User manual Meade 14" LX600 ACF Telescope with StarLock 1408-70-01

Operating instructions and pdf manual for use - Meade 14" LX600 ACF Telescope with StarLock 1408-70-01 User manual, User manual Meade 14" LX600 ACF Telescope with StarLock 1408-70-01, Meade, 14, LX600, ACF, Telescope, with, StarLock, 1408-70-01,


User manual for Meade 14" LX600 ACF Telescope with StarLock 1408-70-01

Meade 14
  • Manufacturer: Meade
  • Basic description and contents of package
  • Product classification: Optics - Telescopes - Catadioptrics (Cassegrain)
  • Safety instructions
  • Startup and operation of the catadioptrics (cassegrain)
  • Tips for setting up your Meade
  • Settings and expert assistance
  • Contact Meade service
  • Troubleshooting
  • Warranty information
We recommend checking out our discussion threads on the Meade 14" LX600 ACF Telescope with StarLock 1408-70-01, which address similar problems with connecting and setting up Catadioptrics (Cassegrain) Meade.



User manual for the Meade 14" LX600 ACF Telescope with StarLock 1408-70-01

The user manual for the Meade 14" LX600 ACF Telescope with StarLock 1408-70-01 provides necessary instructions for the proper use of the product Optics - Telescopes - Catadioptrics (Cassegrain).

The 14" LX600 ACF Telescope with StarLock from Meade is a technologically advanced Cassegrain telescope with a computerized fork mount. This innovative design combined with Meade's Ultra High Transmission Coating ensures that images are bright, with high contrast and faithful color reproduction. The included Giant Field Tripod has 3" diameter steel legs with a cast aluminum adjustable head, providing the LX600 with a professional-grade foundation for celestial observations.
If you own a Meade catadioptrics (cassegrain) and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Meade 14" LX600 ACF Telescope with StarLock 1408-70-01 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Meade 14" LX600 ACF Telescope with StarLock 1408-70-01:
Telescope
Optical Design Advanced Coma Free
Aperture 14" (35.5 cm)
Focal Length 2845 mm
Focal Ratio f/8
Resolving Power 0.325 arcseconds (Dawes)
Secondary Mirror Obstruction 13.28%
Eyepiece Barrel Diameter 1.25"
Diagonal 1.25"
Finderscope 8 x 50 refractor with crosshairs
Focus System Internal Crayford-style with dual speed
Slew Speeds, R.A. and Dec. 0.01 to 1.0x sidereal (0.01x increments); 2x, 8x, 16x, 64x, 128x sidereal; 1 to 2°/sec (0.1° increments)
Tracking Method Sidereal, lunar, custom selected
Tripod Giant Field Tripod
Mount Type Heavy-duty double-tine fork
Control Panel 12v DC input, 12v DC output, Handbox input, Computer connection input (RS232), StarLock input, Aux input
Power Source (8) C batteries, 12v DC 5A Meade Universal Power Supply
Optical Tube Dimensions Not specified
Weight Optical Tube: Not specified

Tripod: 50 lb (22.7 kg)

Shipping Weight 239 lb (108.4 kg)
StarLock
Wide Field Camera 25 x 26 mm f/1.04 optic; 1/2" CMOS sensor; 14.72 x 11.78° angle of view
Narrow Field Camera 80 x 400 mm f/5 optic; 1/2" CMOS sensor; 57.2 x 45.8 arcminutes field of view (2.68 arcseconds per pixel)
High Precision Pointing +/- 1 arcminute
High Precision Guiding +/- 1 arcsecond RMS (with good seeing)
High Precision Alignment Semi-automatic drift align
Weight 2.7 lb ( 1.2 kg)
The user manual for the Meade 14" LX600 ACF Telescope with StarLock 1408-70-01 can be downloaded in .pdf format if it did not come with your new catadioptrics (cassegrain), although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Meade users keep a unique electronic library for Meade catadioptrics (cassegrain)s, where you can use our link to download the user manual for the Meade 14" LX600 ACF Telescope with StarLock 1408-70-01.

The user manual lists all of the functions of the Meade 14" LX600 ACF Telescope with StarLock 1408-70-01, all the basic and advanced features and tells you how to use the catadioptrics (cassegrain). The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Meade service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Meade 14" LX600 ACF Telescope with StarLock 1408-70-01. User manuals are also available on the Meade website under Optics - Telescopes - Catadioptrics (Cassegrain).
