The user manual for the Phoenix Audio MT454-PSTN Octopus USB Base Unit MT454-PSTN provides
necessary instructions for the proper use of the product A/V Presentation - Audio Conferencing.
The MT454-PSTN Octopus USB Base Unit with Analog Telephone Interface from Phoenix Audio is an audio conferencing mixer with four XLR mic/line inputs. It can be used in applications for conference rooms, classrooms, training rooms, courtrooms, depositions, and more.
|
If you own a Phoenix Audio audio conferencing and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Phoenix Audio MT454-PSTN Octopus USB Base Unit MT454-PSTN in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the Phoenix Audio MT454-PSTN Octopus USB Base Unit MT454-PSTN:
| Designation | Mic (mixer inputs), auxiliary, sound reinforcement | | Number of Inputs | 4x | | Phantom Power | User Selectable: 3 V, 24 V, or none (for line inputs) | | Connectors | XLR | | Input Impedance | Phantom 3 V: 2 kOhms
Phantom 24 V: 590 ohms
No Phantom: 2 kOhms | | Maximum Input Level | 1.8 V/gain | | Gain | User Selectable: 0 to 42 db in 6 dB steps | | Frequency Response | 20 Hz to 16 kHz | | Connectors | RCA
XLR (the XLR is re-assigned as link-up when the unit is configured as slave) | | Level | Line or mic level (user selectable) | | Line Level | 1.8 V pp max | | Mic Level Output | 90 mV pp max | | Link-Up Level | Line (1.8 V pp fixed) | | Impedance | 25 ohms | | Frequency Response | 20 Hz to 16 kHz | | Connector | RCA | | Impedance | 100 kOhms | | Level | 1.8 V pp | | Connector | N/A | | Impedance | N/A | | Level | N/A | | Com Ports | RS232 | | Power | 5V, 200 mAmp (through the USB connector) | | Dimensions (L x W x D) | 8 x 16.5 x 1.75" (20.3 x 41.9 x 4.4 cm) | | Weight | 5.65 lb (2.6 kg) | |
