User manual for the Earthworks 521 ZDT Single-Channel Mic Preamplifier for 500 521
The user manual for the Earthworks 521 ZDT Single-Channel Mic Preamplifier for 500 521 provides
necessary instructions for the proper use of the product Pro Audio - Recording - Microphone Preamps.
Based on the ZDT Preamp technology designed by David Blackmer, the 1 RU space 521 ZDT Single-Channel Mic Preamplifier from Earthworks brings the exacting standards of the Zero Distortion Technology preamplifiers to the convenient 500 series format. The solid-state 521 ZDT Preamplifier features switchable phantom power, polarity invert, and peak amplitude clip detection. The transformerless output stage of the 521 ZDT preamplifier can easily drive long cable runs without loss of quality, making it suitable for remote recordings. Transparent gain is switchable from 5 to 60 dB in 5 dB steps. The Earthworks microphone preamplifier topology provides strong common mode rejection, a high overload margin, and a low noise floor, combined with the wide bandwidth of the ZDT preamplifiers (1 Hz to 200 kHz +0.5 dB), and distortion of less than one part per million (0.0001%). This level of performance is maintained over an extensive range of impedances applied to the input, making the 521 ZDT preamplifier suitable for practically any microphone—ribbon, dynamic, or condenser.
|
If you own a Earthworks microphone preamps and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Earthworks 521 ZDT Single-Channel Mic Preamplifier for 500 521 in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the Earthworks 521 ZDT Single-Channel Mic Preamplifier for 500 521:
Preamplifier | Type: Solid state | Number of Channels | 1 | Frequency Response | 2 Hz to 100 kHz ± 0.1 dB 1 Hz to 200 kHz ± 0.5 dB | Impulse Response | 1.4 µs | Distortion | XLR Out: less than 1 ppm (0.0001%) 1/4" Out: 0.001% | Input Noise | 1.6 nV/Hz½ at 20 dB gain 0.6 nV/Hz½ at 60 dB gain | EIN | -132 dBV at 20 dB gain -143 dBV at 60 dB gain | Slew Rate | 22 V/µs | Output | DC Offset: ±1 mV typical, servo balanced | Input / Output Connectors | 500 series EDAC Edge connector | Input Impedance | XLR: 10 kΩ phantom on 100 kΩ phantom off | Front Panel | Balanced Out: 1/4" TRS XLR female, balanced, transformerless (variable) | Dimensions | One 500 series rack space: 1.50 x 5.25 x 6.00" (38.10 x 133.35 x 152.40 mm) | Weight | 0.80 lb (0.36 kg) | |
The user manual for the Earthworks 521 ZDT Single-Channel Mic Preamplifier for 500 521 can be downloaded in .pdf
format if it did not come with your new microphone preamps, although the seller is
required to supply one. It is also quite common that customers throw out
the user manual with the box, or put the CD away somewhere and then can’t find it.
That’s why we and other Earthworks users keep a unique electronic library
for Earthworks microphone preampss,
where you can use our link to download the user manual for the Earthworks 521 ZDT Single-Channel Mic Preamplifier for 500 521.
The user manual lists all of the functions of the Earthworks 521 ZDT Single-Channel Mic Preamplifier for 500 521,
all the basic and advanced features and tells you how to use the microphone preamps.
The manual also provides troubleshooting for common problems. Even greater
detail is provided by the service manual, which is not typically shipped with the product,
but which can often be downloaded from Earthworks service.
If you want to help expand our database, you can upload a link to this website
to download a user manual or service manual, ideally in .pdf format. These pages
are created by you – users of the Earthworks 521 ZDT Single-Channel Mic Preamplifier for 500 521. User manuals are also
available on the Earthworks website under Pro Audio - Recording - Microphone Preamps.
