The Draper Orbiter Projector Mount for Video Projectors, Model B - 27 x 29.5 x 16" is an exciting projector mounting solution. This totally unique lift conceals your projector above the ceiling and quickly rotates it into the "show" position at the touch of a switch or wireless transmitter.
If you own a Draper projector lifts and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Draper Orbiter Projector Mount for Video Projectors, 300353 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Draper Orbiter Projector Mount for Video Projectors, 300353:
Lift
Lift Type Video projector
Depth From Mounting Source Flush
Mounting Source Opening (WxD) Ceiling recessed; can be installed on an angle, up to 90°
Closure Panel Dimension (WxD)
  • Ceiling Panel Size: 21.5 x 23-9/16" (54.6 x 59.9cm)
  • Ceiling Cutout Size: 25 x 23" (63.5 x 58.4cm)
  • Max Equipment Size Maximum projector width:
  • 17" for Model A
  • 20.75" for Model B
  • Travel Distance Not Specified by Manufacturer
    Travel Speed Not Specified by Manufacturer
    Adjustments Tilt, yaw and pan
    Controls
    Control Option DC Motor Control; 3-Button 12V DC switch, IR or RF

    Since Orbiter has a DC motor, this control unit is required for IR or RF remote control, or when interfacing with a master control system

    Integrated Control 12V DC motor with adjustable limits. Double-pole, double-throw wall switch is standard
    Low Voltage Not Specified by Manufacturer
    General
    Construction Metal
    Power Requirements Unit operates on 12VDC
    Maximum Current Draw Output: 12 VDC; 1.25-1.5 Amp
    Dimensions 27 x 29.5 x 16" (68.6 x 74.9 x 40.6cm)
    Weight Capacity Suits most projectors up to 26 lbs (11.8 kg)
    Weight 38 lbs (17.2 kg)
    The user manual for the Draper Orbiter Projector Mount for Video Projectors, 300353 can be downloaded in .pdf format if it did not come with your new projector lifts, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Draper users keep a unique electronic library for Draper projector liftss, where you can use our link to download the user manual for the Draper Orbiter Projector Mount for Video Projectors, 300353.

    The user manual lists all of the functions of the Draper Orbiter Projector Mount for Video Projectors, 300353, all the basic and advanced features and tells you how to use the projector lifts. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Draper service.
