User manual for the Draper Signature/Series E Motorized Projection Screen 111314

The user manual for the Draper Signature/Series E Motorized Projection Screen 111314 provides necessary instructions for the proper use of the product A/V Presentation - Projection Screens - Electric Screens (Square & 4:3 Formats).

The Draper 14 x 14' Signature/Series E Motorized Front Projection Screen offers the clean appearance of a ceiling-recessed screen in virtually any size, with any viewing surface.
If you own a Draper electric screens (square & 4:3 formats) and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Draper Signature/Series E Motorized Projection Screen 111314 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Draper Signature/Series E Motorized Projection Screen 111314:
Type
Style Signature/Series E/Quiet Motor
Front/Rear Projection Front
Mount Ceiling recessed
Finish Matte White ; flame and mildew resistant
Tension Control Non-tensioned
Keystone Control Not Applicable
Dimensions
Overall Size 14 x 14' (4.3 x 4.3m)
Image Size 14 x 14' (4.3 x 4.3m)
Diagonal 237" (6m)
Format Square/Audio-Visual
Aspect Ratio 1:1
Masking Options None

NTSC, HDTV and WideScreen format screens have black borders on all four sides

Controls
Voltage 110-120V AC, 60Hz
Motor mounted with sound-absorbing fixtures
Preset, accessible limit switches
Integrated Control 3-position control switch
Switch furnished with cover plate
5-wire motor mounted inside screen roller
Instantly reversible
Lifetime lubricated, with internal thermal overload protector and electric brake
Trap door automatically opens into case when screen is operated in down direction
Control Options Single Station Control (SS-1R)
Low Voltage Switch (LVC-S)
Key Operated 3-Position Switch (KS3/SP-KSM)
Radio Frequency Remote Control (WRT/R)
Infrared Remote Control (IRT/R)
MC1 Motor Control Board
Video Interface Control
Casing
Color White
Material Extruded aluminum
Length 177" (4.3m)
General
Shipping Weight Net: 317 lbs (143.8kg)
Packaging Info
Package Weight 288.0 lb
Box Dimensions (LxWxH) 189.0 x 14.0 x 13.0"
The user manual for the Draper Signature/Series E Motorized Projection Screen 111314 can be downloaded in .pdf format if it did not come with your new electric screens (square & 4:3 formats), although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Draper users keep a unique electronic library for Draper electric screens (square & 4:3 formats)s, where you can use our link to download the user manual for the Draper Signature/Series E Motorized Projection Screen 111314.

The user manual lists all of the functions of the Draper Signature/Series E Motorized Projection Screen 111314, all the basic and advanced features and tells you how to use the electric screens (square & 4:3 formats). The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Draper service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Draper Signature/Series E Motorized Projection Screen 111314. User manuals are also available on the Draper website under A/V Presentation - Projection Screens - Electric Screens (Square & 4:3 Formats).
