User manual for the A-Neuvideo 24x24 RGB Serial Matrix Switcher ANI-RGB2424
The user manual for the A-Neuvideo 24x24 RGB Serial Matrix Switcher ANI-RGB2424 provides
necessary instructions for the proper use of the product Professional Video - Signal Processing & Distribution - Routers & Switchers.
This is a professional crosspoint RGB Matrix Switcher from A-Neuvideo, offering 24 Component BNC inputs and 24 outputs. It uses high-performance IC chips and features a 350MHz bandwidth supporting resolutions up to 2048 x 1536/60Hz and 1280 x 1024/120Hz.
A monochrome dot-matrix LCD display confirms routing selections, which you can control via front panel push buttons or RS-232 communication interface. Up to 30 user preset matrixes can be stored. A user-friendly GUI compatible with all versions of Windows up to Windows 8 is included.
|
