User manual Toshiba EHV4-120-500 Embedded Hybrid Video Recorder EHV4-120-500

Operating instructions and pdf manual for use - Toshiba EHV4-120-500 Embedded Hybrid Video Recorder EHV4-120-500 User manual, User manual Toshiba EHV4-120-500 Embedded Hybrid Video Recorder EHV4-120-500, Toshiba, EHV4-120-500, Embedded, Hybrid, Vid


User manual for Toshiba EHV4-120-500 Embedded Hybrid Video Recorder EHV4-120-500

Toshiba EHV4-120-500 Embedded Hybrid Video Recorder EHV4-120-500
  • Manufacturer: Toshiba
  • Basic description and contents of package
  • Product classification: Surveillance - Surveillance Video - Digital Video Recorders (DVRs)
  • Safety instructions
  • Startup and operation of the digital video recorders (dvrs)
  • Tips for setting up your Toshiba
  • Settings and expert assistance
  • Contact Toshiba service
  • Troubleshooting
  • Warranty information
  • Price: 599 USD
We recommend checking out our discussion threads on the Toshiba EHV4-120-500 Embedded Hybrid Video Recorder EHV4-120-500, which address similar problems with connecting and setting up Digital Video Recorders (DVRs) Toshiba.



User manual for the Toshiba EHV4-120-500 Embedded Hybrid Video Recorder EHV4-120-500

The user manual for the Toshiba EHV4-120-500 Embedded Hybrid Video Recorder EHV4-120-500 provides necessary instructions for the proper use of the product Surveillance - Surveillance Video - Digital Video Recorders (DVRs).

The Toshiba EHV4-120-500 Embedded Hybrid Video Recorder (500 GB) enables analog and IP video recording for maximum flexibility in a cost effective solution. With up to 16 analog channels, 4 IP channels, and 480 FPS at full D1 resolution, the EHV series provides efficient and reliable video recording. Compatible with Surveillix SCS video management software and MySurveillix for remote access and multi-site deployments for a complete surveillance solution.
If you own a Toshiba digital video recorders (dvrs) and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Toshiba EHV4-120-500 Embedded Hybrid Video Recorder EHV4-120-500 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Toshiba EHV4-120-500 Embedded Hybrid Video Recorder EHV4-120-500:
Overview
Number of Channels 4
Video Channels Analog: 4 IP: 4
Local Display 1 VGA, 1 BNC
1 BNC (Call monitor)

Local display shows analog video only. IP video accessed via browser or VMS software.

Frame Rate 120 fps@CIF (analog only)
90 fps@CIF (with IP cameras)
Compression Format Analog: H.264 IP: H.264
Maximum Recording Throughput IP: 32 Mbps
Storage
Storage Capacity 500 GB
HDD 2 Internal SATA
External Storage eSATA x 1 (3TB maximum, 10MB/s speed)

eSATA port supports 1 drive only.

Export Formats AVI, MPEG
Analog Recording Rate/Resolution 720 x 480: 30 fps (analog only)
720 x 480: 27 fps (with IP)
720 x 240: 60 fps (analog only)
720 x 240: 45 fps (with IP)
352 x 240: 120 fps (analog only)
352 x 240: 90 fps (with IP)
Live Viewing Rate (PPS) Analog: 120 fps
Inputs/Outputs
Audio Inputs up to 4 (4 analog)
Audio Outputs 1 RCA Line Out
USB 2 USB 2.0
Alarm I/O 4/4
RS-232 9 Pin D-Sub Male
RS-485 Terminal Block
Ethernet 1 Gigabit Ethernet
Remote
Browser / Remote Client Internet Explorer
Application Software Smartphone: iPhone/Android/Blackberry Tablet: iPad/Android
Software VMS: Surveillix SCS
Other Features
Operating System Embedded Linux
ONVIF Version 1.02
Approvals FCC Class B, EN55022, EN61000, EN50130, ANSI C63, IEC 0950
Screen Live: 4 (analog channel, local display), 4 (client software)
Playback: 4 (client software)
User Interface Mouse & wireless IR remote
Power
Power Input 12 VDC, 5 A
Power Consumption 60 W
Environmental
Humidity 10 to 80% R.H
Operating Temperature 41 to 104°F (5 to 40°C)
Dimensions
Dimensions (H x W x D) 3.46 x 16.53 x 16.85" (87.88 x 419.86 x 427.99 mm)
The user manual for the Toshiba EHV4-120-500 Embedded Hybrid Video Recorder EHV4-120-500 can be downloaded in .pdf format if it did not come with your new digital video recorders (dvrs), although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Toshiba users keep a unique electronic library for Toshiba digital video recorders (dvrs)s, where you can use our link to download the user manual for the Toshiba EHV4-120-500 Embedded Hybrid Video Recorder EHV4-120-500.

The user manual lists all of the functions of the Toshiba EHV4-120-500 Embedded Hybrid Video Recorder EHV4-120-500, all the basic and advanced features and tells you how to use the digital video recorders (dvrs). The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Toshiba service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Toshiba EHV4-120-500 Embedded Hybrid Video Recorder EHV4-120-500. User manuals are also available on the Toshiba website under Surveillance - Surveillance Video - Digital Video Recorders (DVRs).
