User manual Barco MatrixPRO-II 8x8 Switcher with 3G SDI R9004661

Operating instructions and pdf manual for use - Barco MatrixPRO-II 8x8 Switcher with 3G SDI R9004661 User manual, User manual Barco MatrixPRO-II 8x8 Switcher with 3G SDI R9004661, Barco, MatrixPRO-II, 8x8, Switcher, with, 3G, SDI, R9004661,


User manual for Barco MatrixPRO-II 8x8 Switcher with 3G SDI R9004661

Barco MatrixPRO-II 8x8 Switcher with 3G SDI R9004661
  • Manufacturer: Barco
  • Basic description and contents of package
  • Product classification: Professional Video - Signal Processing & Distribution - Routers & Switchers
  • Safety instructions
  • Startup and operation of the routers & switchers
  • Tips for setting up your Barco
  • Settings and expert assistance
  • Contact Barco service
  • Troubleshooting
  • Warranty information
We recommend checking out our discussion threads on the Barco MatrixPRO-II 8x8 Switcher with 3G SDI R9004661, which address similar problems with connecting and setting up Routers & Switchers Barco.



User manual for the Barco MatrixPRO-II 8x8 Switcher with 3G SDI R9004661

The user manual for the Barco MatrixPRO-II 8x8 Switcher with 3G SDI R9004661 provides necessary instructions for the proper use of the product Professional Video - Signal Processing & Distribution - Routers & Switchers.

The Barco MatrixPRO-II 8x8 Switcher with 3G SDI combines a high 600MHz bandwidth with a flat +/-1.0dB to 300MHz frequency to deliver image switching and signal distribution without any artifacts.

A genlock input synchronizes all switching with the house sync. A user-selectable RGB delay mode locks down-stream equipment to a new signal before anything is visible on the screen. And presets are available to be stored and allow easy system reconfiguration. I/O grouping and split-mode switching features divide the matrix into smaller sub-switchers and let each color channel switch independently.

Control can be by front panel buttons, by RS232, or via Ethernet connections. The switcher also fully integrates with Barco's Encore and ScreenPRO-II presentation systems and can be controlled through them.
If you own a Barco routers & switchers and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Barco MatrixPRO-II 8x8 Switcher with 3G SDI R9004661 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Barco MatrixPRO-II 8x8 Switcher with 3G SDI R9004661:
Specifications
    Supported Formats DVB-ASI, SMPTE 259M, SMPTE 292M, SMPTE 424M; 270M bps - 2.97Gbps; 2K, 2048x1556/23.98 and 24
    Inputs
    Standard SMPTE 259M / SMPTE 292M / SMPTE 424M
    Data Rate 270Mbps - 1.485Gbps / 2.97Gbps
    Connector 75 ohm BNC female
    Impedance 75 ohm nominal
    Return Loss > 15dB (5MHz - 1.485GHz); > 10dB (1.5 - 3GHz)
    Cable Equalization Automatic up to 230' (70m) @ 2.97Gbps, typical Belden 1694A
    Automatic up to 328' (100m) @ 1.485Gbps, typical Belden 1694A
    Automatic up to 984' (300m) @ 270Mbps, typical Belden 8281
    Outputs
    Connector 75 ohm BNC female
    Impedance 75 ohm nominal
    Return Loss > 15dB (5MHz - 1.485GHz); > 10dB (1.5 - 3GHz)
    Signal Level 800mVp-p ±10%
    Rise & Fall - 20 - 80%
    - SD limit: 0.4 - 1.5ns, < 0.5ns rise/fall variation
    - HD limit: < 270ps, < 100ps rise/fall variation
    - 3G-HD limit: < 135ps, < 50ps rise/fall variation
    Amplitude Overshoot < 10%
    Signal Polarity Non-inverting electrical with respect to inputs
    Power & Other Parameters
    Power 14W
    Signal Speed Timing jitter: SD: < 0.2 UI; 3G-HD/HD: < 1UI
    Alignment jitter: SD: < 0.2UI; 3G-HD/HD: < 0.2UI
    Safety Regulations Compliant with CE EN55103-1 and 2
    Control Serial port: RS-232, DB9 connector female
    Ethernet port: 10/100BaseT Ethernet bus, 1x RJ45 connector
    Rack Mount 1RU
    Dimensions 1.7 x 19 x 2" (4.4 x 48.3 x 5 cm)
    Weight 2.9 lbs (1.3 kg)
    The user manual for the Barco MatrixPRO-II 8x8 Switcher with 3G SDI R9004661 can be downloaded in .pdf format if it did not come with your new routers & switchers, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Barco users keep a unique electronic library for Barco routers & switcherss, where you can use our link to download the user manual for the Barco MatrixPRO-II 8x8 Switcher with 3G SDI R9004661.

    The user manual lists all of the functions of the Barco MatrixPRO-II 8x8 Switcher with 3G SDI R9004661, all the basic and advanced features and tells you how to use the routers & switchers. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Barco service.

    If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Barco MatrixPRO-II 8x8 Switcher with 3G SDI R9004661. User manuals are also available on the Barco website under Professional Video - Signal Processing & Distribution - Routers & Switchers.
