User manual for the B W 46mm Close-up 2 Lens (NL2) 65-076017

The user manual for the B W 46mm Close-up 2 Lens (NL2) 65-076017 provides necessary instructions for the proper use of the product Photography - Filters - Close-up Lens Filters.

The B+W 46mm Close-up +2 Lens (NL2) is a close-up diopter lens which allows you to decrease the minimum focus distance on any lens, in turn increasing the effective maximum reproduction ratio of your lens. Additionally, you can combine close-up lenses to increase their strength and to fine tune your close-up settings.

The +2 diopters of this close-up lens focus at a distance of 50cm (1.6') with the lens focused at infinity. For the normal lens it is a stepless extension of its close-up range to approximately 1:4.5. On short to medium telephoto lenses it extends the NL1 close-up range seamlessly (with an 85mm lens to approx. 1:3.5 and with a 135mm lens to approx. 1:2.5).

B+W filters are constructed from high quality Schott glass for increased optical clarity and color fidelity. This filter has a single anti-reflective coating, which helps to improve light transmission to over 98% while preventing internal reflections and ghosting. Additionally, it features a brass filter ring for increased durability as well as jamming prevention.
If you own a B+W close-up lens filters and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the B W 46mm Close-up 2 Lens (NL2) 65-076017 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the B W 46mm Close-up 2 Lens (NL2) 65-076017:
Type Close-up lens/diopter
Size 46 mm
Dioptric Strength +2
Filter Factor N/A
Multi-Coated Single coated
Effect Decreases minimum focus distance on any lens
Construction Schott glass
Front Filter Thread Size 46 mm
Front Lens Cap Size 46 mm
Packaging Info
Package Weight 0.1 lb
Box Dimensions (LxWxH) 2.6 x 2.6 x 0.8"
