User manual American Dynamics Discover 300 Outdoor Bullet Camera ADCA3BWO3RN

Operating instructions and pdf manual for use - American Dynamics Discover 300 Outdoor Bullet Camera ADCA3BWO3RN User manual, User manual American Dynamics Discover 300 Outdoor Bullet Camera ADCA3BWO3RN, American, Dynamics, Discover, 300, Outdoor,


User manual for American Dynamics Discover 300 Outdoor Bullet Camera ADCA3BWO3RN

American Dynamics Discover 300 Outdoor Bullet Camera ADCA3BWO3RN
  • Manufacturer: American Dynamics
  • Basic description and contents of package
  • Product classification: Surveillance - Surveillance Video - Wired Analog & HD Cameras
  • Safety instructions
  • Startup and operation of the wired analog & hd cameras
  • Tips for setting up your American Dynamics
  • Settings and expert assistance
  • Contact American Dynamics service
  • Troubleshooting
  • Warranty information
  • Price: 177 USD
We recommend checking out our discussion threads on the American Dynamics Discover 300 Outdoor Bullet Camera ADCA3BWO3RN, which address similar problems with connecting and setting up Wired Analog & HD Cameras American Dynamics.



User manual for the American Dynamics Discover 300 Outdoor Bullet Camera ADCA3BWO3RN

The user manual for the American Dynamics Discover 300 Outdoor Bullet Camera ADCA3BWO3RN provides necessary instructions for the proper use of the product Surveillance - Surveillance Video - Wired Analog & HD Cameras.

The silver Discover 300 Outdoor Bullet Camera with Varifocal Lens from American Dynamics uses 1/3” Format Interline CCD sensor and DSP (Digital Signal Processing) to deliver clear picture quality at a resolution of 600 TVL. This bullet camera offers BLC (Backlight Compensation), AGC (Automatic Gain Control), auto iris, and AWB (Auto White Balance). Optimal white balance is achieved through pre-defined or user-customized settings to provide clear images. Low light sensitivity renders sharp images in scenes with reduced lighting down to 0.5 lux.
If you own a American Dynamics wired analog & hd cameras and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the American Dynamics Discover 300 Outdoor Bullet Camera ADCA3BWO3RN in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the American Dynamics Discover 300 Outdoor Bullet Camera ADCA3BWO3RN:
Specifications
    Imager 1/3˝ Format Interline CCD sensor
    Horizontal Resolution 600 TVL
    Active Pixel Count (H x V) 768 x 494
    Lens Varifocal auto iris
    Focal Length 9 to 22 mm
    Aperture f/1.4 to 1.6
    Scanning Frequency 2:1 Interlace
    Minimum Illumination 0 lux with IR On
    0.55 lux (50 IRE, F1.4, AGC maximum) with IR Off
    Iris Control Video / DC auto
    S / N Ratio 48 dB (100 IRE)
    Synchronization Internal
    Shutter Speed MES 1/60, FLK, 1/250 to 1/100,000, Auto
    IR Illuminator 850 mm
    IR Range 164.04' (50.00 m)
    AGC Level Low, Middle, High, Off
    Dynamic Range AGC: 70 to 100 IRE
    AES Auto luminance control 1/60 to 1/100,000 sec
    BLC 2 zone On, Off, HLC
    White Balance Auto
    Auto White Balance Range AW1 (2,700 to 9,700 K), ATW2 (2,000 to 20,000 K), AWC, Manual
    Day/Night Auto, Color, B/W, Ext
    Brightness 0 to 255 level
    Sharpness 0 to 31 level
    DWDR On, Off
    Noise Reduction On, Off
    Programmable Privacy Zones 8
    Mirror On, Off
    On-Screen Display On, Off
    Back Focus CS mount 12 ± 1 mm
    Connectors Composite Video Output: 75 Ω BNC
    Voltage 12 VDC ± 10%
    Power Consumption 2.6 W maximum
    Housing Aluminum, Silver RAL 9022 (Pantone 877C)
    Temperature Operational: 14 to 122°F (-10 to 50°C)
    Storage: -4 to 140°F (-20 to 60°C)
    Relative Humidity 90% non-condensing
    Regulatory IP Rating: IP66
    Emissions: FCC: Part 15, Class B; CE: EN61000, Class B
    Immunity CE: EN50130-4
    Dimensions D x L: 3.33 x 7.34" (84.50 x 186.50 mm)
    Weight 2.52 lb (1.14 kg)
    Packaging Info
    Package Weight 2.5 lb
    Box Dimensions (LxWxH) 10.8 x 9.2 x 5.6"
    The user manual for the American Dynamics Discover 300 Outdoor Bullet Camera ADCA3BWO3RN can be downloaded in .pdf format if it did not come with your new wired analog & hd cameras, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other American Dynamics users keep a unique electronic library for American Dynamics wired analog & hd camerass, where you can use our link to download the user manual for the American Dynamics Discover 300 Outdoor Bullet Camera ADCA3BWO3RN.

    The user manual lists all of the functions of the American Dynamics Discover 300 Outdoor Bullet Camera ADCA3BWO3RN, all the basic and advanced features and tells you how to use the wired analog & hd cameras. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from American Dynamics service.

    If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the American Dynamics Discover 300 Outdoor Bullet Camera ADCA3BWO3RN. User manuals are also available on the American Dynamics website under Surveillance - Surveillance Video - Wired Analog & HD Cameras.
