User manual for the Shinybow 4x4 VGA Matrix Routing Switcher SB-4140LCM

The user manual for the Shinybow 4x4 VGA Matrix Routing Switcher SB-4140LCM provides necessary instructions for the proper use of the product Professional Video - Signal Processing & Distribution - Routers & Switchers.

Route any input to any output or all outputs, or cross-route in various combinations. This Shinybow 4x4 offers four VGA inputs, four VGA outputs, and RS-232 serial control. Send different VGA sources, such as PC or satellite signals, to a projector or other VGA display in resolutions up to 1920x1200. Make your routing selections using front panel buttons, RS-232, or the included remote control.

The front panel also offers memory, recall, and lock controls, source status LEDs, and an LCD displaying selected input/output destinations. A Windows compatible control software is included for use with RS-232 control.
If you own a Shinybow routers & switchers and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Shinybow 4x4 VGA Matrix Routing Switcher SB-4140LCM in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Shinybow 4x4 VGA Matrix Routing Switcher SB-4140LCM:
Inputs 4x VGA HD-15
Outputs 4x VGA HD-15
Bandwidth 450 MHz (-3 dB), 200 mVp-p
Supported Resolutions WUXGA (1920x1200), WSXGA, UXGA, SXGA, XGA
Low All Hostile Crosstalk -83 dB @ 5 MHz
Fast Settling Time 15 ns to 0.1%
All Hostile Crosstalk -84 dB @ 5 MHz, -54 @ 50 MHz
Controls Front panel, RS-232, included IR remote
RS-232 Interface DB-9
Gain Control 60 MHz 0.1 dB gain flatness
Chassis Material Metal, 1 mm thin
Safety Approvals CE, FCC, VCCl, REACH, Erp, WEEE
Power Supply 12 VDC, 2 A
100 - 230 VAC, 50/60 Hz
Dimensions 19 x 7.9 x 1.7" (48 x 20 x 4.4 cm)
Weight Approx. 2.5 lb (1.1 kg)
The user manual for the Shinybow 4x4 VGA Matrix Routing Switcher SB-4140LCM can be downloaded in .pdf format if it did not come with your new routers & switchers, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Shinybow users keep a unique electronic library for Shinybow routers & switcherss, where you can use our link to download the user manual for the Shinybow 4x4 VGA Matrix Routing Switcher SB-4140LCM.

The user manual lists all of the functions of the Shinybow 4x4 VGA Matrix Routing Switcher SB-4140LCM, all the basic and advanced features and tells you how to use the routers & switchers. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Shinybow service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Shinybow 4x4 VGA Matrix Routing Switcher SB-4140LCM. User manuals are also available on the Shinybow website under Professional Video - Signal Processing & Distribution - Routers & Switchers.
