AJA's HD/SD 8 Channel AES Embedder/Disembedder is a dual rate 8-channel AES audio Embedder/Disembedder. The Disembedder is always functional providing 4 AES outputs. The Embedder is user selectable, on a channel pair basis, to either "pass" SDI input audio or to embed input AES audio from the breakout cable. AES inputs are sample rate converted to a 48KHz rate synchronous to the video input. The HD10AM automatically detects and configures to the input video standard.
If you own a AJA embedders & de-embedders and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the AJA HD/SD 8 Channel AES Embedder/Disembedder HD10AM in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
User manual for AJA HD/SD 8 Channel AES Embedder/Disembedder HD10AMDownload user manual for AJA HD/SD 8 Channel AES Embedder/Disembedder HD10AM
(PDF file, 0.58 MB)
Additional parameters of the AJA HD/SD 8 Channel AES Embedder/Disembedder HD10AM:
Specifications
    Formats HD SMPTE 292/296M SD SMPTE 259M (Automatic Configuration)
    Video Input HD-SDI or SDI BNC
    Video Output Follows input, 2 x BNC
    Audio Input 4 x AES 110 ohm XLR
    Audio Output 4 x AES 110 ohm XLR
    AES Audio SMPTE 272M/299M, 48KHz synchronous
    User Controls External Dipswitch, Embedder On/Off, Ch pairs 1/2 - 7/8 Input group select 1/2, 3/4 Output Group Select 1/2, 3/4 SRC Bypass
    Power +5-18VDC, 5 watts
    Dimensions 5.8 x 3.1 x 1" (147 x 79 x 25 mm)
    Packaging Info
    Package Weight 2.5 lb
    Box Dimensions (LxWxH) 9.8 x 7.1 x 2.9"
    The user manual for the AJA HD/SD 8 Channel AES Embedder/Disembedder HD10AM can be downloaded in .pdf format if it did not come with your new embedders & de-embedders, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other AJA users keep a unique electronic library for AJA embedders & de-embedderss, where you can use our link to download the user manual for the AJA HD/SD 8 Channel AES Embedder/Disembedder HD10AM.

    The user manual lists all of the functions of the AJA HD/SD 8 Channel AES Embedder/Disembedder HD10AM, all the basic and advanced features and tells you how to use the embedders & de-embedders. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from AJA service.

    If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the AJA HD/SD 8 Channel AES Embedder/Disembedder HD10AM. User manuals are also available on the AJA website under Professional Video - Signal Processing & Distribution - Embedders & De-Embedders.
