User manual SeaSonic Electronics Platinum Series PLATINUM-760 SS-760XP2

Operating instructions and pdf manual for use - SeaSonic Electronics Platinum Series PLATINUM-760 SS-760XP2 User manual, User manual SeaSonic Electronics Platinum Series PLATINUM-760 SS-760XP2, SeaSonic, Electronics, Platinum, Series, PLATINUM-760,


User manual for SeaSonic Electronics Platinum Series PLATINUM-760 SS-760XP2

Overall rating 5.0
Overall Rating: 5.0

100% of respondents would recommend this to a friend.
SeaSonic Electronics Platinum Series PLATINUM-760 SS-760XP2
  • Manufacturer: SeaSonic Electronics
  • Basic description and contents of package
  • Product classification: Computers & Solutions - Computer Components - Power Supplies
  • Safety instructions
  • Startup and operation of the power supplies
  • Tips for setting up your SeaSonic Electronics
  • Settings and expert assistance
  • Contact SeaSonic Electronics service
  • Troubleshooting
  • Warranty information
  • Price: 160 USD
SeaSonic Electronics Platinum Series PLATINUM-760 SS-760XP2 SeaSonic Electronics Platinum Series PLATINUM-760 SS-760XP2 SeaSonic Electronics Platinum Series PLATINUM-760 SS-760XP2 SeaSonic Electronics Platinum Series PLATINUM-760 SS-760XP2 SeaSonic Electronics Platinum Series PLATINUM-760 SS-760XP2
Click to enlarge image

We recommend checking out our discussion threads on the SeaSonic Electronics Platinum Series PLATINUM-760 SS-760XP2, which address similar problems with connecting and setting up Power Supplies SeaSonic Electronics.



User manual for the SeaSonic Electronics Platinum Series PLATINUM-760 SS-760XP2

The user manual for the SeaSonic Electronics Platinum Series PLATINUM-760 SS-760XP2 provides necessary instructions for the proper use of the product Computers & Solutions - Computer Components - Power Supplies.

The Platinum Series SS-760XP2 Active PFC F3 760W Power Supply Unit from Sea Sonic Electronics is designed for high-performance PCs where reliability is essential. It offers tight voltage regulation (±2%), virtually silent operation, and a fully-modular design. The 80 PLUS Platinum efficiency ensures power savings with up to 92% efficiency at 50% operating load.
If you own a SeaSonic Electronics power supplies and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the SeaSonic Electronics Platinum Series PLATINUM-760 SS-760XP2 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the SeaSonic Electronics Platinum Series PLATINUM-760 SS-760XP2:
Specifications
Compliance Intel ATX12V / EPS12V
80 PLUS Certification Level Platinum
Power Efficiency >90, 92, and 89% efficiency at 20, 50, and 100% operating load respectively
AC Input Range 100 to 240 V, 9.5 to 4.5 A, 50/60 Hz
DC Output Total: 760 W
Load At +3.3 & +5 VDC Output:
Maximum Load: 25 A
Combined Load: 125 W

At +12 VDC Output:
Maximum Load: 63 A
Combined Load: 756 W

At -12 VDC Output:
Maximum Load: 0.5 A
Combined Load: 6 W

At +5 Vsb DC Output:
Maximum Load: 3 A
Combined Load: 15 W
Connectors 1 x 20/24-pin motherboard power [24" (610 mm)]
1 x 6/8-pin EPS12V / ATX12V [25.5" (650 mm)]
1 x 8-pin EPS12V [25.5" (650 mm)]
4 x 6/8-pin PCIe [23.6" (600 mm)]
5 x 4-pin Peripheral
10 x SATA
1 x 4-pin floppy (Y-adapter)
Fan Control Fanless, Silent, and Cooling modes
PFC (Power Factor Correction) 99%
Efficiency ENERGY STAR
ErP Lot 6 2013 complaint
Protection Features OPP / OVP / UVP / SCP / OCP / OTP
Safety Certificates WEEE, RoHS, UL, FCC, CB, CE, TÜV, C-Tick, PCT, CCC & EMC, BSMI, Green Dot
Dimensions (L x W x H) 6.3 x 5.9 x 3.4" (16.0 x 15.0 x 8.6 cm)
Packaging Info
Package Weight 7.75 lb
Box Dimensions (LxWxH) 13.0 x 7.7 x 5.4"
The user manual for the SeaSonic Electronics Platinum Series PLATINUM-760 SS-760XP2 can be downloaded in .pdf format if it did not come with your new power supplies, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other SeaSonic Electronics users keep a unique electronic library for SeaSonic Electronics power suppliess, where you can use our link to download the user manual for the SeaSonic Electronics Platinum Series PLATINUM-760 SS-760XP2.

The user manual lists all of the functions of the SeaSonic Electronics Platinum Series PLATINUM-760 SS-760XP2, all the basic and advanced features and tells you how to use the power supplies. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from SeaSonic Electronics service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the SeaSonic Electronics Platinum Series PLATINUM-760 SS-760XP2. User manuals are also available on the SeaSonic Electronics website under Computers & Solutions - Computer Components - Power Supplies.
