User manual Kowa LMZ111AM 1/3" Zoom DC Auto Iris Lens LMZ111AMPDC

Operating instructions and pdf manual for use - Kowa LMZ111AM 1/3" Zoom DC Auto Iris Lens LMZ111AMPDC User manual, User manual Kowa LMZ111AM 1/3" Zoom DC Auto Iris Lens LMZ111AMPDC, Kowa, LMZ111AM, 1/3, Zoom, DC, Auto, Iris, Lens, LMZ111AMPDC,


User manual for Kowa LMZ111AM 1/3" Zoom DC Auto Iris Lens LMZ111AMPDC

Kowa LMZ111AM 1/3
  • Manufacturer: Kowa
  • Basic description and contents of package
  • Product classification: Surveillance - Surveillance Video - Lenses - Lenses
  • Safety instructions
  • Startup and operation of the lenses
  • Tips for setting up your Kowa
  • Settings and expert assistance
  • Contact Kowa service
  • Troubleshooting
  • Warranty information
  • Price: 553 USD
We recommend checking out our discussion threads on the Kowa LMZ111AM 1/3" Zoom DC Auto Iris Lens LMZ111AMPDC, which address similar problems with connecting and setting up Lenses Kowa.



User manual for the Kowa LMZ111AM 1/3" Zoom DC Auto Iris Lens LMZ111AMPDC

The user manual for the Kowa LMZ111AM 1/3" Zoom DC Auto Iris Lens LMZ111AMPDC provides necessary instructions for the proper use of the product Surveillance - Surveillance Video - Lenses - Lenses.

The Kowa LMZ111AM 1/3" Zoom DC Auto Iris Lens (6 to 60mm, Preset Version) features a 3-cam design, which is also incorporated in Kowa’s varifocal and zoom lenses. This innovative system has solved the problem of de-centering that sometimes occurs in the conventional pole system. Not only is the movement of the lens impaired by de-centering but the optical performance suffers as well. The 3-cam design also reduces internal reflection. As a result, the image obtained by this design is sharp. With the 3-cam design, the customer can expect higher optical performance and a longer service life.
If you own a Kowa lenses and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Kowa LMZ111AM 1/3" Zoom DC Auto Iris Lens LMZ111AMPDC in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Kowa LMZ111AM 1/3" Zoom DC Auto Iris Lens LMZ111AMPDC:
Specifications
    Sensor Size 1/3" for B&W and color camera
    Focal Length 6 to 60 mm
    Iris Range F1.6 to 360
    Image Size Ø6 4.8 x 3.6
    Back Focal Length 0.37" (9.55 mm)
    Flange Focal Length 0.49" (12.5 mm)
    Field Angle Diameter: 54.3° (wide), 5.8° (tele)
    Horizontal: 44.2° (wide), 4.7° (tele)
    Vertical: 33.5° (wide), 3.5° (tele)
    Field of View at M.O.D Diameter: 1,145.6 mm (wide), 116.4 mm (tele)
    Horizontal: 914.6 mm (wide), 93 mm (tele)
    Vertical: 682 mm (wide), 69.7 mm (tele)
    Distortion Wide: -0.7%
    Tele: -0.05%
    Lens Construction 11 groups, 14 elements
    Aperture Front: ø46
    Rear: ø10.6
    Exit Pupil Position -4.44" (-113 mm) format
    Coil Driving
    Resistance: 190 ohms (68°F / 20°C) / Color: Red (4-pin), black (3-pin)
    Brake
    Resistance: 1150 ohms (68°F / 20°C) / Color: Yellow (2-pin), green (1-pin)
    Driving Voltage Open: <4 v
    Close: >0 V without closing spring
    Weight 18.69 oz (530 g)
    Packaging Info
    Package Weight 3.0 lb
    Box Dimensions (LxWxH) 7.0 x 5.25 x 4.0"
    The user manual for the Kowa LMZ111AM 1/3" Zoom DC Auto Iris Lens LMZ111AMPDC can be downloaded in .pdf format if it did not come with your new lenses, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Kowa users keep a unique electronic library for Kowa lensess, where you can use our link to download the user manual for the Kowa LMZ111AM 1/3" Zoom DC Auto Iris Lens LMZ111AMPDC.

    The user manual lists all of the functions of the Kowa LMZ111AM 1/3" Zoom DC Auto Iris Lens LMZ111AMPDC, all the basic and advanced features and tells you how to use the lenses. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Kowa service.

    If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Kowa LMZ111AM 1/3" Zoom DC Auto Iris Lens LMZ111AMPDC. User manuals are also available on the Kowa website under Surveillance - Surveillance Video - Lenses - Lenses.
