User manual Nikon D750 DSLR Camera Body Video Kit

Operating instructions and pdf manual for use - Nikon D750 DSLR Camera Body Video Kit User manual, User manual Nikon D750 DSLR Camera Body Video Kit, Nikon, D750, DSLR, Camera, Body, Video, Kit, Video


User manual for Nikon D750 DSLR Camera Body Video Kit

Nikon  D750 DSLR Camera Body Video Kit
  • Manufacturer: Nikon
  • Basic description and contents of package
  • Product classification: Photography - Digital Cameras - DSLR Cameras
  • Safety instructions
  • Startup and operation of the dslr cameras
  • Tips for setting up your Nikon
  • Settings and expert assistance
  • Contact Nikon service
  • Troubleshooting
  • Warranty information
Nikon  D750 DSLR Camera Body Video Kit Nikon  D750 DSLR Camera Body Video Kit Nikon  D750 DSLR Camera Body Video Kit Nikon  D750 DSLR Camera Body Video Kit Nikon  D750 DSLR Camera Body Video Kit Nikon  D750 DSLR Camera Body Video Kit Nikon  D750 DSLR Camera Body Video Kit Nikon  D750 DSLR Camera Body Video Kit
Click to enlarge image

We recommend checking out our discussion threads on the Nikon D750 DSLR Camera Body Video Kit, which address similar problems with connecting and setting up DSLR Cameras Nikon.



User manual for the Nikon D750 DSLR Camera Body Video Kit

The user manual for the Nikon D750 DSLR Camera Body Video Kit provides necessary instructions for the proper use of the product Photography - Digital Cameras - DSLR Cameras.

Combining the versatility of the D750 along with a host of video-oriented accessories, the Nikon D750 DSLR Camera Body Video Kit from B&H is designed for improving the already impressive movie recording capabilities from this DSLR. Beyond the camera body itself, this kit also includes a 32GB SDHC memory card, two spare rechargeable lithium-ion batteries, a dual battery charger, a Rode VideoMic Pro Compact Directional On-Camera Microphone, a 9V battery, a shoulder support rig, and a backpack for protecting and carrying the entire kit.

The D750 features a 24.3MP FX-format CMOS sensor and EXPEED 4 image processor to enable a continuous shooting rate of 6.5 fps, an expandable sensitivity range to ISO 51200, and the ability to record Full HD 1080p video at 60 fps. Complementing the imaging assets, a 51-point autofocus system, with 15-cross type points, is well-suited to working with moving subjects in a variety of lighting conditions, and can also be configured to utilize five AF points as a single point in Group AF mode for refined subject tracking. The sleek body design is matched with a 3.2" 1.229m-dot tilting LCD monitor as well as built-in Wi-Fi for wirelessly transferring imagery to a mobile device.
If you own a Nikon dslr cameras and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Nikon D750 DSLR Camera Body Video Kit in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Nikon D750 DSLR Camera Body Video Kit:
Specifications
  • Nikon D750 DSLR Camera (Body Only)
    Imaging
    Lens Mount Nikon F
    Camera Format Full-Frame (1.0x Crop Factor)
    Pixels Actual: 24.93 Megapixel
    Effective: 24.3 Megapixel
    Max Resolution 24.1 MP: 6016 x 4016
    Aspect Ratio 3:2
    Sensor Type / Size CMOS, 35.9 x 24 mm
    File Formats Still Images: JPEG, RAW
    Movies: MOV, MPEG-4 AVC/H.264
    Audio: Linear PCM
    Bit Depth 14-bit
    Dust Reduction System Yes
    Memory Card Type SD
    SDHC
    SDXC
    Focus Control
    Focus Type Auto & Manual
    Focus Mode Automatic (A), Continuous-servo AF (C), Full-time Servo (F), Manual Focus (M), Single-servo AF (S)
    Autofocus Points Phase Detection:51, 15 cross-type
    Viewfinder/Display
    Viewfinder Type Pentaprism
    Viewfinder Eye Point 21.00 mm
    Viewfinder Coverage 100%
    Viewfinder Magnification Approx. 0.7x
    Diopter Adjustment - 3 to +1 m
    Display Screen 3.2" Rear Screen Tilting  LCD (1,229,000)
    Screen Coverage 100%
    Diagonal Angle of View 170.0°
    Exposure Control
    ISO Sensitivity Auto, 100-12800 (Extended Mode: 50-51200)
    Shutter Type: Electronic & Mechanical
    Speed: 30 - 1/4000 second,  Bulb Mode
    Remote Control ML-L3, MC-DC2, WR-T10, WR-R10, WR-R1 (Optional)
    Mirror Lock-Up Yes
    Metering Method 3D Color Matrix Metering, Center-weighted average metering, Spot metering, Highlight Weighted
    Exposure Modes Modes: Aperture Priority, Manual, Programmed Auto, Shutter Priority
    Metering Range: EV 0.0 - EV 20.0
    Compensation: -5 EV to +5 EV (in 1/3 or 1/2 EV steps)
    White Balance Modes Auto, Cloudy, Color Temperature, Direct Sunlight, Flash, Fluorescent, Incandescent, Preset Manual, Shade
    Flash
    Flash Modes Auto
    Auto/Red-eye Reduction
    Fill-in
    Hi-Speed Sync
    Off
    Rear Curtain/Slow Sync
    Rear Sync
    Red-eye Reduction
    Slow Sync
    Slow Sync/Red-eye Reduction
    Built-in Flash Yes
    Maximum Effective Flash Range Not Specified By Manufacturer
    Guide No. 39' (11.89 m) ISO100
    Max Sync Speed 1 / 200 seconds
    Flash Compensation -3 EV to +1 EV (in 1/3, 1/2 or 1 EV steps)
    Dedicated Flash System iTTL
    External Flash Connection Hot Shoe
    AV Recording
    Video Recording Yes, NTSC/PAL
    File Size 1920 x 1080p (Full HD)
    1280 x 720p (HD)
    Aspect Ratio 16:9
    Frame Rate @ 1920 x 1080: 60 fps, 50 fps, 30 fps, 25 fps, 24 fps
    @ 1280 x 720: 60 fps, 50 fps, 30 fps, 25 fps
    Exposure Control Auto
    Manual: Shutter Speed, Aperture, ISO
    ISO Sensitivity Auto, 200 - 12800
    Focus Auto
    Manual
    Continuous Auto
    Video Clip Length 1920 x 1080
    @ 60 fps: 29 min. 59 seconds
    Audio Recording Built-in Mic: With Video, Stereo
    Optional External Mic: With Video, Stereo
    Performance
    Continuous Shooting Up to 6.5 fps
    Self Timer 20 seconds, 10 seconds, 5 seconds, 2 seconds
    Custom: 0-3 seconds at 0.5, 1.0, 2.0, 3.0 second intervals
    Number of Shots: 1-9
    Interval Recording Yes
    Connectivity 1/8" Headphone, 1/8" Microphone, HDMI C (Mini), USB 2.0
    Wi-Fi Capable Yes
    Power
    Battery 1x EN-EL15 Rechargeable Lithium-ion Battery Pack, 7 VDC, 1900 mAh
    AC Power Adapter EH-5b (Optional)
    Operating/Storage Temperature Operating
    32 to 104°F (0 to 40°C)
    Physical
    Dimensions (WxHxD) 5.5 x 4.4 x 3.1" / 140.5 x 113.0 x 78.0 mm
    Weight 1.65 lb / 750 g body only
    Packaging Info
    Box Dimensions (LxWxH) 8.6 x 7.0 x 5.7"
  • SanDisk 32GB Extreme Pro UHS-I SDHC U3 Memory Card (Class 10)
    Card Type SDHC
    Storage Capacity 32 GB
    Speed Class 10
    UHS Speed Class U3
    Speed (X-rating) 633x
    Bus Interface Speed UHS Class I
    Data Transfer Read Speed 95 MB/s Maximum
    Write Speed 90 MB/s Maximum
    Durability Shockproof, Temperature Extremes, Waterproof, X-Ray Proof
    Insertion/Removal Cycles Not Specified By Manufacturer
    Operating Temperature -13 to 185°F/ -25 to 85°C
    Storage Temperature -40 to 185°F/ -40 to 85°C
    Error Correction Yes
    Built-in Write-Protect Switch Yes
    Wireless Capability None
    File System FAT32
    RoHS Compliant Not Specified By Manufacturer
    Packaging Info
    Box Dimensions (LxWxH) 7.0 x 4.5 x 2.0"
  • 2 x Watson EN-EL15 Lithium-Ion Battery Pack (7.0V, 2000mAh)
    Chemistry Lithium-ion
    Capacity 2000 mAh
    Output Voltage 7.0 V
    Dimensions 2.2 x 1.6 x 0.8" / 5.6 x 4.1 x 2 cm
    Weight 2.8 oz / 79.4 g
    Packaging Info
    Box Dimensions (LxWxH) 5.5 x 3.2 x 0.5"
  • Watson Duo LCD Charger with 2 EN-EL15 Battery Plates
    Input Power 100-240 VAC, 50 / 60 Hz
    12 / 24 VDC, 2.0 A
    Output Power 1.2-8.4 VDC, 2.0 A (max.)
    USB 2.0 port: 5.0 VDC, 2.0 A (max.)
    Charging Time 2-6 hr
    Interface USB 2.0 port for charging another device
    Operating Temperature 32 to 104°F (0 to 40°C)
    Storage Temperature -4 to 140°F (-20 to 60°C)
    Dimensions Charger: 4.9 x 4.5 x 1.75" (12.4 x 11.4 x 4.45 cm)
    Cord length: 4.7' (1.4 m)
    Weight 7.7 oz (218 g)
    Packaging Info
    Box Dimensions (LxWxH) 10.6 x 6.4 x 2.5"
  • Ruggard Outrigger 45 Backpack
    Material Exterior: 600D polyester
    Lining: 200D polyester
    Type of Closure Zippers
    Tripod Holder Yes - two bottom straps
    Waist Belt Yes
    Carrying/Transport Options Adjustable backpack straps
    Top grab handle
    Sternum strap
    Interior Dimensions 10.0 x 14.5 x 5.0" (25.4 x 36.8 x 12.7 cm)
    Exterior Dimensions 11.5 x 15.5 x 7.5" (29.2 x 39.4 x 19.1 cm)
    Weight 2.4 lb (1.1 kg)
    Packaging Info
    Box Dimensions (LxWxH) 17.0 x 13.0 x 9.0"
  • Rode VideoMic Pro Compact Directional On-Camera Microphone
    Operating Principle Line Gradient
    Transducer Condenser
    Diaphragm 0.50" (12.70 mm)
    Polar Pattern Supercardioid
    Frequency Range 40 Hz to 20 kHz
    Equivalent Noise Level 20 dB A-Weighted
    Maximum SPL 134 dB SPL 1%
    Impedance 200 ohms
    Sensitivity -32 dB, re: 1 V/Pa
    Power Requirements 9 V Battery
    Low-Cut Filter Yes @ 80 Hz
    Output Connectors 3.5mm TRS
    General
    Length 3.94" (100 mm)
    Diameter 2.95" (75 mm)
    Weight 3.00 oz (85 g)
    Packaging Info
    Box Dimensions (LxWxH) 8.2 x 6.2 x 2.4"
  • Revo SR-1000 Shoulder Support Rig
    Capacity 5.5 lb (2.5 kg)
    Dimensions 19 x 10" (48.26 x 25.4 cm)
    Weight 2.25 lb (1.02 kg)
    Packaging Info
    Box Dimensions (LxWxH) 12.7 x 9.6 x 3.6"
  • Duracell 9V Alkaline Battery (Coppertop)
    Chemistry Alkaline
    Output Voltage 9V
    Operating Voltage 9.6 - 4.8V
    Impedance 1700 m-ohm@1kHz
    Storage Temperature -4 to 95°F (-20 to 35°C)
    Operating Temperature Range -1 to 130°F (-20 to 54°C)
    Terminals Miniature snap
    Volume Typical: 1.4 cu in (22.8 cu centimeter)
    Dimensions 1.9 x 0.7 x 1.0" (48.5 x 17.5 x 26.5 mm)
    Weight 1.6 oz (45.4 g)
    Packaging Info
    Box Dimensions (LxWxH) 4.5 x 3.7 x 0.5"
The user manual for the Nikon D750 DSLR Camera Body Video Kit can be downloaded in .pdf format if it did not come with your new dslr cameras, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Nikon users keep a unique electronic library for Nikon dslr camerass, where you can use our link to download the user manual for the Nikon D750 DSLR Camera Body Video Kit.

The user manual lists all of the functions of the Nikon D750 DSLR Camera Body Video Kit, all the basic and advanced features and tells you how to use the dslr cameras. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Nikon service.
