User manual for the Linhof Technorama Tele-Xenar 250mm f/5.6 Lens Unit 000915

The user manual for the Linhof Technorama Tele-Xenar 250mm f/5.6 Lens Unit 000915 provides necessary instructions for the proper use of the product Photography - Lenses - Medium Format Lenses.

The Linhof Technorama Tele-Xenar 250mm f/5.6 Lens Unit is a long focal length lens, providing a 37.6° angle of view, which is specifically designed for use with the Linhof 617s III Panoramic Camera. The lens is housed within a dedicated lens unit that allows for simple attachment to the 617s III camera body and also incorporates a range of functional elements that pair well with the handheld design of the system. A helical focusing mount is integrated into the lens unit to allow for one-handed, bellows-free, focusing as close as 12.8'. The lens is set in a standard Copal #1 shutter for shutter speeds between 1/400 to 1 sec, as well as B and T settings, and has an attached cable release with soft pressure shutter release. The shutter is uncoupled from the film winding mechanism and must be cocked prior to each exposure.

When in use, a corresponding accessory viewfinder can be used for precise image composition and the lens' distance scales are demarcated in imperial and metric measurements for focusing control.
If you own a Linhof medium format lenses and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Linhof Technorama Tele-Xenar 250mm f/5.6 Lens Unit 000915 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Linhof Technorama Tele-Xenar 250mm f/5.6 Lens Unit 000915:
Focal Length 250 mm
Aperture Maximum: f/5.6
Minimum: f/64
Camera Mount Linhof Technorama 617s III
Angle of View @ Infinity 37.6°
Image Circle @ Infinity 190 mm @ f/22
Minimum Focus Distance 12.80' (3.9 m)
Area of coverage 6 x 17 cm
Diaphragm Blades Not Specified By Manufacturer
Elements/Groups 5/5
Shutter Copal
Shutter Type Copal # 1
Shutter Speeds 1 / 400 to 1 second
Flash Synchronization At all Speeds
Flange Focal Distance 195.1 mm
DOF Scale Yes
Distance Scale Yes
PC Outlet Yes
Autofocus No
Filter Thread Front: 82 mm
Weight 3.28 lb (1.49 kg)
Dimensions Approx. 8.70 x 8.82" (221 x 224 mm)
Packaging Info
Package Weight 5.55 lb
Box Dimensions (LxWxH) 13.7 x 12.4 x 7.7"
