User manual for Orion Images VF703GHC 7" LED Viewfinder/Field VF703G-RMK1

Orion Images VF703GHC 7
  • Manufacturer: Orion Images
  • Basic description and contents of package
  • Product classification: Professional Video - Monitors - Production Monitors
  • Safety instructions
  • Startup and operation of the production monitors
  • Tips for setting up your Orion Images
  • Settings and expert assistance
  • Contact Orion Images service
  • Troubleshooting
  • Warranty information
  • Price: 948 USD
We recommend checking out our discussion threads on the Orion Images VF703GHC 7" LED Viewfinder/Field VF703G-RMK1, which address similar problems with connecting and setting up Production Monitors Orion Images.



User manual for the Orion Images VF703GHC 7" LED Viewfinder/Field VF703G-RMK1

The user manual for the Orion Images VF703GHC 7" LED Viewfinder/Field VF703G-RMK1 provides necessary instructions for the proper use of the product Professional Video - Monitors - Production Monitors.

The black VF703GHC 7" LED Viewfinder/Field Monitor from Orion Images uses an IPS panel with 178/178° wide viewing angles and is capable of multi-inputs including 3G-SDI and HDMI input and output. Many of the built-in functions and front assignable buttons deliver convenient usage during field production. The monitor comes with a BLK-02 metal plate. The versatile folding sunshade hood facilitates easy viewing in field and outside broadcast production when critical monitoring is required. When not needed, it is easily detachable.
If you own a Orion Images production monitors and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Orion Images VF703GHC 7" LED Viewfinder/Field VF703G-RMK1 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Orion Images VF703GHC 7" LED Viewfinder/Field VF703G-RMK1:
Panel 7.0" (177.8 mm) IPS
Resolution 1280 x 800 pixels
Pixel Pitch 0.11775 x 0.11775 mm
Display Area 5.93 x 3.70" (150.72 x 94.20 mm)
Colors 2,62,000
Brightness 400 cd/m2
Contrast Ratio 800:1
Aspect Ratio 16:9
Backlight LED
Video Interface CVBS 1 In, YPbPr 1 In, HDMI 1 In/Out
Speaker 1 (built-in) / Ear Phone 1 (built-in)
SDI 1080p (23.98/24/25/29.97/30/50/59.94/60)
1080psf (23.98/24/25/29.97/30)
1080i / 720p (50/59.94/60), 480i (59.94), 575i (50)
Assignable Buttons Center Marker, Screen Marker, Check Field, Color Bar, PIP Camera, Flip, Zoom, Pixel-to-Pixel, Freeze Input, H/V Delay, Under Scan, Peaking, False Color, Exposure, Histogram
Power Requirements 100 to 240 VAC (with AC Adapter, XLR Connector)
Power Consumption Approximately 11 W
Temperature Operating: 32 to 122°F (0 to 50°C)
Storage: -4 to 140°F (-20 to 60°C)
Dimensions (W x H x D) 7.53 x 5.99 x 1.64" (191.50 x 152.30 x 41.70 mm)
Weight without cover: 1.67 lb (0.75 kg)
with cover: 2.06 lb (0.93 kg)
with carrying case: 4.76 lb (2.15 kg)
The user manual for the Orion Images VF703GHC 7" LED Viewfinder/Field VF703G-RMK1 can be downloaded in .pdf format if it did not come with your new production monitors, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Orion Images users keep a unique electronic library for Orion Images production monitorss, where you can use our link to download the user manual for the Orion Images VF703GHC 7" LED Viewfinder/Field VF703G-RMK1.

The user manual lists all of the functions of the Orion Images VF703GHC 7" LED Viewfinder/Field VF703G-RMK1, all the basic and advanced features and tells you how to use the production monitors. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Orion Images service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Orion Images VF703GHC 7" LED Viewfinder/Field VF703G-RMK1. User manuals are also available on the Orion Images website under Professional Video - Monitors - Production Monitors.
