The Pair of X12 Subwoofers & SBC800 Powered LFE/Sub-Bass and LCR Controller from Quested is a subwoofer system for surround sound or film production. The two X12 subwoofers feature 12" drivers with a frequency range of 20 to 200 Hz. The subwoofers connect to the SBC800 via binding post banana connectors. The SBC800 provides EQ for all outputs and amplification for subwoofer outputs.
If you own a Quested pa speakers and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Quested Pair of X12 Subwoofers & SBC800 SBC800/2 X X12 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Quested Pair of X12 Subwoofers & SBC800 SBC800/2 X X12:
Specifications
    • 2 x
      X12 Passive 12" Subwoofer (2000W)
      Frequency Response 20 - 200 Hz
      Nominal Impedance 8 Ω
      Maximum Sound Pressure Level (SPL) 91 dB (1 W, 1 m)
      Voice Coil Diameter 4" (10 cm)
      Magnet Composition Ferrite
      Magnet Weight 7.7 lb (3.5 kg)
      Dimensions (W x D x H) 17.7 x 16.3 x 19.7" (45.0 x 41.5 x 50.0 cm) without feet
      Weight 77 lb (35 kg)
    • SBC800 Powered LFE/Sub-Bass and LCR Controller (800W)
      Connectors 4 x XLR and 1/4" combination sockets, inputs female
      3 x XLR outputs, male
      2 pairs of 4 mm banana socket, speaker binding posts +/- , female
      1 x 3.5 mm phone jack, system bypass link and remote switching, female
      1 x IEC, power input
      Impedance XLR and 1/4" Combination Sockets: 10 kΩ, electronically balanced
      XLR Outputs: <100 Ω, electronically balanced
      High Pass Filter -3 dB at 7 Hz, 24 dB/Oct
      Low Pass Filter -3 dB at 100 kHz
      Controls Left, Center, Right (LCR) Channel:
      Phase: 0 - 180°
      Frequency: 30 Hz - 90 Hz, adjustable crossover frequency
      Bypass/Sub-Off: Switches LCR inputs directly to LCR outputs
      Mix Level: -16 dB to +6 dB relative to LCR input

      Low Frequency Effects (LFE) Channel:
      Gain: -16 dB to +6 dB relative to LCR input
      +10 dB Boost: Switched, for LFE input
      Frequency: 50 Hz - 150 Hz, adjustable low pass filtering
      Phase: 0 - 180°
      Bypass: Switched, for LFE section

      Parametric Equalizer (PEQ) Section:
      Frequency: 20 - 90 Hz
      Width: Q Factor 0.5/3.0
      Gain: -6 dB to +6 dB
      Phase/Polarity: 180° phase reversal
      Sub Solo: Mutes all outputs except subwoofers
      Mono Output 800 W @ 4Ω
      400 W @ 8Ω
      Hum and Noise <-105 dB (referred to clip level)
      THD <0.03% at levels up to 1 dB below clip level
      Power Requirements 115 / 230 VAC, 50/60 Hz
      Operation 115 VAC (80 to 127 VAC maximum)
      230 VAC (160 to 255 VAC maximum)
      Power Consumption 45 W (quiescent current)
      Dimensions 19.0 x 3.5 x 11.8" (48.2 x 8.8 x 30.0 cm)
      Weight 23.1 lb (10.5 kg)
