User manual for the Iluminar VB164 Vision Series Day/Night Indoor/Outdoor VB164-5-24

The user manual for the Iluminar VB164 Vision Series Day/Night Indoor/Outdoor VB164-5-24 provides necessary instructions for the proper use of the product Surveillance - Surveillance Video - Wired Analog & HD Cameras.

The gray VB164 Vision Series Day/Night Indoor/Outdoor IR Bullet Camera (NTSC) from Iluminar features a built-in 5 to 50mm varifocal DC iris lens and a 1/3" Sony 960H Ex-view HAD CCD II image sensor. This camera provides clear video even in complete darkness (0 lux) thanks to the integrated IR illuminators that are effective up to a distance of 164' (50m).
If you own a Iluminar wired analog & hd cameras and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Iluminar VB164 Vision Series Day/Night Indoor/Outdoor VB164-5-24 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Iluminar VB164 Vision Series Day/Night Indoor/Outdoor VB164-5-24:
Image Sensor 1/3" Sony 960H Ex-view HAD CCD II
Lens 5 to 50 mm varifocal DC iris
Effective Picture Elements 976 x 494
Horizontal Resolution Color: 650 TVL
B&W: 700 TVL
Day/Night True Day & Night (ICR)
Minimum Illumination 0 lux with IR on
IR Illuminators 850 nm wavelength
Illumination Distance Automatic IR On / Off: 164' (50 m)
MTBF IR LEDs: 20,000 hours
Management IR: Intelligent IR Image Compensation
Synchronization System Internal
Format Transfer Format:
525 lines
2:1 interlaced
Video Output 1.0 Vpp Composite
Shutter Speed 1/60 to 1/100,000 sec
S/N Ratio >52 dB (AGC Off)
Gamma Correction r=0.45
Smear Smear Effect: 0.005%
Camera Title On / Off
Shutter Auto / Manual
AGC (Automatic Gain Control) Auto / Manual
White Balance ATW / Push / Push Lock / User 1, 2 / Anti CR / Manual
Picture Adjustment Mirror (On / Off), Brightness, Contrast, Sharpness, HUE, Gain
Privacy On / Off (4 zone setting available)
Noise Reduction NR Mode / Y Level / C Level
Digital Noise Reduction (DNR) 2D
Connections BNC video cable & power cable
Set-Up Easy-to-play OSD button on the unit
Extra video out
Remote Access RS-485 interface (Pelco-D Protocol)
Language English / German / French / Russian / Spanish / Portuguese / Japanese
Construction Aluminum
Input Voltage 12 VDC / 24 VAC dual power (±20%)
Current IR Off / On:
12 VDC: 120 to 520 mA
24 VAC: 90 to 400 mA
Certifications IP67 rated
CE listed
RoHS certified
Operating Temperature 14 to 122˚F (-10 to 50˚C)
Humidity Within 90% RH
Dimensions (W x H x D) 3.8 x 3.6 x 10.2" (97.0 x 91.0 x 257.0 mm)
Weight 4.85 lb (2.20 kg)
Packaging Info
Package Weight 6.0 lb
Box Dimensions (LxWxH) 17.0 x 8.0 x 8.0"
The user manual for the Iluminar VB164 Vision Series Day/Night Indoor/Outdoor VB164-5-24 can be downloaded in .pdf format if it did not come with your new wired analog & hd cameras, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Iluminar users keep a unique electronic library for Iluminar wired analog & hd camerass, where you can use our link to download the user manual for the Iluminar VB164 Vision Series Day/Night Indoor/Outdoor VB164-5-24.

The user manual lists all of the functions of the Iluminar VB164 Vision Series Day/Night Indoor/Outdoor VB164-5-24, all the basic and advanced features and tells you how to use the wired analog & hd cameras. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Iluminar service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Iluminar VB164 Vision Series Day/Night Indoor/Outdoor VB164-5-24. User manuals are also available on the Iluminar website under Surveillance - Surveillance Video - Wired Analog & HD Cameras.
