User manual for the QSC CXD4.3 Processing Amplifier CXD4.3-XX

The user manual for the QSC CXD4.3 Processing Amplifier CXD4.3-XX provides necessary instructions for the proper use of the product Pro Audio - Live Sound - Power Amplifiers.

The QSC CXD4.3 Processing Amplifier from the CXD Series is designed specifically for the needs of integrators. It provides efficient, robust, and high-fidelity power to drive multiple channels and configurations of loudspeakers. It simultaneously deploys sophisticated digital processing with optimal energy and rack space efficiency. This 4-channel amplifier with onboard DSP has the capability to configure and combine channels in various ways to drive a wide range of loudspeaker systems including 70V and 100V without the use of transformers. This amplifier not only provides the power and processing to make your system perform better, it also offers efficiency ensuring that energy consumption will be kept to a minimum over the life of the installation.
If you own a QSC power amplifiers and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the QSC CXD4.3 Processing Amplifier CXD4.3-XX in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the QSC CXD4.3 Processing Amplifier CXD4.3-XX:
Specifications
    Channels 4 Channels Continuous:

    100 V RMS: 500 W

    70 V RMS: 625 W

    8 Ω: 625 W

    4 Ω: 625 W

    2 Ω: 625 W

    2 Channels Continuous:

    8 Ω: 1250 W

    4 Ω: 1200 W

    2 Ω: 1200 W

    1 Channel Continuous:

    8 Ω: 2500 W

    4 Ω: 2500 W

    2 Ω: 2500 W

    1 Ω: 2500 W

    1.0 kHz sine wave, 1% THD, 1 channel driven

    Distortion Typical Distortion:

    8 Ω: 0.01 to 0.03%

    4 Ω: 0.03 to 0.06%

    Maximum Distortion:

    4 to 8 Ω: 1.0%

    20 Hz to 15 kHz +/- 0.2 dB

    Frequency Response 20 Hz to 20 kHz + 0.2 dB

    -0.7 dB (8 Ω)

    Noise Characteristics
    Output Unweighted Output Unmuted: -101 dB

    Weighted Output Muted: -109 dB

    Gain 38.4 dB (1.2 V setting)
    Damping Factor > 150
    Input Impedance > 10 k, balanced or unbalanced
    Maximum Input Level 3.9 V Setting: 12.28 V (+24 dBu)

    1.2 V Setting: 3.88 V (+14 dBu)

    Controls and Indicators Front:

    Power

    Channel mute buttons

    Channel select buttons

    Channel input signal and clip LED indicators

    Channel output and limit LED meters

    Home, enter, exit, gain navigation buttons

    Control knob

    Rear:

    AC power disconnect

    Input Connectors 3-pin phoenix
    Output Connectors 2-pin phoenix speaker
    Amplifier Amplifier and load protection: Short circuit, open circuit, thermal, RF protection. On / Off muting, DC fault shutdown, active inrush limiting, input current limiting
    AC Power Input: Universal power supply 100 to 240 VAC, 50 to 60 Hz
    Agency Approval UL, CE, RoHS / WEEE compliant, FCC Class A (conducted and radiated emissions)
    Dimensions (H x W x D) 3.50 x 19.00 x 16.00" (8.89 x 48.26 x 40.64 cm)
    Weight 21.00 lb (9.53 kg)
    Packaging Info
    Package Weight 26.25 lb
    Box Dimensions (LxWxH) 23.1 x 20.7 x 6.6"
    The user manual for the QSC CXD4.3 Processing Amplifier CXD4.3-XX can be downloaded in .pdf format if it did not come with your new power amplifiers, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other QSC users keep a unique electronic library for QSC power amplifierss, where you can use our link to download the user manual for the QSC CXD4.3 Processing Amplifier CXD4.3-XX.

    The user manual lists all of the functions of the QSC CXD4.3 Processing Amplifier CXD4.3-XX, all the basic and advanced features and tells you how to use the power amplifiers. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from QSC service.

    If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the QSC CXD4.3 Processing Amplifier CXD4.3-XX. User manuals are also available on the QSC website under Pro Audio - Live Sound - Power Amplifiers.
