User manual for the Middle Atlantic BGR-RR38 Rail Rack Kit BGR-RR38
The user manual for the Middle Atlantic BGR-RR38 Rail Rack Kit BGR-RR38 provides
necessary instructions for the proper use of the product Pro Audio - Furniture & Racks - Rack Rails.
The Middle Atlantic BGR-RR38 Rail Rack Kit is a next-generation, gangable enclosure that is designed with significant installation and performance benefits. This kit is equipped with 2 pairs of fully adjustable steel rack rail with tapped 10 to 32 mounting holes in universal EIA spacing, black e-coat finish and numbered rack spaces.
If you own a Middle Atlantic rack rails and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Middle Atlantic BGR-RR38 Rail Rack Kit BGR-RR38 in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Middle Atlantic BGR-RR38 Rail Rack Kit BGR-RR38:
| Rack Space || 38 RU |
| Construction || 100" (2540 mm)thick, fully welded steel along rack rail brackets |
310" (7874 mm)thick steel at corners
| Usable Height || 66.63" (1,692.40 mm) |
| Usable Depth || 24.4" (620 mm) |
| Knockouts || Electrical: |
0.5" (12.7 mm)
0.75" (19.05 mm)
1" (25.4 mm)
1 to 0.5" (25.4 to 12.7 mm)
3" (76.2 mm)
1 to 1/2" (25.4 to 12.7 mm) for top cable management plate
0.5" (12.7 mm)
0.625" (15.88 mm)
0.625" (15.88 mm)and 0.5" (12.7 mm) on rear top and bottom
| Ganging Holes || Pre-threaded 5/16"-18 ganging holes |
| Mounts on Studs || Grounding and Bonding: 1/4-20 threaded installed in the top and the bottom |
| Load Capacity || Static Capacity: 12,000 lb (5,443.10 kg) |
UL-listed Load Capacity: 3,000 lb (1,360.77 kg)
Seismic-Certified Capacity: 1,175 lb (3,592 kg)
| Certifications || 1997 UBC; 2001, 2007, & 2010 CBC; 2000, 2003, 2006, & 2009 IBC; ASCE 7-02, ASCE 7-05, ASCE 7-10, and the 2003, 2006, & 2009 editions of NFPA 5000 |
| Dimensions (H x W x D) || 66.63 x 23 x 24.4" (1,692.40 x 584.2 x 619.76 mm) |
| Package Weight || 14.8 lb |
| Box Dimensions (LxWxH) || 68.0 x 5.0 x 3.5" |
