The Midas DL431 Input Splitter Unit is a 6U 19" rack fixed configuration unit which features 24 mic/line inputs. Each input feeds three separate preamps, two with separate gain controls, the third being fixed gain. The two variable-gain preamps feed separate ADCs, which then pass 96 kHz digital audio to the AES50 ports. Four discrete AES50 outputs supply dual-redundant digital audio to AES50 networks, and allow for easy connection to any AES50 device, such as an HD recorder, network bridge, or mixing console.

Two balanced analog splits (sourced post each mic amp) are provided on the rear panel. The third, fixed-gain preamp feeds a transformer-isolated split on the front panel for recording or broadcast applications. The two variable gain preamps are remote controllable from two separate locations, such as front of house and monitor positions. Front panel controls and local monitoring with integral headphone amplifier also make the DL431 usable as a standalone device. Also, its integral dual-redundant power supplies are designed to ensure peace of mind at all times.
If you own a Midas digital mixer accessories and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Midas DL431 Input Splitter Unit DL431 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Midas DL431 Input Splitter Unit DL431:
Specifications
    Inputs 24 x 3-pin XLR balanced
    Phantom Power 48 V with local switch and remote control from XL8 control center
    Gain Control Range 2 x -2.5 to 45 dB analog gain in 2.5dB steps with local and remote control, plus a further +/-20 dB of high-resolution interpolated DSP trim
    Filters 2 x 30 Hz high pass with local defeat switch and remote control from XL8 control center
    Meter 24-off: 7-segment, -18 to 24 dBu
    Meter A/B: meters can be switched to monitor A or B preamplifiers
    A/D Converters 2 x 24-bit, 96k and 128 times over sampling
    Analog Outputs 2 x rear 3-pin XLR balanced, independent
    1 x 3-pin XLR balanced, front-mounted, transformer isolated with fixed gain of -6 dB
    Audio monitor: 1 x 3-pin XLR balanced
    Headphone output: 1 x 1/4" jack
    System Outputs 2 x independent AES50 (24 channels of digital audio) on Ethercon XLR, plus dual-redundant backups of each
    Power 100 - 240 VAC, 50 - 60 Hz
    Operating Temperature 41 - 104°F (5 - 40°C)
    Storage Temperature -4 - 140°F (-20 - 60°C)
    Dimensions (HxD) 6U x 16.1" (6U x 41.0 cm)
    Weight 47.4 lb (21.5 kg)
    Packaging Info
    Package Weight 56.7 lb
    Box Dimensions (LxWxH) 24.0 x 22.0 x 17.0"
