The black AV-20D Micro Amplifier from TOA Electronics is a 2 channel digital amplifier for speech and general announcement. It introduces a new standard in small amperes for plenum use. With ultra-compact size, a flexible compliment of inputs and power configuration, control features and carrying both PLENUM rated (UL 2043 listed) and Energy Star 2.0 certification, it is a suitable choice for corporate meeting rooms, POS/signage, board room, conference room, AV presentation room, and kiosks or any place where space and placement limitations are a factor.

This compact amplifier is equipped with switching power supply circuit inside, Energy Star 2.0 certified and PLENUM rated (UL 2043 listed) for the installation into air handling space without external AC adapter. The rated output power is 15W at 8 Ω x 2 channels, 20W at 4 Ω x 2 channels or 40W at 8 Ω in BTL connection.
If you own a Toa Electronics standard amplifiers and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Toa Electronics AV-20D Micro Amplifier AV-20D AM in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Toa Electronics AV-20D Micro Amplifier AV-20D AM:
Specifications
    Power Source 100 to 240 VAC , 50/60 Hz
    Rated Output Current 15 W x 2 channels @ 8 Ω, 20 W x 2 @ 4 Ω or 40 W @ 8 Ω (Bridge)
    Power Consumption Rated Output: 63 W
    Idle: Less than 6 W
    Power Save Mode: Less than 1 W
    Frequency Response 20 Hz to 20 kHz ± 3dB (Line1 Input with Transformer:100 Hz to 20 kHz)
    Total Harmonic Distortion (THD) +N: Less than 0.15%
    Input Line 1: -10/-20 dB (selectable), 10 kΩ, transformer-balanced, removable terminal block
    Line 2: -10/-20 dB (selectable), 10 K Ω, unbalanced, 3.5 mm stereo jack
    Line 3: -10/-20 dB (selectable), 10 kΩ, unbalanced, RCA jacks
    Output Speaker output, removable terminal block (4P)
    Tone Control Bass: ±10 dB at 100 Hz, Treble: ±10 dB at 10 kHz
    Control Master volume control
    Remote volume control
    Bass tone control, Treble tone control
    Bridge ON/OFF Switch
    Mono/Stereo switch
    Input sensitivity switches (Line 1, Line 2, Line 3)
    Indicators Power LED, protection LED, signal LED, peak LED
    Operating Temperature 50 to 104°F (-10 to +40°C)
    Dimensions (W x H x D) 5.90 x 1.73 x 6.14 (150.00 x 44.00 x 156.00 mm)
    Weight 2.2 lb (1.0 kg)
    The user manual for the Toa Electronics AV-20D Micro Amplifier AV-20D AM can be downloaded in .pdf format if it did not come with your new standard amplifiers, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Toa Electronics users keep a unique electronic library for Toa Electronics standard amplifierss, where you can use our link to download the user manual for the Toa Electronics AV-20D Micro Amplifier AV-20D AM.
