User manual for the Yamaha MG16 - 16-Input Mixer MG16

The user manual for the Yamaha MG16 - 16-Input Mixer MG16 provides necessary instructions for the proper use of the product Pro Audio - Recording - Analog Recording Mixers.

The MG16 from Yamaha is a compact mixer capable of sixteen simultaneous inputs and is ideal for performances, recordings lectures and more. The mixer features eight mono mic/line combo input channels, two stereo line input channels that can also be used as mono mic or line inputs (XLR and stereo 1/4" inputs), and two stereo line inputs with 1/4" and RCA jacks.

Channels 1-12 are each equipped with D-PRE mic preamps, 3-band EQ, pan control and a high-pass filter. The D-PRE mic preamps feature an inverted Darlington circuit and switchable 48V phantom power for use with dynamic and condenser microphones. Channels 1-8 each also feature 26dB attenuation switches for use with loud sound sources such as guitar amplifiers and drums.

The MG16 mixer has XLR and TRS stereo outs for connecting to your PA system or monitor speakers. It also has a 1/4" headphone output with level control for personal monitoring, as well as additional TRS 1/4" stereo monitor outs for sending to powered speakers, amplifiers or devices such as digital recorders.
If you own a Yamaha analog recording mixers and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Yamaha MG16 - 16-Input Mixer MG16 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Yamaha MG16 - 16-Input Mixer MG16:
Specifications
    Phantom Power +48 V switchable, channels 1 - 12
    Input Channels 8x mono [mic/line]
    2x mono/stereo [mic/line]
    2x stereo [line]
    Output Channels 2x stereo out
    1x monitor out
    1x headphone out
    4x aux out
    4x group out
    Bus Stereo: 1
    AUX: 4
    GROUP: 4
    Pad 26 dB (mono)
    HPF 80 Hz, 12 dB/oct (mono/stereo: MIC only)
    Compressor Threshold: +22 dBu to -8 dBu
    Ratio: 1:1 to 4:1
    Output level: 0 dB to 7 dB
    Attack time: approx. 25 msec
    Release time: approx. 300 msec
    Equalizer EQ high gain: +15 dB/-15 dB, frequency: 10 kHz shelving
    EQ mid gain: +15 dB/-15 dB, frequency: mono 250 Hz - 5 kHz peaking
    EQ low gain: +15 dB/-15 dB, frequency: 100 Hz shelving
    LED Peak LED turns on when post EQ signal reaches 3 dB below clipping
    Total Harmonic Distortion 0.03% @ +14 dBu (20 Hz to 20 kHz), GAIN knob: Min, 0.005% @ +24 dBu (1 kHz), GAIN knob: Min
    Frequency Response +0.5 dB/-1.5 dB (20 Hz to 48 kHz), refer to the nominal output level @ 1 kHz, GAIN knob: Min
    Equivalent Input Noise -128 dBu (mono input channel, Rs: 150 Ω, GAIN knob: max)
    Residual Output Noise -102 dBu (STEREO OUT, STEREO master fader: min)
    Crosstalk -78 dB
    Power Requirement AC 100 - 240 V, 50 / 60 Hz
    Power Consumption 30 W
    Dimensions 17.5 x 5.1 x 19.7" (444 x 130 x 500 mm)
    Net Weight 14.6 lb (6.6 kg)
    Packaging Info
    Package Weight 19.9 lb
    Box Dimensions (LxWxH) 21.9 x 20.4 x 8.4"
    MG Mixers Demo
    The user manual for the Yamaha MG16 - 16-Input Mixer MG16 can be downloaded in .pdf format if it did not come with your new analog recording mixers, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Yamaha users keep a unique electronic library for Yamaha analog recording mixerss, where you can use our link to download the user manual for the Yamaha MG16 - 16-Input Mixer MG16.

    The user manual lists all of the functions of the Yamaha MG16 - 16-Input Mixer MG16, all the basic and advanced features and tells you how to use the analog recording mixers. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Yamaha service.

    If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Yamaha MG16 - 16-Input Mixer MG16. User manuals are also available on the Yamaha website under Pro Audio - Recording - Analog Recording Mixers.
