The APB-DynaSonics ProRack House H1020 Rackmountable Sound Reinforcement Mixer delivers professional level FOH (Front Of House) sound reinforcement mixing in a compact chassis that may be rackmounted or positioned flat on a desktop. The mixer features a pivoting connector panel capable of variable angle positions for mounting in straight or angled racks. The unit features 12 mono input channels and 4 dual-mono/stereo input channels (20 mic preamps in total). There are 6 aux send controls switchable between pre or post fader. APB-DynaSonics mixers are constructed with a passive mother board and multiple active daughter boards. The active electronics input channels are user replaceable.
If you own a APB DynaSonics sound reinforcement mixers and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the APB DynaSonics ProRack House H1020 Rackmountable PRORACK-HOUSE in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the APB DynaSonics ProRack House H1020 Rackmountable PRORACK-HOUSE:
Specifications
    Connections Direct outputs on all input channels
    Inserts on all Mono input channels, Aux, Group, and Main outputs Bus inputs on all 14 mix buses (Aux, Groups, Mains) to allow for easy expansion through linking of units
    Both 1/4" and 1/8" Headphone connectors are provided
    Frequency Response +0/-0.5dB 20Hz to 20kHz (ref to 1kHz)
    THD <0.01% @ +15dBu output
    Phase Phase Response (Mic Input to Main Output): +10/-15 degrees 20Hz to 20kHz (ref to 1kHz)
    Noise Mic EIN: -128dBu @ 60dB gain, 150Ω source
    Main Bus (L-R-C-M) Output Noise: -85dBu (All channels assigned w/faders down, Master faders at unity)
    Group Bus (1-4) Output Noise: -85dBu (All Chan assigned w/faders down, Group Master fader at unity)
    Aux Bus (1-6) Output Noise: -90dBu (Aux Sends down, Aux Master at unity)
    Crosstalk Measures @ 1kHz:
    Channel Mute: > 100dB
    Channel Fader Attenuation: > 100dB
    Channel Routing: > 80dB
    Channel Pan Isolation: > 80dB
    Channel to Channel Isolation: > 90dB
    Aux Send Attenuation: > 90dB
    Aux Pan Isolation: > 70dB
    Impedance Channel XLR Input: > 3k Ω Balanced (with or without Pad)
    Channel Line Input (via TRS): > 20k Ω Balanced
    Channel Line Input (via XLR w/Pad): >4k Ω Balanced
    Channel TRS Direct Out: 100 Ω Impedance-Balanced
    Bus XLR Outputs (Main, Group, Aux): 100 Ω Symmetrically-Balanced (To Feed 600Ω or greater)
    Monitor TRS Outputs: 100 Ω Impedance-Balanced
    Levels Channel Insert: +4dBu (Tip= Send, Ring= Return, Sleeve= Audio Gnd) Max Out= +22dBu
    Channel Direct Out: +4dBu (TRS Impedance Balanced, Tip= "Hot") Max Out= +22dBu
    XLR Balanced Outs: +4dBu (Symmetrically-Balanced, Pin 2= "Hot")
    TRS Balanced Outs: +4dBu (Impedance-Balanced, Tip= "Hot") Max Out= +22dBu
    Bus Insert: -2dBu (Tip= Send, Ring= Return, Sleeve= Audio Gnd) Max Out= +22dBu
    Power Input Voltage: 100 to 240 VAC 50/60Hz
    Input Power: < 72W
    AC Mains Connector: IEC 15A Receptical
    ProRack is supplied with mating IEC cordset with either an Edison-plug (USA/Canada) or Euro-plug (Export)

    DC Output Voltages & Currents (as used by the ProRack):
    +17.6V @ 1.3A
    -17.6V @ 1.3A
    +15V @ 1A
    +48V @ 0.2A DC Output Connector: 7-Way Molex 0.156" pitch
    Dimensions (WxHxD) 19 x 4.822 x 17.47" (482.60 x 122.48 x 443.74mm)
    Weight 34 lb (15.5 kg)
    Packaging Info
    Package Weight 40.0 lb
    Box Dimensions (LxWxH) 22.0 x 22.0 x 10.0"
