The VAMP AC-3/M from Wohler/Panorama is a professional-quality high resolution audio and video device that's been designed for the specific task of simultaneously monitoring HD/SD-SDI digital video and AC-3 or AES/EBU digital audio. While it may not be the most practical gadget to have lying around the house, the VAMP AC-3 is indispensable in mobile production vehicles, TV studios, radio stations, VTR bays, and any situation associated with ATSC/DVB programming.
If you own a Wohler rack mount monitors and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Wohler VAMP AC-3/M - HD/SD-SDI/AES/AC-3 Audio/Video VAMP AC-3/M in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Wohler VAMP AC-3/M - HD/SD-SDI/AES/AC-3 Audio/Video VAMP AC-3/M:
Specifications
    Signals Supported AES/EBU
    HD/SD-SDI
    Dolby AC-3
    Rack Height 2U (2 Rack Spaces)
    Analog Inputs None
    Analog Outputs 2 Balanced XLR Analog outputs from selected source
    AES/EBU Inputs:
    4 Unbalanced Dolby AC-3 or AES Input on BNC
    1 Balanced XLR Dolby AC-3 or AES Input

    Outputs:
    1 Unbalanced Dolby AC-3 or AES Loop-Through Output Pair on BNC
    1 Balanced Dolby AC-3 or AES Loop-Through

    SDI Input 2 HD/SD-SDI Video Inputs on BNC
    SDI Output 1 HD/SD-SDI Re-Clocked Output on BNC
    Meters 6 x 53-Segment LED (Vertical)
    Display Modes NTSC/PAL Auto-Sensing
    Display Size 4.3"
    Aspect Ratio 16:9
    Resolution 480 x 272
    Frequency Range 80 Hz - 16 kHz, +/- 5 dB
    (-10 dB @ 40 Hz, 20 kHz)
    Maximum Sound Pressure Level (SPL) 100 DB SPL
    Shielded <0.8 Gauss Any Adjacent Surface
    Power Consumption 45W
    Power Supply IEC Connector, Universal Input, 100-240VAC, 50/60 Hz, CE & UL Approved
    Dimensions (HxWxD) 3.5 x 19 x 12" (89 x 483 x 305 mm)
    Weight 18 lbs (8.2 kg)
