User manual for the Kramer VP-1608 16x8 RGBHV/Audio Matrix Switcher VP-1608

The user manual for the Kramer VP-1608 16x8 RGBHV/Audio Matrix Switcher VP-1608 provides necessary instructions for the proper use of the product Professional Video - Signal Processing & Distribution - Routers & Switchers.

The VP-1608 16x8 RGBHV/Audio Matrix Switcher from Kramer is a high-performance matrix switcher for use with RGBHV and balanced audio signals. This solution can route any or all inputs to any or all outputs simultaneously, making it an ideal solution for presentation and production applications.

By employing delayed switching and changing sync ahead of video, this unit ensures nearly glitch-free switching of non-genlocked sources. A take button allows for the execution of multiple switches at once, audio breakaway switching is also a standard feature, and memory locations store multiple switch presets to be recalled and executed as needed.

Control of the system is managed through the unit's front panel (which features a control lockout security feature), or the included Windows-based control software. The system comes ready to manage up to 400MHz of bandwidth. It also features a standard 19" width and 3U height to accommodate easy rack placement.
If you own a Kramer routers & switchers and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Kramer VP-1608 16x8 RGBHV/Audio Matrix Switcher VP-1608 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Kramer VP-1608 16x8 RGBHV/Audio Matrix Switcher VP-1608:
Input 16 x 3 video (RGB) 0.7Vpp/75 Ω on BNC connectors
16 x 2 H&V, TTL level on BNC connectors
16 balanced audio stereo on detachable terminal blocks
Output 8 x 3 video (RGB) 0.7Vpp/75Ω on BNC connectors
8 x 2 H&V, TTL level/75Ω an BNC connectors
8 balanced audio stereo on detachable terminal blocks
Video Bandwidth 400MHz
Audio Bandwidth 30kHz
Video Signal-to-Noise Ratio 71.7dB
Audio Signal-to-Noise Ratio 74.5dB unweighted (1Vpp)
Video Crosstalk -62.5dB @ 5MHz
Control Front panel switches and IR, RS-232 and RS- 485 may also control input and output audio levels
Audio Control Mute, - 46dB to +10dB Gain Range, via RS-232, RS 485, IR
Audio THD 0.028% (1kHz)
Power Source 230 VAC, 50/60 Hz (115 VAC, USA), 28VA
Dimensions (WxD) 19 x 7"
3U rack height
Weight 5.5 lbs (12.2kg)
Packaging Info
Package Weight 20.05 lb
Box Dimensions (LxWxH) 21.5 x 12.0 x 8.0"
The user manual for the Kramer VP-1608 16x8 RGBHV/Audio Matrix Switcher VP-1608 can be downloaded in .pdf format if it did not come with your new routers & switchers, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Kramer users keep a unique electronic library for Kramer routers & switcherss, where you can use our link to download the user manual for the Kramer VP-1608 16x8 RGBHV/Audio Matrix Switcher VP-1608.

The user manual lists all of the functions of the Kramer VP-1608 16x8 RGBHV/Audio Matrix Switcher VP-1608, all the basic and advanced features and tells you how to use the routers & switchers. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Kramer service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Kramer VP-1608 16x8 RGBHV/Audio Matrix Switcher VP-1608. User manuals are also available on the Kramer website under Professional Video - Signal Processing & Distribution - Routers & Switchers.
