User manual for the M-Audio BX8 Carbon Monitor - Two-Way Studio Monitor BX8CARBONXUS
The user manual for the M-Audio BX8 Carbon Monitor - Two-Way Studio Monitor BX8CARBONXUS provides
necessary instructions for the proper use of the product Pro Audio - Recording - Studio Monitors.
The M-Audio BX8 Carbon Monitor - Two-Way Studio Monitor with 8" Woofer can be used for home studio recording and mixing. The monitor utilizes a 70W powered 6" Kevlar woven woofer and a 60W powered 1.25" silk dome tweeter to deliver a frequency response of 38 to 22,000 Hz with a signal to noise ratio of 100 dB.
The monitor's class A/B amplifier helps provide a flat frequency response with low noise to enable you to mix a wide variety of modern music styles. The tweeter output is sent through a waveguide to improve stereo imaging and pinhole mounted LED placement cues can help you place the monitor in relation to the optimal listening position.
A series of acoustic control calibration switches on the back of the unit allow the response of the monitor to be adjusted to different acoustic environments such as bedroom home studios or professionally treated facilities. Both XLR and TRS inputs are available for connection to your audio interface.
|
If you own a M-Audio studio monitors and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the M-Audio BX8 Carbon Monitor - Two-Way Studio Monitor BX8CARBONXUS in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the M-Audio BX8 Carbon Monitor - Two-Way Studio Monitor BX8CARBONXUS:
| Type | 2-way near-field studio reference monitor | | LF Driver Size | 8" (203 mm) Kevlar curved cone with high temperature magnetically shielded voice coil and damped rubber surround | | HF Driver Size | 1.25" (32 mm) magnetically shielded natural silk dome | | Frequency Response | 38 to 22,000 Hz | | Crossover Frequency | 2,200 Hz | | LF Amplifier | 70 W | | HF Amplifier | 60 W | | Signal to Noise Ratio | >100 dB typical A-weighted | | Input Connectors | 1x XLR balanced input
1x TRS balanced/unbalanced input connector | | Polarity | Positive signal at + input produce outward LF cone displacement | | Input Impedance | 20 kΩ balanced
10 kΩ unbalanced | | Input Sensitivity | 85 mV pink noise produces 90 dBA output SPL at 1 meter with volume control at maximum | | Protection | RF interference
Output current limiting
Over temperature
Turn on/off transient
Subsonic filter
External mains fuse | | Indicators | Power on.off indicator on rear panel | | Power Requirements | Factory-programmed for 115 V ~50/60 Hz, 230 V ~50/60 Hz, or 100 V ~50/60 Hz | | Cabinet | Vinyl-laminated high-acoustic-efficiency MDF | | Dimensions (H x W x D) | 15 x 10 x 12" (381 x 254 x 305 mm) | | Weight | 26.4 lb (12 kg) | | Package Weight | 26.0 lb | | Box Dimensions (LxWxH) | 20.0 x 16.0 x 14.0" | |
