User manual ViewSonic VA2855SMH 28" Full HD LED Monitor VA2855SMH

Operating instructions and pdf manual for use - ViewSonic VA2855SMH 28" Full HD LED Monitor VA2855SMH User manual, User manual ViewSonic VA2855SMH 28" Full HD LED Monitor VA2855SMH, ViewSonic, VA2855SMH, 28, Full, HD, LED, Monitor, VA2855SMH,


User manual for ViewSonic VA2855SMH 28" Full HD LED Monitor VA2855SMH

Overall rating 4.0
Overall Rating: 4.0

80% of respondents would recommend this to a friend.
ViewSonic VA2855SMH 28
  • Manufacturer: ViewSonic
  • Basic description and contents of package
  • Product classification: Computers & Solutions - Monitors & Displays - Computer Monitors
  • Safety instructions
  • Startup and operation of the computer monitors
  • Tips for setting up your ViewSonic
  • Settings and expert assistance
  • Contact ViewSonic service
  • Troubleshooting
  • Warranty information
  • Price: 220 USD
We recommend checking out our discussion threads on the ViewSonic VA2855SMH 28" Full HD LED Monitor VA2855SMH, which address similar problems with connecting and setting up Computer Monitors ViewSonic.



User manual for the ViewSonic VA2855SMH 28" Full HD LED Monitor VA2855SMH

The user manual for the ViewSonic VA2855SMH 28" Full HD LED Monitor VA2855SMH provides necessary instructions for the proper use of the product Computers & Solutions - Monitors & Displays - Computer Monitors.

The VA2855SMH 28" Full HD LED Monitor from ViewSonic features a 1920 x 1080 resolution, 3,000:1 contrast ratio, and 6.5 ms response time. It features an integrated HDMI port, as well as a VGA port, so you can easily connect to your devices for an optimal multimedia experience. It also features language selection and on-screen controls.
If you own a ViewSonic computer monitors and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the ViewSonic VA2855SMH 28" Full HD LED Monitor VA2855SMH in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the ViewSonic VA2855SMH 28" Full HD LED Monitor VA2855SMH:
Specifications
    Display
    Display Type Color a-Si Active Matrix TFT LCD
    Display Size 28.0" (711.2 mm)
    Resolution 1920 x 1080
    Brightness 300 cd/m2
    Contrast Ratio (Typical) 3,000:1
    Viewing Angles (H/V) 178°/178°
    Colors 16.7M (true 8-bit)
    Response Time (GtG) 6.5 ms
    Backlight White-light LED
    Backlight Life 40,000 hours (minimum)
    Panel Surface Anti-glare, hard-coating (3H)
    Video Input
    Digital VGA, HDMI
    Frequency Fh: 24 to 82 kHz
    Fv: 50 to 75 Hz
    Sync Separate Sync
    Composite Sync
    Sync on Green
    Audio Output
    Speakers 2 x 2 W
    Connectors
    Video In 1 x VGA
    1 x HDMI
    Audio In 1 x 3.5 mm mini jack
    Headphone 1 x 3.5 mm mini jack
    Power External power adapter
    Controls
    Front Panel Buttons Power, 1, Up, Down, 2
    OSD Auto Image Adjust, Contrast/Brightness, Input Select, Audio Adjust, Color Adjust, Information, Manual Image Adjust, Setup Menu, Memory Recall
    Ergonomics
    Tilt Forward 5°/Back 23°
    Power
    Voltage 100 to 240 VAC (universal), 50/60 Hz
    Consumption 32 W (typical)
    42 W (maximum)
    Optimize: 26 W (typical)
    Conserve: 20 W (typical)
    General
    Compatibility PC: Up to 1920 x 1080 non-interlaced
    Mac: Up to 1920 x 1080
    Operating Conditions Temperature: 32 to 104°F (0 to 40°C)
    Humidity: 10 to 90% (non-condensing)
    Regulations WHQL, CE, CB, RoHS, REACH, WEEE, TCO, UL, UL, FCC-B, ES 6.0, EPEAT SILVER, NRCan
    VESA Compatibility VESA: 100 x 100 mm
    Dimensions (W x H x D) With Stand: 26.0 x 17.8 x 9.8" (659.7 x 452.6 x 249.7 mm)
    Without Stand: 26.0 x 15.4 x 1.9" (659.7 x 391.0 x 49.3 mm)
    Weight With Stand: 11.7 lb (5.3 kg)
    Without Stand: 10.4 lb (4.7 kg)
    Packaging Info
    Package Weight 15.0 lb
    Box Dimensions (LxWxH) 28.0 x 21.0 x 6.0"
    The user manual for the ViewSonic VA2855SMH 28" Full HD LED Monitor VA2855SMH can be downloaded in .pdf format if it did not come with your new computer monitors, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other ViewSonic users keep a unique electronic library for ViewSonic computer monitorss, where you can use our link to download the user manual for the ViewSonic VA2855SMH 28" Full HD LED Monitor VA2855SMH.

    The user manual lists all of the functions of the ViewSonic VA2855SMH 28" Full HD LED Monitor VA2855SMH, all the basic and advanced features and tells you how to use the computer monitors. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from ViewSonic service.

    If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the ViewSonic VA2855SMH 28" Full HD LED Monitor VA2855SMH. User manuals are also available on the ViewSonic website under Computers & Solutions - Monitors & Displays - Computer Monitors.
