User manual for the Marshall Electronics V-R44P Quad 4" LCD Monitor Unit V-R44P

The user manual for the Marshall Electronics V-R44P Quad 4" LCD Monitor Unit V-R44P provides necessary instructions for the proper use of the product Professional Video - Monitors - Production Monitors.

The Marshall V-R44P is a 4 x 4 inch monitor unit integrated into a rack mountable package. Extremely space efficient, the monitors take up only 2 rack units in height.
If you own a Marshall Electronics production monitors and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Marshall Electronics V-R44P Quad 4" LCD Monitor Unit V-R44P in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
User manual for Marshall Electronics V-R44P Quad 4Download user manual for Marshall Electronics V-R44P Quad 4" LCD Monitor Unit V-R44P
(PDF file, 0.27 MB)
Additional parameters of the Marshall Electronics V-R44P Quad 4" LCD Monitor Unit V-R44P:
Specifications
    Application Rack Mount, Control Room, Director's Location
    LCD Size 4 inch diagonal
    Video System NTSC and PAL
    Picture Elements 480 horizontal x 234 vertical dots
    Input and Output Connectors Composite Video- BNC (x 1 input, 1 output each monitor)
    Power- Coaxial (x 1 input only)
    Tally- 15-Pin (x 1)
    Picture Controls Contrast
    Color
    Brightness
    Tint
    Remote Control None
    Power Requirements 12 Volts DC
    Power Consumption 1.1 A
    Dimensions (WxHxD) 19.125 x 3.43 x 1.90 inches
    Weight 3.5 lbs.
    Packaging Info
    Package Weight 6.5 lb
    Box Dimensions (LxWxH) 24.5 x 9.0 x 9.0"
    The user manual for the Marshall Electronics V-R44P Quad 4" LCD Monitor Unit V-R44P can be downloaded in .pdf format if it did not come with your new production monitors, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Marshall Electronics users keep a unique electronic library for Marshall Electronics production monitorss, where you can use our link to download the user manual for the Marshall Electronics V-R44P Quad 4" LCD Monitor Unit V-R44P.

    The user manual lists all of the functions of the Marshall Electronics V-R44P Quad 4" LCD Monitor Unit V-R44P, all the basic and advanced features and tells you how to use the production monitors. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Marshall Electronics service.

    If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Marshall Electronics V-R44P Quad 4" LCD Monitor Unit V-R44P. User manuals are also available on the Marshall Electronics website under Professional Video - Monitors - Production Monitors.
