Walkera Propellers for Scout X4 Multi-Rotor (Pair) SCOUT X4-Z-01 The pair of Propellers for Scout X4 Multi-Rotor from Walkera features one clockwise- (CW) and one counterclockwise- (CCW) rotating propeller. When installing new props, please ensure you follow the rotational direction indicated b... Walkera G-2D 2 Axis Brushless Gimbal for iLook / GoPro HERO3 The G-2D 2 Axis Brushless Gimbal from Walkera is designed to stabilize a GoPro HERO3 or Walkera iLook action camera. Two axis of stabilization enable 45-degree side-to-side movement and ±90-degree tilt. The gimbal features co... Walkera Hook-and-Loop Fastener Strap for Runner RUNNER 250-Z-27 The Hook-and-Loop Fastener Strap for Runner 250 Quadcopter from Walkera secures the flight battery.... Walkera Motor for Runner 250 Quadcopter (CW) RUNNER 250-Z-14 The Motor for Runner 250 Quadcopter from Walkera features a motor velocity constant of 2500 Kv. This motor is produces clockwise (CW) rotation. Please be sure this rotational direction is the same as the motor you are replacing.... Walkera Vibration Damper for Runner 250 RUNNER 250-Z-08 The Vibration Damper for Runner 250 Quadcopter from Walkera features four damping balls that sandwich between the two halves of the camera fixed plate. They serve to isolate the camera from vibrations generated by the motors.... Walkera Bottom Main Board for Runner 250 RUNNER 250-Z-03 The Bottom Main Board for Runner 250 Quadcopter from Walkera provides a platform to which key flight control components attach.... Walkera TX5816 5.8 GHz Video Transmitter RUNNER 250-Z-20 The TX5816 5.8 GHz Video Transmitter for Runner 250 from Walkera broadcasts a live, low-latency video feed from the quadcopter's camera to a separately available receiver or FPV goggles at the ground end. This version of the trans... Walkera Receiver for Runner 250 Quadcopter RUNNER 250-Z-18 The Receiver for Walkera enables the Runner 250 Quadcopter to communicate with select DEVO transmitters (radio controllers). Note: Your transmitter must be bound to the receiver before use. Please refer to the Runner 250's manua... Walkera Mushroom Antenna for Runner 250 RUNNER 250-Z-28 The Mushroom Antenna from Walkera is a cloverleaf 5.8 GHz video transmitter antenna that works with the FPV transmitter for the Runner 250 Quadcopter as well as the iLook and iLook+ cameras.... Walkera 2200mAh LiPo Flight Battery for Runner RUNNER 250-Z-26 The 2200mAh Flight Battery for Runner 250 Quadcopter from Walkera will power the racing quad for up to 14 minutes.... Walkera OSD Module for Runner 250 Quadcopter RUNNER 250-Z-25 The OSD Module for Runner 250 Quadcopter from Walkera enables key telemetry data to be superimposed over the video downlink image. The module includes installation screws.... Walkera FPV Camera for Runner 250 Quadcopter RUNNER 250-Z-24 The FPV Camera for Runner 250 Quadcopter from Walkera installs at the front of the aircraft, affording you a first-person perspective from the air. It features a resolution of 800 TVL and can output composite video in NTSC or PAL.... Walkera Power Board for Runner 250 Quadcopter RUNNER 250-Z-23 The Power Board for Runner 250 from Walkera distributes power from the battery to the ESCs and the flight control system.... Walkera LED Light for Runner 250 Quadcopter RUNNER 250-Z-22 The pair of red LED Lights for Runner 250 from Walkera install at the rear ("tail") of the quadcopter, helping the pilot see the aircraft as well as stay on top of its orientation.... Walkera Main Control Board for Runner 250 RUNNER 250-Z-19 The Main Control Board for Runner 250 from Walkera is a mini computer in charge of aircraft functions. It processes user input from the transmitter (radio controller) and, after taking into account sensor data, translates this in... Walkera ESC for Runner 250 Multi-Rotor (CCW) RUNNER 250-Z-17 The ESC for Runner 250 Multi-Rotor from Walkera regulates power supplied to one of the quadcopter's motors (one is required per motor). This ESC is for the motor with counterclockwise (CCW) rotation. Please be sure this rotational... Walkera ESC for Runner 250 Multi-Rotor (CW) RUNNER 250-Z-16 The ESC for Runner 250 Multi-Rotor from Walkera regulates power supplied to one of the quadcopter's motors (one is required per motor). This ESC is for the motor with clockwise (CW) rotation. Please be sure this rotational directi... Walkera Motor for Runner 250 Quadcopter (CCW) RUNNER 250-Z-15 The Motor for Runner 250 Quadcopter from Walkera features a motor velocity constant of 2500 Kv. This motor is produces counterclockwise (CCW) rotation. Please be sure this rotational direction is the same as the motor you are repl... Walkera Screw Set for Runner 250 Quadcopter RUNNER 250-Z-13 The Screw Set for Runner 250 Quadcopter from Walkera features a complete set of assembly screws required to build a stock Runner 250.... Walkera Support Frame for Runner 250 Quadcopter RUNNER 250-Z-12 The Support Frame for Runner 250 from Walkera provides a support platform for the Upper Main Board at the "nose" section of the quadcopter. It also includes the Support Pillar....
