User manual Metric Halo ULN-2 2d2J - FireWire Digital Audio 000-50006-2-JEN

Operating instructions and pdf manual for use - Metric Halo ULN-2 2d2J - FireWire Digital Audio 000-50006-2-JEN User manual, User manual Metric Halo ULN-2 2d2J - FireWire Digital Audio 000-50006-2-JEN, Metric, Halo, ULN-2, 2d2J, FireWire, Digital,


User manual for Metric Halo ULN-2 2d2J - FireWire Digital Audio 000-50006-2-JEN

Metric Halo ULN-2 2d2J - FireWire Digital Audio 000-50006-2-JEN
  • Manufacturer: Metric Halo
  • Basic description and contents of package
  • Product classification: Pro Audio - Computer Audio - Audio Interfaces & Systems
  • Safety instructions
  • Startup and operation of the audio interfaces & systems
  • Tips for setting up your Metric Halo
  • Settings and expert assistance
  • Contact Metric Halo service
  • Troubleshooting
  • Warranty information
We recommend checking out our discussion threads on the Metric Halo ULN-2 2d2J - FireWire Digital Audio 000-50006-2-JEN, which address similar problems with connecting and setting up Audio Interfaces & Systems Metric Halo.



User manual for the Metric Halo ULN-2 2d2J - FireWire Digital Audio 000-50006-2-JEN

The user manual for the Metric Halo ULN-2 2d2J - FireWire Digital Audio 000-50006-2-JEN provides necessary instructions for the proper use of the product Pro Audio - Computer Audio - Audio Interfaces & Systems.

The ULN-2 2d from Metric Halo is a portable, high quality FireWire based, multi-format audio converter and interface. Housed in a single space rack-mount chassis, the unit provides 12 inputs and 14 outputs of simultaneous I/O, while having the ability to be powered entirely from the FireWire bus of a laptop computer, or from an appropriate DC power source.
If you own a Metric Halo audio interfaces & systems and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Metric Halo ULN-2 2d2J - FireWire Digital Audio 000-50006-2-JEN in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
User manual for Metric Halo ULN-2 2d2J - FireWire Digital Audio 000-50006-2-JENDownload user manual for Metric Halo ULN-2 2d2J - FireWire Digital Audio 000-50006-2-JEN
(PDF file, 30.97 MB)
Additional parameters of the Metric Halo ULN-2 2d2J - FireWire Digital Audio 000-50006-2-JEN:
Specifications
    Converters 24-bit
    Sample Rates 44.1, 48, 88.2 and 96kHz
    Analog Input 2 x Neutrik Combo (both inputs fitted with Jensen transformers)
    2 x 1/4" TRS phone FX Return
    Analog Output 4 x 1/4" TRS phone
    2 x 1/4" TRS phone FX Send
    Digital Input 1 x XLR AES/EBU
    1 x RCA coaxial S/PDIF
    1 x TOSlink ADAT lightpipe
    Digital Output 1 x XLR AES/EBU
    1 x RCA coaxial S/PDIF
    1 x TOSlink ADAT lightpipe
    MIDI In/Out No
    Sync In/Out 2 x BNC Wordclock I/O
    Headphone Output 1 x 1/4" TRS phone
    THD + N 0.0005% @ 1kHz (+9dBu in @ 6dB gain)
    Dynamic Range A/D: 110dB
    D/A: 120dB
    Frequency Response 8Hz to 50kHz, +/-1.0dB
    Power Requirements FireWire bus
    1 x 4-pin XLR 9 to 30V DC (pin-4 hot) 15W
    1 x 2.1 coaxial 9 to 30V DC, center post positive (+)
    System Requirements PowerPC or Intel Mac
    OS X 10.3.9 or better
    512MB RAM
    Monitor with 1024 x 768 resolution or better
    ASIO 2 compatible host (Cubase, Nuendo, Logic Audio, Digital Performer, Deck or Peak)
    Application that supports ASIO direct monitoring for direct monitoring-based fold-back and overdubbing
    Dimensions (WxDxH) 13.5 x 8.25 x 1.73" (343 x 210 x 44mm)
    Weight 4 lbs (1.8 kg)
    Specialties Sample rate conversion (SRC) on digital I/O
    The user manual for the Metric Halo ULN-2 2d2J - FireWire Digital Audio 000-50006-2-JEN can be downloaded in .pdf format if it did not come with your new audio interfaces & systems, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Metric Halo users keep a unique electronic library for Metric Halo audio interfaces & systemss, where you can use our link to download the user manual for the Metric Halo ULN-2 2d2J - FireWire Digital Audio 000-50006-2-JEN.

    The user manual lists all of the functions of the Metric Halo ULN-2 2d2J - FireWire Digital Audio 000-50006-2-JEN, all the basic and advanced features and tells you how to use the audio interfaces & systems. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Metric Halo service.

    If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Metric Halo ULN-2 2d2J - FireWire Digital Audio 000-50006-2-JEN. User manuals are also available on the Metric Halo website under Pro Audio - Computer Audio - Audio Interfaces & Systems.
