User manual ACTi E22 5MP Day/Night Outdoor IP Dome Camera with Basic E22FA

Operating instructions and pdf manual for use - ACTi E22 5MP Day/Night Outdoor IP Dome Camera with Basic E22FA User manual, User manual ACTi E22 5MP Day/Night Outdoor IP Dome Camera with Basic E22FA, ACTi, E22, 5MP, Day/Night, Outdoor, IP, Dome, Ca


User manual for ACTi E22 5MP Day/Night Outdoor IP Dome Camera with Basic E22FA

ACTi E22 5MP Day/Night Outdoor IP Dome Camera with Basic E22FA
  • Manufacturer: ACTi
  • Basic description and contents of package
  • Product classification: Surveillance - Surveillance Video - Wired IP Cameras
  • Safety instructions
  • Startup and operation of the wired ip cameras
  • Tips for setting up your ACTi
  • Settings and expert assistance
  • Contact ACTi service
  • Troubleshooting
  • Warranty information
  • Price: 335 USD
We recommend checking out our discussion threads on the ACTi E22 5MP Day/Night Outdoor IP Dome Camera with Basic E22FA, which address similar problems with connecting and setting up Wired IP Cameras ACTi.



User manual for the ACTi E22 5MP Day/Night Outdoor IP Dome Camera with Basic E22FA

The user manual for the ACTi E22 5MP Day/Night Outdoor IP Dome Camera with Basic E22FA provides necessary instructions for the proper use of the product Surveillance - Surveillance Video - Wired IP Cameras.

The E22 5MP Day/Night Outdoor IP Dome Camera with Basic WDR, 2-Way Audio Support, & 4.2mm Fixed Lens from ACTi is capable of recording images up to 1920 x 1080 at 30 fps and 2592 x 1944 at 15 fps. It uses H.264 HP, MJPEG compression formats for storing images.
If you own a ACTi wired ip cameras and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the ACTi E22 5MP Day/Night Outdoor IP Dome Camera with Basic E22FA in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the ACTi E22 5MP Day/Night Outdoor IP Dome Camera with Basic E22FA:
Camera
Type Box Camera
Image Sensor 1/3.2" Progressive Scan CMOS
Minimum Illumination Color: 0.1 lux at F1.4 (30 IRE, 2400 K)
B/W: 0.05 lux at F1.4 (30 IRE, 2400 K)
Color to B/W Switch ISP based switch, configurable
IR Sensitivity Range 700 to 1,100 nm
Electronic Shutter Manual: 1/5 to 1/2,000 sec
Auto: 1/5 to 1/10,000 sec
Lens
Focal Length / Aperture Fixed, f2.93 mm / F2.0
Iris Fixed iris
Focus Manual focus
Lens Mount CS mount (interchangeable lens)
Horizontal Viewing Angle 81.6°
Video
Compression H.264 HP, MJPEG
Resolutions & Frame Rates 15 fps at 2592 x 1944, 2048 x 1536, & 320 x 240; 30 fps at 1920 x 1080, 1280 x 720, & 640 x 480
Multi-Streaming Simultaneous dual streams based on two configurations
Bit Rate 28 kb/s to 6 Mb/s (per stream)
Bit Rate Mode Constant, Variable
Image Enhancement Basic WDR ((69 dB), White Balance (automatic, hold, and manual), Brightness, Contrast, Sharpness (auto), Auto Gain Control, Digital Noise Reduction, Flickerless
Privacy Masking 4 configurable regions
Text Overlay User defined text on video
Image Orientation Image flip and mirror
Audio
Audio Input & Output Terminal block
Network
Protocol TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour
Ethernet Ports 1 x Ethernet (10/100 Base-T), RJ45 connector
Security IP address filtering, HTTPS encryption, password protected user levels, anonymous login, IEEE 802.1X network access control
Alarm
Triggers Video motion detection (3 regions)
Response Notify control center, change camera settings, command other devices, email notification with snapshots, upload video or snapshot to FTP server
Interface
Connector External connector for DC iris lens
Integration
Unified Solution Fully compatible with ACTi software
ISV Integration Software Development Kit (SDK) available, ONVIF compliant
Firmware Access Browser Microsoft Internet Explorer 8.0 or newer (full functionality); Other browsers with QuickTime installed (partial functionality)
General
Power Source PoE Class 2 (IEEE802.3af)
Power Consumption 4 W
Environmental Casing Optional housing (IP66 rated)
Starting Temperature Starting/Operating: 14 to 122°F (-10 to 50°C)
Operating Humidity 10 to 85% RH
Approvals CE (EN 55022 Class B, EN 55024), FCC (Part15 Subpart B Class B)
Dimensions (W x D x H) 2.6 x 2.6 x 6.7" (6.6 x 6.6 x 16.9 cm)
Weight 0.9 lb (0.4 kg)
The user manual for the ACTi E22 5MP Day/Night Outdoor IP Dome Camera with Basic E22FA can be downloaded in .pdf format if it did not come with your new wired ip cameras, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other ACTi users keep a unique electronic library for ACTi wired ip camerass, where you can use our link to download the user manual for the ACTi E22 5MP Day/Night Outdoor IP Dome Camera with Basic E22FA.

The user manual lists all of the functions of the ACTi E22 5MP Day/Night Outdoor IP Dome Camera with Basic E22FA, all the basic and advanced features and tells you how to use the wired ip cameras. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from ACTi service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the ACTi E22 5MP Day/Night Outdoor IP Dome Camera with Basic E22FA. User manuals are also available on the ACTi website under Surveillance - Surveillance Video - Wired IP Cameras.
