The Shure SLX Wireless Boundary Microphone Basic Kit from B&H provides everything necessary for the wireless capture of speech, ambiance and more utilizing a boundary microphone. The kit includes the Shure MX890 wireless boundary microphone, SLX4 wireless diversity receiver, rugged carrying case, XLR cable, and a set of 4 AA batteries with charger.
If you own a Shure wireless systems and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Shure SLX Series Wireless Boundary Microphone Basic Kit in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Shure SLX Series Wireless Boundary Microphone Basic Kit:
Specifications
    • Shure MX690 Microflex Wireless Boundary Microphone (G5)
      Transducer Electret Condenser
      Polar Pattern Cardioid
      Frequency Range 50 Hz to 17 kHz
      Sensitivity 33 mV/PA
      Power Requirements 2x AA Batteries
      Operating Current Consumption 130 mA

      +/-15 mA

      Dynamic Range 96 dB
      General
      Length 5.83" (148 mm)
      Weight 11.2 oz (0.32 kg)
      Packaging Info
      Box Dimensions (LxWxH) 9.8 x 4.7 x 3.3"
    • Shure SLX4 Wireless Receiver with Antennas and Power Supply (G5: 494-518MHz)
      Type of Receiver UHF Diversity Half-Rack Mountable
      RF Carrier Frequency Range G5: 494-518MHz
      Approx. Working Range 300' (100 m)
      Overall Frequency Response 45Hz - 15KHz ±2dB
      Signal-to-Noise Ratio > 100dB A-weighted
      # Of Channels 960 operating frequencies across a 24MHz
      Type of Output(s) XLR connection: 200Ω
      1/4" connection: 1kΩ
      Headphone Monitoring No
      Power Requirements 12-18 VDC at 150mA, supplied by external power supply
      Display Backlit LCD
      Mounting Options Short and Long Rack-Mount Hardware Included
      Antenna Type Dual 1/4 wave BNC type
      Dimensions 1.65 x 7.76 x 5.26" (42 x 197 x 134mm)
      Weight 28.78 oz (816g)
      Packaging Info
      Box Dimensions (LxWxH) 18.0 x 14.5 x 4.0"
    • Gator Cases GM-1W Wireless Mobile Pack
      Material Exterior: 600 denier nylon
      Interior: Foam padded
      Type of Closure Zippers
      Exterior Dimensions 15.35 x 5.0 x 11.42" (38.99 x 12.7 x 29cm) (LxDxH)
      Interior Dimensions 8.5 x 2.0 x 8.5" (21.59 x 5.08 x 21.59cm) (LxDxH)
      Mic Drops: 8.25" (20.96cm)
      Carrying/Transport Options Shoulder strap
      Padded carrying handles
      Weight 4.4 lbs (2.0kg)
      Packaging Info
      Box Dimensions (LxWxH) 14.724 x 10.315 x 4.882"
    • Kopul Studio Elite 4000 Series XLR M to XLR F Microphone Cable - 20' (6.1 m), Black
      Cable Type 3-Pin XLR balanced microphone cable
      Length 20' (6.1 m)
      Shielding 98% coverage braided shield
      Gauge 24 AWG
      Contacts Silver
      Connector 1 XLR Male
      Connector 2 XLR Female
      Packaging Info
      Box Dimensions (LxWxH) 10.7 x 8.0 x 1.5"
    • Watson 4-Hour Rapid Charger with 4 AA NiMH Rechargeable Batteries (2300mAh)
      Charger
      Configuration 2 or 4 x AA or AAA NiMH or NiCd batteries
      Input Voltage 100-240 VAC, 50/60 Hz
      Output Voltage 2.8 VDC, 500 mAh
      Charging Time 4 AAA 1000 mAh batteries: About 200 min
      2 AAA 1000 mAh: About 100 min
      4 AA 1800 mAh: About 220 min
      2 AA 1800 mAh: About 110 min
      4 AA 2300 mAh: About 280 min
      2 AA 2300 mAh: About 140 min
      Operating Temperature 32 to 113°F (0 to 45°C)
      Dimensions 2.7 x 1.3 x 4.3" (6.9 x 3.3 x 10.9 cm)
      Weight 2.8 oz (79.4 g)
      Battery
      Quantity 4 x AA
      Chemistry Nickel-metal hydride (NiMH) rechargeable
      Capacity 2300 mAh
      Output Voltage 1.2 V
      Durability Can be recharged up to 1000 times
      Environmental Protection Mercury- and cadmium-free
      Packaging Info
      Box Dimensions (LxWxH) 7.7 x 4.3 x 1.9"
