User manual NVT NV-653T Active Video Transmitter NV-653T

Operating instructions and pdf manual for use - NVT NV-653T Active Video Transmitter NV-653T User manual, User manual NVT NV-653T Active Video Transmitter NV-653T, NVT, NV-653T, Active, Video, Transmitter, NV-653T, Video

User manual for NVT NV-653T Active Video Transmitter NV-653T

NVT NV-653T Active Video Transmitter NV-653T
  • Manufacturer: NVT
  • Basic description and contents of package
  • Product classification: Surveillance - Surveillance Video - Video Transmission - Signal Extenders
  • Safety instructions
  • Startup and operation of the signal extenders
  • Tips for setting up your NVT
  • Settings and expert assistance
  • Contact NVT service
  • Troubleshooting
  • Warranty information
  • Price: 164 USD
We recommend checking out our discussion threads on the NVT NV-653T Active Video Transmitter NV-653T, which address similar problems with connecting and setting up Signal Extenders NVT.


User manual for the NVT NV-653T Active Video Transmitter NV-653T

The user manual for the NVT NV-653T Active Video Transmitter NV-653T provides necessary instructions for the proper use of the product Surveillance - Surveillance Video - Video Transmission - Signal Extenders.

The NV-653T Active Video Transmitter allows the transmission of real-time monochrome or color video up to 1 mi (1.6km) using Category 2 or better Unshielded Twisted-Pair (UTP) cable. It offers remarkable interference rejection and low emissions that allow long run video signals to co-exist in the same wire bundle as telephone, datacom, or low-voltage power circuits. This allows the use of shared or existing cables. The transmitter features ground-lifting that ensures the elimination of hum-bars when ground potential differences exist. With built-in transient protection, damaging voltage spike problems are eliminated.
If you own a NVT signal extenders and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the NVT NV-653T Active Video Transmitter NV-653T in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the NVT NV-653T Active Video Transmitter NV-653T:

Go To

Video
Frequency Response DC to 10 MHz
Controls 3-Position adjustable distance switch
Mode Noise Rejection Common-mode / Differential-mode rejection 15 kHz to 5 MHz: 60 dB typical
Impedance Coaxial, Female BNC: 75 Ω
UTP, Screw Terminal Block: 100 Ω
LED Indicators Blue: Power-On, Green: Active signal present
Cable Specifications
Network One unshielded twisted pair 24 to 16 AWG (0.5 to 1.31 mm)

Not included.
Type Category 2 or better
Impedance 100 ± 20 Ω
DC Loop Resistance 52 Ω per 1000.0' (304.8 m), 18 Ω per 328.1' (100.0 m)
Differential Capacitance 19 pF/ft maximum, 62 pF/m maximum
General
Power Input 24 VAC/DC, 250 mA maximum

Power supply not included. Capable of sharing 24VAC power with a camera, provided supply is floating.
Ambient Temperature 32 to 122°F (0 to 50°C)
Humidity (Non-condensing) 0 to 95%
Transient Immunity per ANSI / IEEE 587 C62.41
Material ABS
Mounting 2 x 0.17" (4.40 mm) diameter holes 2.5" (63.5 mm) apart
Dimensions 3.0 x 1.5 x 1.1" (76.0 x 39.0 x 28.0 mm) excluding brackets and connectors
Weight 0.17 lb (0.08 kg)
Packaging Info
Package Weight 0.23 lb
Box Dimensions (LxWxH) 3.5 x 2.25 x 2.0"
The user manual for the NVT NV-653T Active Video Transmitter NV-653T can be downloaded in .pdf format if it did not come with your new signal extenders, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other NVT users keep a unique electronic library for NVT signal extenderss, where you can use our link to download the user manual for the NVT NV-653T Active Video Transmitter NV-653T.

The user manual lists all of the functions of the NVT NV-653T Active Video Transmitter NV-653T, all the basic and advanced features and tells you how to use the signal extenders. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from NVT service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the NVT NV-653T Active Video Transmitter NV-653T. User manuals are also available on the NVT website under Surveillance - Surveillance Video - Video Transmission - Signal Extenders.
