)
      1920 x 1080p / 25 fps (20 Mbps)
      1920 x 1080p / 29.97 fps (20 Mbps)
      1920 x 1080p / 50 fps (28 Mbps)
      1920 x 1080p / 59.94 fps (28 Mbps)
      1280 x 720p / 25 fps (10 Mbps)
      1280 x 720p / 29.97 fps (10 Mbps)
      Standard Definition
      MP4
      640 x 480p / 25 fps (4 Mbps)
      640 x 480p / 29.97 fps (4 Mbps)
      High Definition
      AVCHD
      1920 x 1080p / 23.98 fps (24 Mbps)
      1920 x 1080p / 50 fps (28 Mbps)
      1920 x 1080p / 59.94 fps (28 Mbps)
      1920 x 1080i / 50 fps (24 Mbps)
      1920 x 1080i / 50 fps (17 Mbps)
      1920 x 1080i / 59.94 fps (24 Mbps)
      1920 x 1080i / 59.94 fps (17 Mbps)
      Aspect Ratio 4:3, 16:9
      Video Clip Length Up to 220 Min
      Audio Recording With Video, Stereo
      Focus Control
      Focus Type Auto & Manual
      Focus Mode Continuous-servo AF (C), Flexible (AFF), Manual Focus (M), Single-servo AF (S)
      Viewfinder/Display
      Viewfinder Type Electronic
      Viewfinder Pixel Count 2,359,000
      Viewfinder Eye Point 21.0 mm
      Viewfinder Coverage 100%
      Viewfinder Magnification Approx. 1.34x
      Diopter Adjustment - 4.0 to +4.0 m
      Display Screen 3" Touchscreen Swivel  OLED (1,036,000)
      Screen Coverage 100%
      Exposure Control
      ISO Sensitivity 200-25600 (Extended Mode: 100-25600)
      Shutter 60 - 1/8000
      60 minute in  Bulb Mode
      1/24 - 1/16000  in  Movie Mode
      Remote Control DMW-RSL1 (Optional)
      Metering Method Center-weighted average metering, Multiple, Spot metering
      Exposure Modes Modes: Aperture Priority, Manual, Program, Shutter Priority
      Metering Range: EV 0.0 - EV 18.0
      White Balance Modes Auto, Cloudy, Color Temperature, Daylight, Flash, Incandescent, Shade, White Set
      Continuous Shooting Up to 40 fps  frames
      Flash
      Flash Modes Auto
      Auto/Red-eye Reduction
      Forced On
      Forced On/Red-eye Reduction
      Off
      Slow Sync
      Slow Sync/Red-eye Reduction
      Built-in Flash Yes
      Max Sync Speed 1 / 250 seconds
      Flash Compensation -3 EV to +3 EV (in 1/3 EV steps)
      Dedicated Flash System TTL
      External Flash Connection Hot Shoe
      Performance
      Self Timer 10 seconds, 2 seconds
      Number of Shots: 1-3
      Interval Recording Yes
      Connectivity 1/8" Headphone, 1/8" Microphone, AV Output, HDMI D (Micro), USB 2.0, Wired Remote Port
      Wi-Fi Capable Yes
      Software System Requirements Windows: XP, Vista, 7, 8
      Mac: OS X 10.5 or later
      Power
      Battery 1x Rechargeable Lithium-ion Battery Pack, 7.2 VDC, 1860 mAh
      Operating/Storage Temperature Operating
      32 to 104°F (0 to 40°C)
      Humidity: 10 - 80%
      Physical
      Dimensions (WxHxD) 5.2 x 3.7 x 3.3" / 132.9 x 93.4 x 83.9 mm
      Weight 19.75 oz / 560 g with SD card and Battery
      Packaging Info
      Box Dimensions (LxWxH) 7.7 x 5.7 x 5.7"
