User manual for the FotodioX WonderPana FreeArc Core Unit WDPFA-ES.6SE-KIT-TK1628

The user manual for the FotodioX WonderPana FreeArc Core Unit WDPFA-ES.6SE-KIT-TK1628 provides necessary instructions for the proper use of the product Photography - Filters - Filter Kits.

This WonderPana FreeArc Core Unit Kit from FotodioX includes a WonderPana FreeArc Core Unit designed to specifically fit the Tokina AT-X 16-28mm f/2.8 Pro FX lens, as well as a WonderPana 6.6" Holder Bracket. Those items can be combined to allow for the convenient use of two 2.5 to 4.0mm-thick filters measuring 6.6" wide, or one 2.5 to 4.0mm-thick filter measuring 6.6" wide along with one FotodioX 145mm round filter behind it. A compatible 145mm solid neutral-density 1.2 filter and a 6.6 x 8.5" soft-edge graduated ND 0.6 filter are also provided, plus a 145mm inner-pinch lens cap for 145mm FotodioX round filters.

The included WonderPana FreeArc Core Unit consists of two components, a front filter holder and a rear lens collar. Placement of this FreeArc Core Unit onto a Tokina AT-X 16-28mm f/2.8 Pro FX lens is easily accomplished by sliding the rear lens collar over the rear of the lens until it has achieved a secure fit. Afterwards, the front filter holder can be screwed onto the front of the installed rear lens collar.

To use the WonderPana 6.6" Holder Bracket with the FreeArc Core Unit for a Tokina AT-X 16-28mm f/2.8 Pro FX lens, pre-tapped threaded inserts along the edge of the front filter holder accommodate the six included brass short-screws for correct positioning of the WonderPana 6.6" Holder Bracket's two assembly pieces so that they are placed parallel to each other and can hold a 6.6"-wide filter between them. Once the holder bracket and the front filter holder are combined, and the separate collar has been slid over the rear of a Tokina AT-X 16-28mm f/2.8 Pro FX lens, the front filter holder with the attached holder bracket can be screwed onto the installed rear lens collar.

After being fitted onto a Tokina AT-X 16-28mm f/2.8 Pro FX lens, the bearing design of this WonderPana FreeArc Core Unit allows a WonderPana 6.6" Holder Bracket to be rotated 360°. This permits the use of graduated neutral density and other filters that are enhanced by varied positioning.

The FotodioX WonderPana 6.6" Holder Bracket provides two pairs of filter slots, a configuration that accommodates two compatible rectangular filters. For each rectangular filter that is placed within one of the holder bracket's slots, its position can be secured using the included brass long-screws. Pre-tapped threaded inserts along the outside of the holder bracket allow the long-screws to each apply pressure to a spring-loaded retainer within each filter slot. When a pair of the long-screws are used, the level of grip upon a rectangular filter can be varied, which can complement the use of graduated filters whose effect can be adjusted to better suit changing lighting conditions or creative demands by sliding them up or down within a filter slot.

This FotodioX WonderPana FreeArc Core Unit includes front filter threads, which allow a FotodioX 145mm round filter to be used along with the holder bracket. If a 145mm round filter is used on the attached WonderPana FreeArc Core Unit, the rectangular filter slot closest to the rear of the holder bracket becomes unavailable. The WonderPana 6.6" Holder Bracket features a durable and lightweight aluminum-alloy construction that has a corrosion-resistant, black anodized finish.

The FotodioX 145mm Solid Neutral Density 1.2 Filter is an ND filter with a 16x filter factor that provides a 4-stop exposure reduction. Its 1.2 density creates a darkening of the entire image, allowing you to photograph with a wider aperture or slower shutter speed than normally required. By slowing your exposure time or increasing your aperture, you are able to control depth of field and convey movement more easily. Neutral density filters do not affect the coloration of the image and are ideal for pairing with other filters.

To prevent internal ghosting and reflections, this filter includes multiple layers of anti-reflection coating. These coatings also offer greater protection to the filter substrate and help it to stay clean for longer than with uncoated filters. This FotodioX 145mm Solid Neutral Density 1.2 Filter is constructed from optical glass for clarity as well as color fidelity and features an aluminum-alloy filter ring for durability while remaining lightweight.

The FotodioX 6.6 x 8.5" Soft-Edge Graduated Neutral Density 0.6 Filter is a filter designed for use with the WonderPana 66 and FreeArc filter holder systems. It helps to darken specific areas of an image, such as bright skies, while allowing for a normal, unaffected exposure in the other regions of the image. The filter is densest at the edge and tapers to clear by the middle, with a soft-edged line of transition between the dense and clear areas. Neutral density filters do not affect the coloration of the image and this filter provides up to a 2-stop reduction in light from entering a lens.

This filter is made of durable, optical resin (CR39) and measures 4mm thick.

The FotodioX 145mm Center-Pinch Snap-On Lens Cap for Select WonderPana Systems and Filters is a 145mm front lens cap with a squeeze, spring, and snap-on mechanism. It is easy to install as well as remove, and can attach to a WonderPana 145, FreeArc, or Absolute filter holder system in order to protect the front element of a lens that any one of those systems are mounted on. Additionally, this lens cap can be used to protect a non-slim FotodioX WonderPana 145 filter that is mounted on a FotodioX WonderPana 145, FreeArc, or Absolute filter holder system and has no other filters placed in front of it.

Lens caps protect your lens or filter from scratches, fingerprints, and the elements when the lens or filter is not in use.
If you own a FotodioX filter kits and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the FotodioX WonderPana FreeArc Core Unit WDPFA-ES.6SE-KIT-TK1628 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the FotodioX WonderPana FreeArc Core Unit WDPFA-ES.6SE-KIT-TK1628:
Specifications
  • WonderPana 6.6" Holder Bracket
    Material Aluminum alloy
    Compatibility Adapter Ring:
    WonderPana FreeArc Core Unit
    WonderPana 145 Core Unit
    WonderPana FreeArc Step-Up Ring

    Filters:
    Accepts up to two 6.6" rectangular filters (167.6 mm wide, 2.5 to 4.0 mm thick); or up to one 6.6" rectangular filter (167.6 mm wide, 2.5 to 4.0 mm thick) and one round FotodioX 145 mm filter
    Rotating When installed on a WonderPana FreeArc Core Unit: Yes, 360°
    When installed on a WonderPana 145 Core Unit: No, but can be installed in 45° increments around the edge of a WonderPana 145 Core Unit
    When installed on a WonderPana FreeArc Step-Up Ring: Yes, 360°
    Dimensions Area occupied from edge-to-edge when installed on a WonderPana FreeArc Core Unit, WonderPana 145 Core Unit, or WonderPana FreeArc Step-Up Ring: 7.3 x 0.8" (18.5 x 2.0 cm)
    Weight 5.6 oz (158.8 g)
    Packaging Info
    Box Dimensions (LxWxH) 6.3 x 5.9 x 5.7"
  • 145mm Solid Neutral Density 1.2 Filter (4 Stop)
    Type Solid neutral density
    Size 145 mm
    Density 1.2
    Filter Factor 16 (4 stop)
    Color Temperature Does not affect color
    Effect Permits a longer exposure
    Construction Optical glass
    Front Filter Thread Size 145 mm
    Front Lens Cap Size 145 mm
    Packaging Info
    Box Dimensions (LxWxH) 7.0 x 6.7 x 0.7"
  • FotodioX 6.6 x 8.5" Soft-Edge Graduated Neutral Density 0.6 Filter (2-Stop)
    Type Graduated neutral density
    Soft/Hard Edge Soft
    Size 6.6 x 8.5 x 0.2" (168.0 x 216.0 x 4.0 mm)
    Density Up to 0.6
    Filter Factor Up to 4 (2 stop)
    Construction Optical resin CR39
    Packaging Info
    Box Dimensions (LxWxH) 10.2 x 8.4 x 1.9"
  • 145mm Center-Pinch Snap-On Lens Cap for Select WonderPana Systems and Filters
    Construction Plastic
    Size 145 mm
    Packaging Info
    Box Dimensions (LxWxH) 6.0 x 5.7 x 0.3"
