User manual for the Ubiquiti Networks PBE-M5-400-ISO-US PowerBeam PBE-M5-400-ISO-US

The user manual for the Ubiquiti Networks PBE-M5-400-ISO-US PowerBeam PBE-M5-400-ISO-US provides necessary instructions for the proper use of the product Computers & Solutions - Networking - Wireless Bridges.

Install the 5-Pack of PBE-M5-400-ISO-US PowerBeam M5 ISO 5 GHz airMAX Bridges with RF Isolated Reflector from Ubiquiti Networks into a variety of network configurations including point-to-multipoint, wireless client, or point-to-point and take advantage of enhanced beamwidth technology. Ubiquiti Networks combines beamwidth technology with RF isolation to filter out noise, creating a cleaner and more reliable connection. Built-in airMAX technology utilizes the Time Division Multiple Access (TDMA) signal which breaks down the signal into specified time slots to reduce collisions. As a result, you receive reduced latency, noise immunity, and improved throughput.
If you own a Ubiquiti Networks wireless bridges and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Ubiquiti Networks PBE-M5-400-ISO-US PowerBeam PBE-M5-400-ISO-US in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Ubiquiti Networks PBE-M5-400-ISO-US PowerBeam PBE-M5-400-ISO-US:
Specifications
Processor Atheros MIPS 74Kc, 560 MHz
Memory 64 MB DDR2, 8 MB flash
Networking Interface 1 x 10/100 Ethernet port
Wireless Approvals FCC, IC, CE
RoHS Compliance Yes
Power Supply 24 V, 0.5 A PoE
Power Method Passive PoE (Pairs 4, 5+; 7, 8 Return)
Voltage Range 18-26 VDC
Power Consumption 8 W (max.)
Gain 25 dBi
Operating Frequency Worldwide: 5170 - 5875 MHz
USA: 5725 - 5850 MHz
Wind Loading 88 lbf @ 125 mph (390 N @ 200 km/h)
Wind Survivability 125 mph (200 km/h)
LEDs 1 x Power
1 x LAN
4 x WLAN
Signal Strength LEDs Software-adjustable to correspond to custom RSSI levels
Channel Sizes 5/8/10/20/30/40 MHz
Polarization Dual Linear
Enclosure Outdoor UV stabilized plastic
Mounting Pole-mounted kit included
ESD/EMP Protection Air: ± 24 kV
Contact: ± 24 kV
Temperature & Humidity Operating Temperature: -40 to 158°F / -40 to 70°C
Operating Humidity: 5 to 95% non-condensing
Salt Fog Test IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5
Vibration Test IEC 68-2-6
Temperature Shock Test IEC 68-2-14
UV Test IEC 68-2-5 at 104° F (40° C), Equivalent: ETS 300 019-1-4
Wind-Driven Rain Test ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5
Output Power Output Power
24 dBm
TX Power Specifications
802.11a
Data Rate Avg. TX Tolerance
6 - 24 Mbps 24 dBm ± 2 dB
36 Mbps 24 dBm ± 2 dB
48 Mbps 23 dBm ± 2 dB
54 Mbps 22 dBm ± 2 dB
802.11n/airMAX
Data Rate Avg. TX Tolerance
MCS0 24 dBm ± 2 dB
MCS1 24 dBm ± 2 dB
MCS2 23 dBm ± 2 dB
MCS3 23 dBm ± 2 dB
MCS4 22 dBm ± 2 dB
MCS5 21 dBm ± 2 dB
MCS6 20 dBm ± 2 dB
MCS7 20 dBm ± 2 dB
MCS8 24 dBm ± 2 dB
MCS9 24 dBm ± 2 dB
MCS10 23 dBm ± 2 dB
MCS11 23 dBm ± 2 dB
MCS12 22 dBm ± 2 dB
MCS13 21 dBm ± 2 dB
MCS14 20 dBm ± 2 dB
MCS15 20 dBm ± 2 dB

RX Power Specifications
802.11a
Data Rate Sensitivity Tolerance
6 - 24 Mbps -94 dBm Min. ± 2 dB
36 Mbps -80 dBm ± 2 dB
48 Mbps -77 dBm ± 2 dB
54 Mbps -75 dBm ± 2 dB
802.11n/airMAX
Data Rate Sensitivity Tolerance
MCS0 -96 dBm ± 2 dB
MCS1 -95 dBm ± 2 dB
MCS2 -92 dBm ± 2 dB
MCS3 -90 dBm ± 2 dB
MCS4 -86 dBm ± 2 dB
MCS5 -83 dBm ± 2 dB
MCS6 -77 dBm ± 2 dB
MCS7 -74 dBm ± 2 dB
MCS8 -96 dBm ± 2 dB
MCS9 -95 dBm ± 2 dB
MCS10 -92 dBm ± 2 dB
MCS11 -90 dBm ± 2 dB
MCS12 -86 dBm ± 2 dB
MCS13 -83 dBm ± 2 dB
MCS14 -77 dBm ± 2 dB
MCS15 -74 dBm ± 2 dB
Max VSWR 1.5:1
Built-In Mechanical Downtilt ±20°
Dimensions 18.07 x 18.07 x 10.28" / 459 x 459 x 261 mm
Weight 7.10 lb / 3.22 kg
Packaging Info
Package Weight 50.65 lb
Box Dimensions (LxWxH) 20.5 x 20.4 x 16.2"
The user manual for the Ubiquiti Networks PBE-M5-400-ISO-US PowerBeam PBE-M5-400-ISO-US can be downloaded in .pdf format if it did not come with your new wireless bridges, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Ubiquiti Networks users keep a unique electronic library for Ubiquiti Networks wireless bridgess, where you can use our link to download the user manual for the Ubiquiti Networks PBE-M5-400-ISO-US PowerBeam PBE-M5-400-ISO-US.

The user manual lists all of the functions of the Ubiquiti Networks PBE-M5-400-ISO-US PowerBeam PBE-M5-400-ISO-US, all the basic and advanced features and tells you how to use the wireless bridges. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Ubiquiti Networks service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Ubiquiti Networks PBE-M5-400-ISO-US PowerBeam PBE-M5-400-ISO-US. User manuals are also available on the Ubiquiti Networks website under Computers & Solutions - Networking - Wireless Bridges.



Discussion Question and answer discussion forum concerning user instructions and resolving problems with the Ubiquiti Networks PBE-M5-400-ISO-US PowerBeam PBE-M5-400-ISO-US - no comments have been made yet - be the first to add a comment

Post new comment/question/response regarding the Ubiquiti Networks PBE-M5-400-ISO-US PowerBeam PBE-M5-400-ISO-US
