User manual for the Panasonic PT-LZ370U 3LCD Projector PT-LZ370U
The user manual for the Panasonic PT-LZ370U 3LCD Projector PT-LZ370U provides
necessary instructions for the proper use of the product A/V Presentation - Projectors - Home Theater Projectors.
The Panasonic PT-LZ370U 3LCD Projector is flexible and powerful enough to thrive in a variety of working conditions. With a brightness of 3000 lumens and a contrast ratio of 10,000:1 with Dynamic Iris Pro, the PT-LZ370U uses a single lamp and efficient focusing reflector to minimize consumption to only 350W.
|
If you own a Panasonic home theater projectors and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Panasonic PT-LZ370U 3LCD Projector PT-LZ370U in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the Panasonic PT-LZ370U 3LCD Projector PT-LZ370U:
| Projector Display System | 0.74" diagonal (16:9 aspect ratio)
Display method: Transparent LCD panel (x 3, R/G/B) | | Lumens | 3000 lumens | | System | NTSC / NTSC4.43 / PAL-M / PAL60 / PAL/ PAL-N / SECAM | | Recommended Projection Size | 40-300" (1-7.6 m) | | Throw Distance | 3.7-57.3" (1.1-17.5 m) | | Native Resolution | 1920 x 1080
Uniformity: 85% | | Pixels | 2,073,600 (1920 x 1080) x 3, total of 6,220,800 pixels | | Colors | Full color (1,073,741,824 colors) | | Lens | F=2-3.4, f=21.5-43mm | | Focus/Zoom Adjusting | Manual zoom (1-2x), manual focus lenses | | Lens Shift | Optical axis shift: Vertical: ±65%; Horizontal: ±26% | | Scanning Frequency | RGB: fH: 15.6-91.1 kHz, fV: 24.0-85.1 Hz, dot clock: 162.0 MHz or lower
HDMI: 525p (480p), 625p (576p), 750 (720)/60p, 750 (720)/50p, 1125 (1080)/60i, 1125 (1080)/50i, 1125 (1080)/60p, 1125 (1080)/50p, 1125 (1080)/24p
Dot clock: 25.2-162.0 MHz, displayable resolution: VGA-UXGA (non-interlace)
YPBPR (YCBCR): 525i (480i): fH 15.75 kHz; fV 60.0 Hz, 625i (576i): fH 15.63 kHz; fV 50.0 Hz, 525p (480p): fH 31.5 kHz; fV 60.0 Hz, 625p (576p): fH 31.25 kHz; fV 50.0 Hz, 750 (720)/60p: fH 45.0 kHz; fV 60.0 Hz, 750 (720)/50p: fH 37.5 kHz; fV 50.0 Hz, 1125 (1080)/60i: fH 33.75 kHz; fV 60.0 Hz, 1125 (1080)/50i: fH 28.13 kHz; fV 50.0 Hz, 1125 (1080)/24p: fH 27.0 kHz; fV 24.0 Hz, 1125 (1080)/60p: fH 67.5 kHz; fV 60.0 Hz, 1125 (1080)/50p: fH 56.25 kHz; fV 50.0 Hz
Video / S-video: fH: 15.75 kHz, fV: 60 Hz [NTSC / NTSC4.43 / PAL-M / PAL60]
fH: 15.63 kHz, fV: 50 Hz [PAL / PAL-N / SECAM] | | Lamp (Bulb) | 280W UHM lamp | | Aspect Ratio | 16:9 | | Contrast Ratio | 10,000:1 (All white / All black, with Dynamic Iris Pro on) | | Projection Tilt Option | Yes | | Rear Screen Projection | Yes | | Ceiling Mountable | Yes | | Keystone Correction | Vertical: Approx. ±30° | | Inputs/Outputs | HDMI: HDMI 19-pin x 2, Deep color, Compatible with HDCP
Computer (RGB) in: D-sub HD 15-pin (female) x 1
Component in: RCA pin (YPBPR/YCBCR) x 3
Video in: RCA pin z 1, 1.0 Vp-p, 75 ohms
S-video in: Mini DIN 4-pin x 1
Audio in: M3 (L / R) x 1
Audio out: M3 (L / R) x 1 (Monitor out: 0-2.0 Vrms, Variable)
Serial in: D-sub 9-pin x 1 for external control (RS-232C compliant)
LAN: RJ-45 x 1, for network connection, 100Base-TX/10Base-T, compliant with PJLink | | Fan Noise | 35 dB (Normal), 29 dB (Eco) | | Remote Control | 49' (15 m) long range wireless remote control | | Power Requirements | 100-240 VAC, 50/60Hz | | Power Consumption | 350W (0.08W in standby mode) | | Material | Molded plastic (PC+ABS) | | Operating Temperature | 32-104°F (0-40°C) | | Humidity | 20-80% (No condensation) | | Languages | English, French, German, Spanish, Italian, Chinese, Korean, Russian, Swedish, Danish, Norwegian, Polish, Czech, Hungarian, Portuguese, Thai, Japanese | | Dimensions (WxHxD) | 18.5 x 5.9 x 14.9" (469.9 x 149.9 x 378.5mm) | | Weight | 19 lb. (8.6kg) | | Package Weight | 29.0 lb | | Box Dimensions (LxWxH) | 19.0 x 15.0 x 6.0" | |
The user manual for the Panasonic PT-LZ370U 3LCD Projector PT-LZ370U can be downloaded in .pdf
format if it did not come with your new home theater projectors, although the seller is
required to supply one. It is also quite common that customers throw out
the user manual with the box, or put the CD away somewhere and then can’t find it.
That’s why we and other Panasonic users keep a unique electronic library
for Panasonic home theater projectorss,
where you can use our link to download the user manual for the Panasonic PT-LZ370U 3LCD Projector PT-LZ370U.
The user manual lists all of the functions of the Panasonic PT-LZ370U 3LCD Projector PT-LZ370U,
all the basic and advanced features and tells you how to use the home theater projectors.
The manual also provides troubleshooting for common problems. Even greater
detail is provided by the service manual, which is not typically shipped with the product,
but which can often be downloaded from Panasonic service.
If you want to help expand our database, you can upload a link to this website
to download a user manual or service manual, ideally in .pdf format. These pages
are created by you – users of the Panasonic PT-LZ370U 3LCD Projector PT-LZ370U. User manuals are also
available on the Panasonic website under A/V Presentation - Projectors - Home Theater Projectors.
